| Price: | US $ 10-100/Square Meter |
|---|---|
| Min Order: | 10/Square Meter |
| Pay Type: | T/T |
| Prod Model: | Awning windows |
|---|---|
| Name: | Awning Windows |
| Payment: | Tt or Others |
| Material: | Aluminum Alloy |
| Frame Material: | Aluminum Alloy |
| Screen Netting Material: | Fiberglass |
| Style: | Modern |
| Opening Pattern: | Horizontal |
| Function: | Invisible |
| Surface Finishing: | Finished |
| Security Rating: | A |
| Open Style: | Crank Open |
 | Profile System | LMA100 |
| Open Style | Crank Open | |
| Window Frame: | Thermal break Aluminum | |
| Surface Finishing: | Anodized | |
| Glass Type: | 5+12A+5mm double glass | |
| Standard: | AS2047 Standard | |
| Hardware: | Original Australia Brand | |
| Fly screen: | Fiberglass·Stainless Steel | |
| More Details - 100mm frame depth - 22mm insulated glass - 1.5mm extruded aluminum thickness - 20μ Anodized coating thickness - German friction stay for MAX 70KG sash. - Key lockable winder for added security - Sash operator has a folding handle to keep it clear of blinds | ||
| Profiles | 1. Thermal break aluminum profiles 2. Non-thermal break aluminum profiles 3. 1.4-2.0mm aluminum profile thickness for choice |
| Glazing | 1. Double tempered glazing: 5+9A+5/ 5+12A+5/ 6+9A+6/ 6+12A+6... 2. Single tempered glazing: 5/6/8/10/12... 3. Laminated glazing:6.38/10.76/10.38 Options: Low-e glazing, frosted/obscure glazing/grey/blue/green tinted glazing |
| Hardware | 1. Germany brand 2. Japanese brand 3. Chinese Brand |
| Fly Screen | 1. Stainless steel security mesh 2. Security mesh 3. Nylon screen 4. Mosquito screen |
| Aluminum Surface Finished | 1. Power Coating 2. Anodized 3. Electrophoresis 4.Wood grain 5. Fluorine carbon painting |
| Color | 1. white,matt black, silver grey or customized 2. Anoized: Silver 3..Kinds of wooden pattern |
| Windows Types | Awning windows, Sliding windows, Vertical slide windows, Casement windows, Tilt & turn windows, Fixed windows,Sliding doors,Hinge door, Bi-fold door, lift and sliding doors, Pivot door, Escape door, Sensor door, Glass louver, aluminum Louver |
| Package | iron Pallet, Corrugated Board,Protective film, Air bags |
| Installation Materials | Angle Aluminum, Timber reveals and sub sills are available |
| Warranty period | 7-10 years for choice |
| Standard | AS2047 |
