SUN HONG PM CLOTH
Polyester Forming fabrics.
Paper making polyester forming fabrics can be divided into 4-shed, 5-shed, 8-shed, 16-shed, 24-shed according to the weaving type. Single layer, double layer, two-and a half layer fabric and triple-layer fabric are the three common Items.
4-shed and 5-shed series single layer polyester forming fabrics are the two widely used polyester forming fabric in paper making, mainly used for producing cultural paper (single glue, double glue and color glue), printing paper, glazed paper, packing paper, common newsprint. Suitable for common fourdrinier paper machine.
8-shed single layer polyester forming fabric is suitable for kraft paper, cardboard , corrugated paper making. Also could be used for producing common printing paper. Suitable for common fourdrinier paper machine.
8-shed double layer fabric is suitable for producing quality printing paper. For example ,dictionary paper, offset printing paper, newsprint and wrap paper. It can be used for tissue paper making and the surface pulp, lining pulp, core pulp and bottom pulp of the board paper etc. Suitable for medium and high speed paper making machine.
16-shed double and a half layer polyester forming fabric is suitable for producing quality printing paper, such as offset printing paper, copper plate paper, newsprint and cigarette paper series (wrap paper and filter tips paper), Also is could be used for producing toilet paper, tissue paper and surface pulp, lining pulp, core pulp and bottom pulp of the board paper etc. Suitable for medium and high speed paper making machine.
Multi-shed three-layer fabric is suitable for producing quality printing paper, tissue paper and cigarette paper etc. Suitable for high speed paper making machine.
Single Layer Forming Fabric
Models | Weaving series and types | Filament diameter mm | Density(root/cm) | tensile strength | Thickness mm | m³/m²h | Force elongtion (in 50N/cm Tension,Tensile rate not more than ) | |||
warp | weft | warp | weft | surface | joint | |||||
SH27254 | 4 heddle monolayer forming fabric | 0.2 | 0.25 | 30 | 22 | ≥600 | ≥400 | 0.49 | 8000 | 0.60% |
SH27274 | 0.2 | 0.27 | 30 | 21.5 | ≥600 | ≥400 | 0.51 | 7800 | 0.60% | |
SH31204 | 0.18 | 0.2 | 35 | 28 | ≥600 | ≥380 | 0.43 | 7500 | 0.68% | |
SH31204-1 | 0.18 | 0.2 | 35 | 30 | ≥600 | ≥380 | 0.43 | 7000 | 0.68% | |
SH30205 | 5 heddle monolayer forming fabric | 0.17 | 0.2 | 32 | 28.5 | ≥500 | ≥350 | 0.41 | 7100 | 0.60% |
SH31215 | 0.2 | 0.21 | 35 | 32 | ≥600 | ≥400 | 0.48 | 7000 | 0.60% | |
SH25358 | 8 heddle monolayer forming fabric | 0.22 | 0.35 | 28 | 19.5 | ≥700 | ≥500 | 0.85 | 9000 | 0.65% |
SH25388 | 0.22 | 0.38 | 29.5 | 19 | ≥700 | ≥500 | 0.87 | 8500 | 0.65% | |
SH27358 | 0.22 | 0.35 | 30 | 20 | ≥700 | ≥500 | 0.85 | 8500 | 0.65% | |
SH25458 | 0.22 | 0.45 | 29 | 15.2 | ≥700 | ≥500 | 0.87 | 7500 | 0.65% |
Double and A Half Layer Forming Fabric
Models | Warp Mesh | Weft Count | Warp Diameter | Weft Diameter | Air Permeability | FSI | DI | |
/m³/m²H | CFM | |||||||
SH2B6408 | 71.5-72.5 | 67.5-68.5 | 0.15 | 0.18 0.12/0.22 0.22 | 4350 | 275 | 155 | 25.7 |
71.5-72.5 | 65.5-66.5 | 0.15 | 0.18 0.12/0.22 0.22 | 4600 | 290 | 152 | 26.3 | |
71.5-72.5 | 56.5-57.5 | 0.15 | 0.18 0.12/0.22 0.22 | 5800 | 370 | 135 | 29 | |
71.5-72.5 | 47.5-48.5 | 0.15 | 0.18 0.12/0.22 0.22 | 7900 | 500 | 119 | 33 | |
SH2B5616 | 62.5-63.5 | 60.5-61.5 | 0.17 | 0.20 0.13/0.30 0.30 | 4500 | 285 | 139 | 23.9 |
62.5-63.5 | 59.56-60.5 | 0.17 | 0.20 0.13/0.30 0.30 | 3950 | 250 | 137 | 20.6 | |
62.5-63.5 | 53.5-54.5 | 0.17 | 0.20 0.13/0.30 0.30 | 5050 | 320 | 126 | 23.7 | |
62.5-63.5 | 47.5-48.5 | 0.17 | 0.20 0.13/0.30 0.30 | 6000 | 380 | 115 | 25.1 | |
SH2B4216 | 47.0-48.0 | 47.0-48.0 | 0.22 | 0.20 0.13/0.30 0.30 | 6000 | 380 | 107 | 25.1 |
47.0-48.0 | 40.0-41.0 | 0.22 | 0.25 0.17/0.40 0.40 | 7000 | 445 | 94 | 25.1 | |
SH2B3616 | 40.5-41.5 | 38.5-39.5 | 0.26 | 0.30 0.20/0.50 0.50 | 5500 | 350 | 89 | 18.8 |
40.5-41.5 | 36.5-37.5 | 0.26 | 0.30 0.20/0.50 0.50 | 6350 | 400 | 85 | 20.4 | |
40.5-41.5 | 34.5-35.5 | 0.26 | 0.30 0.20/0.50 0.50 | 7000 | 445 | 82 | 21.4 |
Triple(SSB) Layer Forming Fabric
Models | Warp Mesh | Weft Count | Warp Diameter | Weft Diameter | Air Permeability | FSI | DI | |
/m³/m²H | CFM | |||||||
SH3C6020 | 69.5-70.5 | 79.5-80.5 | 0.13/0.20 | 0.13 0.13/0.27 0.27 | 3950 | 250 | 195 | 25.4 |
SH3C5220 | 59.5-60.5 | 79.5-80.5 | 0.13/0.20 | 0.13 00.13/0.30 0.30 | 4500 | 285 | 186 | 29 |
59.5-60.5 | 67.5-68.5 | 0.13/0.20 | 0.13 0.13/0.30 0.30 | 6350 | 400 | 166 | 34.5 | |
59.5-60.5 | 61.5-62.5 | 0.13/0.20 | 0.15 0.15/0.35 0.35 | 6000 | 380 | 156 | 29.9 | |
SH3C5224 | 51.5-52.5 | 54.4-55.5 | 0.17/0.25 | 0.17 0.17/0.40 0.40 | 4500 | 285 | 137 | 19.9 |
51.5-52.5 | 48.5-49.5 | 0.17/0.25 | 0.17 0.17/0.40 0.40 | 6000 | 380 | 127 | 23.6 | |
SH3C4224 | 41.5-42.5 | 43.5-44.5 | 0.22/0.30 | 0.22 0.22/0.45 0.45 | 5500 | 350 | 110 | 19.6 |
41.5-42.5 | 39.5-40.5 | 0.22/0.30 | 0.22 0.22/0.45 0.45 | 7000 | 445 | 103 | 22.6 | |
SH3C4220 | 41.5-42.5 | 49.5-50.5 | 0.20/0.30 | 0.22 0.22/0.45 0.45 | 5500 | 350 | 119 | 22.2 |
41.5-42.5 | 45.5-46.5 | 0.20/0.28 | 0.22 0.22/0.50 0.50 | 6350 | 400 | 113 | 23.4 | |
41.5-42.5 | 39.5-40.5 | 0.20/0.28 | 0.22 0.22/0.50 0.50 | 8000 | 505 | 103 | 25.7 |
Feature of Sun Hong Fabric | ||
*Superb dimensional stability. | ||
*Excellent anti-wear property. | ||
*Minimum drainage resistance. | ||
*Allows for smallest thread mark. | ||
*Great retention of fiber fines. | ||
*Much longer lifespan. |
Contact Us
Jack
Cell:+86151 5003 6871
www.sunhongfabric.com
Prod Model: | SH-FF109 |
---|---|
Name: | Forming Fabrics |
Supply Type: | Make-to-Order |
Wire Diameter Warp(mm): | 0.17-0.22 |
Wire Diameter Weft(mm): | 0.20-0.45 |
Density (Root/Cm) Warp: | 28-35 |
Density (Root/Cm) Weft: | 15.2-32 |
Thickness: | 0.41-0.87 |
