Cemented CNC Carbide Button Bits for Wood Drilling
| Price: |
US $ 55-5816 |
| Min Order: |
116 |
| Pay Type: |
T/T,Western Union,Paypal |
1. Advancetages
(1).100% virgin material, HIP-Sintered
(2). Advanced equipments, including "Spray drying tower, CNC press machine, Peripheral grinding machine, HIP-Sinter"
(3). Strict quality control, inspect each batch of products
(4). Professional technical team, our company engaged in carbide industry for decades
(5). Big production capacity & fast delivery time. 50 tons / month, delivery time 5 - 15 days
(6). Good after sale service2. Details DiscriptionsButton bit taper angle/degree: 4um 46, 6um , 7um, 11um , 12um
Socket inside diameter: 19 22 25 28 32 34 36 38 40 42(mm)
3. Grade Recommomdation
Grade |
Density
g/cm3 |
TRS
MPa |
Hardness
HRA |
Performance & application recommended |
YG4C |
15.10 |
1800 |
90.0 |
Mainly used as small buttons for percussion bits to cut soft and medium hard formations. |
YG6 |
14.95 |
1900 |
90.5 |
For coring crowns, electric coal drill bits, coal cutting picks, oil cone bits and scraping knife bits, used in geological prospecting, coal mining and oil well boring. |
YG8 |
14.80 |
2200 |
89.5 |
For coring crowns, electric coal drill bits, coal cutting picks, oil cone bits and scraping knife bits, used in geological prospecting, coal mining and oil well boring. |
YK05 |
14.95 |
2500 |
90.5 |
Mostly used as the buttons of small and medium sized percussion bits and as the inserts of rotary prospecting bits to cut soft and medium hard formations. |
YG8C |
14.80 |
2400 |
88.5 |
YK15 |
14.60 |
2450 |
87.6 |
Suitable to strips, conical buttons for rotary percussion-resistant, geological prospection buttons, cut soft and medium hard formations. |
YK20 |
14.40 |
2500 |
86.8 |
Primarily for the buttons and inserts of rotary percussion bits to cut medium-hard and hard formations. |
YK25 |
14.40 |
2550 |
87.2 |
Primarily for the buttons and inserts of rotary percussion bits to cut medium-hard and very hard formations. |
YG11C |
14.40 |
2700 |
86.5 |
Largely for the inserts and buttons of percussion bits and tricone bits to cut medium-hard, hard, and very hard formations. |
YG13C |
14.2 |
2850 |
86.0 |
Primarily for the buttons of tricone bits and inserts of rotary percussion bits to cut hard and very hard formations. |
YG15C |
14.0 |
3000 |
85.5 |
For oil cone drill bits, for medium soft and medium-hard rocks. |
4.Our Services
(1)More than 2000 products are available. Assembly line production, high standard and strict requirements.
(2)OEM Services Offered
(3)Customized Tools Offered
(3)Free laser marking on tools and boxes Offered
(4)Fast delivery time and Convenient Transportations. We have discount on shipping cost from our courier companies, such as FedEx, DHL, TNT, UPS etc. 5.Company InformationZhuzhou Grewin Tungsten Carbide Tools Co., Ltd is located in hometown of Chinese carbide industry - Zhuzhou city. The company has more than 20 years' experience in manufacture, design and sale of various kinds of carbide products, main products include: Carbide end mills, carbide rods, indexable inserts, brazed inserts, wire drawing dies, forging dies, wood working tools, saw tips, mining buttons, etc
The company has passed ISO 9001: 2008 quality system, possesses advanced production equipments, complete testing instruments, strong R&D center and QC teams.
With excellent quality, strong technical support, and good after sales service, Grewin Carbide brand products are sold to more than 50 countries in the world, such as Europe, USA, south east Asia, Middle East, south America, etc.
The company is dedicated to " WE GROW, WE WIN". Grewin Carbide is growing up with the World's carbide technology, to meet the demand of our customers from all over the world. 6. Product Pictures
7.Contact US
Waiting for your ealry contact and inquiry here!
| Prod Model: |
All sizes |
| Shape: |
Standard or Customized |
| Model No: |
K034, K036, Sq1019, Sq1119, Sq1320, Sz1420 |
| Grade: |
Yg8c, Yg11c, Yk05, Yk20 |
| Features: |
Good Wear Resistance, High Precision |
| Sample: |
Free |
| Application: |
Mining, Water Well Drilling, Construction |
| Brand: |
Grewin |
| Delivery Time: |
15-25days |
| Condition: |
100% New |
| ODM/OEM: |
Accepted |
| Type: |
Drilling Bit |
What we do is not a deal, but create mutual happy cooperation!
Zhuzhou Grewin Tungsten Carbide Tools Co., Ltd is located in hometown of Chinese carbide industry - Zhuzhou city. The company has more than 20 years' experience in design and sale of various kinds of carbide products, main products include: Carbide end mills, carbide rods, indexable inserts, brazed inserts, wire drawing dies, forging dies, wood working tools, saw tips, mining buttons, etc
The company has passed ISO 9001: 2008 quality system, possesses advanced production equipments, complete testing instruments, strong R&D center and QC teams.
With excellent quality, strong technical support, and good after sales service, Grewin Carbide brand products are sold to more than 50 countries in the world, such as Europe, USA, south east Asia, Middle East, south America, etc.
The company is dedicated to " Do the best to customer". Grewin Carbide is growing up with the World's carbide technology, to meet the demand of our customers from all over the world.
