Cloth Fabric Weaving Loom Textile Machinery Jersey Weaving

Name: Cloth Fabric Weaving Loom Textile Machinery Jersey Weaving
Brand: FullPackage
SKU: 695579822
Availability: InStock
Rating: 4.4 (20 reviews)

Price:	US $ 14000-15000set
Trade Terms:	FOB,CFR,CIF
Min Order:	1set
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

CONTACT :
MS. SOPHIA
Mobile : 0086-15275290698

JLH910 Tsudakoma Air Jet Loom Textile Weaving Machinery Price Jersey Weaving

Advantage:

professional manufacturer
2.Good price
3.High-quality weaving(fabric side forming of good quality)
4.Yarn count range to adapt to light(filament,staple fiber)
5.Low energy consumption and low labor costs

Raw material		Combed yarn 7s-80s ,silk, polyester yarn
Respective fabric		100% cotton 60s x 60s 90x88(warp x weft density/inch) (fabric width:178cm) Rayon 45s x 45s 100x80 178cm
Respective machine		Reed width:190cm Shedding:Plain Electronic feeder:2 nozzle Single warp beam Electronic let off and take up ELO& ETU Motor:1.8KW Air consumption:0.7---0.8(different fabric,different air consumption) R.P.M :750-800
If you send us enquiry, please tell us details like following Fabric width:190cm *Fabric warp and weft density:6868 Fabric weave: satin**
JLH910 air jet loom configuration
	Item name		Brand	performance	remark
1	electric equipment		Inovance-China	Latest model
2	feeder		special for jinlihua	double nozzle/four nozzle/six nozzle	Exploration eye and electromagnetic needle imports
3	magnetic valve and nozzle		SMC Jiete	twin nozzle per valve
4	ELO & ETU		Inovance-China
5	weft scissor			special for JLH425m	Import
6	heald frame		New Light brand-Made in China
7	motor		China brand
8	roller seat		positive easing	You can move back and forth up and down, conducive to warp beam	use new type
9	roll axis			solid beating	special for JLH910
10	oil seal		special for JLH910	NOK-Japan
11	bearing in gear box			all import bearing
12	cam dobby		by customer requirement	Changfang-China	Staubli-Made in China
13	dobby		by customer requirement	Changfang-China	Staubli-Made in China
14	jacquard		by customer requirement
15	weft feeder		by customer requirement	Jinlihua-China	ROJ-Made in China
16	electric equipment		by customer requirement	inovance-China	Nanjing Baina-China
					B&L-Europe card

High speed
High rigid structure air jet loom can effectively reduce the vibration caused by high
speed operation

Wide ranging versatility

main products in factory :

AIR JET LOOM	JLH9200	Air compressor	Latest model high speed air jet loom	Link
	JLH910	Air compressor	Ecnomical air jet loom
	JLH425S	Air compressor	Grey gauze fabric weaving
	JLH740	Self air pump	Smart Gauze weaving machine
	JLH425B	Air compressor	Glass fiber weaving machine
	JLH9200M	Air compressor	Terry towel weaving air jet loom
Water jet loom	JLH851	Normal water jet loom	Normal speed ,lower price
	JLH408	High speed water jet loom	High speed reasonable price
	JLH8200	Most advanced water jet loom ZW8100	Super speed heavy fabric weave

Best price air jet loom is designed applicable to a wide range of
fabrics from light weight to middle thick, from low density to high density.

Energy saving

New designed air jet loom can dramatically lower the maintenance, labor and
electricity costs.

main configuration:

Working range	Spun:7-80tex filament:40-500 dtex
Reed width (cm)	Nominal:190 230 280 340 Useful reeding width:reduct 0-60cm
Weft selection	6 color,4 color,2 color,single color
Motor	Super motor with 2.7kw-3.7kw (selected according to the certain model)
Weft picking	Electronic main nozzle+assistant nozzle+profile reed
Shedding	Negative cam machine,8 heald frame
	Positive cam machine,8 heald frame
	Dobby(mechanical),upper negative dobby or electronic dobby,2-16 heald frame (according to customer's demands)
Let-off	Electronic let off-ELO
	Positive let-off device
	Flange diameter:800mm,1000mm
Take-up	Mechanical take-up (25pieces/inch-200pieces/inch)
	Electronic take-up(25pieces/inch-205pieces/inch)
	Upper and down temple(according to the varity of fabric)
Beating	Crank type multiple sley sword beating device,4 rods beating(280cm below),6 rods beating(280cm above)
Yarn storage	Electronic tumbler
selvedge	Leno yarn by planetary gear
Waste filling removel	Mechanical take-up 3 roller
Cutter	Mechanical cutter
lubrication	Oil lake for the main drive parts,thicker oil for centralized lubrication of the rest part.(pump)
Control	Weft:double optical feeler
	Warp:electronic sensor control
	Selveage:stop motion for selvage and catch cord yarn.
	Parking reason:display:4 color lamp display,main keyboard displays the information
Electronic box	The operation of the loom is controlled by computer
	Electromagnetic fixed brake
	Slow speed inching by variable frequency
	Main keyboard

SERVICE:
1.Reply your inquiry in 24 working hours.
2. Customized design is available.
3. We now realizes a one-stop service system including processing, production, installation, storage, sales and after-sale service.
4. Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staff.

Prod Model:	JLH910
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Color:	Cream
Speed:	500-900rpm
Cloth Roller:	Normal/Jumbo Package
Payment Term:	100% L/C at Sight or 30% T/T in Advance
Product Capacity:	98%
Cotton Yarn Range:	8's-50's
.Machine Working Width:	190cm, 230cm, 280cm, 340cm
Warp Beam Flange Diameter:	800mm
After-Sales Service Provided:	Engineers Can Service Machinery Overseas
Model:	Jlh910
Type:	Air Jet Loom
Certification:	ISO9001: 2000
Condition:	New

Our company

We are manufacturer and exporter of Textile weaving machine since 1973.

Main product: Air jet loom, air jet gauze loom, water jet loom, fiberglass weaving air jet loom

We are not only selling machine, but also technique service and guide.

For new client in textile weaving industrial or medical gauze production line, we can supply full support from factory

Building, machine installation, worker trial and sales service in abroad.

Now our machine has exported to

Uzbekistan, Russia, Turkey, India, Pakistan, Sri Lanka, Bangladesh, Indonesia, Tailand, Ethopia, South Africa, South Korea,

Kazakhstan, Uganda, (Asia, Europe, Africa)

Our product

Model JLH9200 air jet loom(ZAX9100)

For high quality cloth fabric, home textile, denim

JLH910air jet loom(ZAX-N)

For normal cloth fabric, home textile, rayon fabric

JLH425S air jet loom

For medical gauze, mother & baby product fabric

JLH740air jet loom with built-in pump

For medical gauze fabric only

JLH425B air jet loom

For special for glassfiber fabric

JLH8200 water jet loom

For heavy fabric for special function

JLH851 water jet loom

For normal polyster fabric

Our relative Product and Service

1. Medical gauze production line(yarn-grey gauze-bleached gauze- gauze dressing)

All equipment and technical support.

2. Cloth weaving production line(sizing-warping-weaving-other relative)

All equipment and technical support

Why Choose Us?

A. A strong team for sales and service, A strong team for technique, A strong company for production.

B. Become a professional manufacturer, a reliable and believable suppliers for client from domestic and abroad.

C. Client is not God, they are our family memeber.

D. Delivery on time, safely and quickly transport the goods to customer's factory.

E. Every accessories are packed and completed. Not allowed any short spare parts

F. For long cooperation, we always work for whole market, not one or two customer.
