Automatic Plywood Core Veneer Composer/Core Veneer Sewing Machine
| Price: |
US $ 30000-35000/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T |
| Prod Model: |
DCBJ-9C |
| Driver: |
Siemens Servo Motor |
| External Dimension: |
12000mm*26000mm*2500mm |
| Structure: |
Integral Steel Plate Cutting |
| Transmission Speed: |
0-35mm/Minute Adjust |
| Working Efficiency: |
300PCS/H |
| PLC Computer Module: |
Siemens PLC |
| Total Weight: |
5500kg |
| Total Power: |
16.5kw |
| Service Voltage: |
380V |
| Working Thickness: |
1.1mm-3.6mm |
| Certification: |
BV |
Product Description
The advantages of the machine1.One operator, no overlap and seamless, no break;
2.Save 70% of core finishing
3.Save 80% assembling workers
4.Save 50% puttying workers
Main applicationsthe machine is mainly used for the production of three-ply board, sandwich panel, LVL, floor substrate, furniture panel, building film faced plywood, container board, melamine plywood, blockboard etc, and it can also be used for the horizontal splicing of rotary cut core veneer with the thickness of 1.2-3.6mm. This changes the traditional manual decking technology and makes plywoood decking unitized and automatic. The used of the machine save lots of core finishing worker, improve the quality of products and save labor costs.
Working principle core veneer (1.2-3.6mm thickness) after dying may have different length and thickness, and the shapes may get irregular. This machine can detect the width, thickness, cavities of the panels, and have them rimmed, glued, spliced, cut to length and stacked automatically. with this machine, customized board of different sizes an be spliced.
Features and advantages1.PLC control, unmanned operation, automatic process, laborsaving.
2.Precise thickness checking, even thickness, mini polishing.
3. Servo drive, effective overlap and joint control.
4.Supported by German Festo, Danfoss, Taiwan Taida, Japanese Mitsubishi and other international to level brands.
5.Highly strengthened thread, improve product horizontal tensile force and flexibility, no break.
FQA1. Are you a factory or trading company?
We are factory , professing plywood core veneer machine equipment manufacturer with 10 years.
2.Wher is your factory located ? How can I visit there?
Our factory is located Lanshan , Linyi city, Shandong Province, china. About 30minutes away from Linyi Airport. All of customers of home and abroad are welcome to visit us.
3.How long is the warranty of your equipment?
One year warranty receipt check upon delivery and we will comprehensive provide you all kinds of technical support services in after-sale.
4.How long I can get feedback after we sent the enquiry?
We will reply you within 12hours in working day.
5.What's the payment term?
T/T 30% in advance, the balance paid before delivery.
6.What is the moisture content of the core plate for use plywood veneer splicing machine?
Moisture in 10%-30% core veneer(board)can be used for this machine.Contract us any time
Shandong Linyi Dadong Machinery Co., Ltd., founded in 2009, is a collection of r &d, design, manufacture, sales, service as one of the new type of modern enterprise. Since its establishment, always follows the policy of people-oriented, science and technology first, reform and innovation. We bring new technology into products in time, make the products get rapid promotion and application. Our products adopt the advanced PLC control technology of industrial computer module. The electric equipment and spare parts we choose, are all well-known brands at home and abroad. For example, Festo, Delta, Omron, Siemens, Mitsubishi and so on. This makes our products more obvious efficiency and quality more stable.
We have a good after-sales service team. We always put the customers' needs as the standard of our service, timely solve difficult as soon as possible for the customer. We deeply know that only us were approved by the customer, can we have the market. So, if your products have any problems, you just need phone to us, then we will do the other things.
