blow moulding machine for producing 60liter drum:
above all production photos is only reference .
his kind of blow molding machine is suitable for open mouth drum or smaller mouth of drum, jerrycan , plastic mannequin ,bus seat and so on .
BLOW MOULDING MACHINE PARAMATER :
| MACHINE MODEL | | HZB90 |
| | | |
| max container capacity | L | 60 |
| machine dimension | M | 5.3*2.4*3.8 |
| total weight | ton | 14 |
| | | |
| clamping force | kn | 320 |
| platen opoening stroke | mm | 450-1050 |
| platen size | mm | 900*880 |
| max mould size | mm | 720*1200 |
| minimum mould thickness | mm | 460 |
| | | |
| motor power of pump | kw | 15 |
| air pressure | mpa | 1 |
| air consumption | m3/min | 0.8 |
| total power | kw | 94 |
| average engergy consumption | kw | 56 |
| | | |
| screw diameter | mm | 90 |
| screw L/D ratio | | 24 |
| plasticing capacity | kg/hr | 140 |
| number of heating zone | | 4 |
| extruder heating power | kw | 21.4 |
| extruder driving | kw | 37 |
| | | |
| number of heating zone | | 4 |
| power of die head | kw | 21.3 |
| max die pin diameter | mm | 350 |
| max die capacity | L | 8 |
blow molding machine parts:1. MITSUBISHI Japan PLC +WINVIEW Touch screen, making the operation easy. Automatic malfunction alarm with selfdiagnosis, making the malfunction clear at a glance.
2. Center input die head, eliminating the kint line completely and making it easy to change the material and color.
3. Double liner rolling moting guider in moving, opening and closing mold, making the claming force equally distributed, so the cut is smoother.
4. Control the hydraulic system with imported proportional valve YUKEN Japan, ensuring the action steasy, accurate and energy saving 35%.
5. High speed and efficient plasticizing system, mixing well and ensuring the produce purity
6. Clamping system: Diagonial two die bar center clamping bi-directional high precision linear guide lamping device
package and shipment for blowmolding machine :in common , wooden pallet and film packing for blow molding machine , wooden box for auxiliary machine and mould , spare parts , if customer has different requirement , we could make some change or adjust our packing type .
