Price: | US $ 3700-3800/Set |
---|---|
Min Order: | 1/Set |
Pay Type: | L/C,T/T,Western Union |
1) Specially for cutting 1600*1000mm, thickness 0.1-20MM nonmetal(depend on meterials), Easy adjustable!
2) Special focus system easy adjust the focus length, inside with American Focus lens.
3) 80,100,150W RECI laser tube, easy cutting and maintaince.
4) Precise and Stable runing---Janpan PANASONIC servo motor and driver, Ball screw rail transmission
5) Human friendly software, English version operations, support multiple file formats supporting
Applicable materials:
MDF, Acrylic,cloth,leather,wood etc.
Applicable industry:
It is widely use inGarment,leather,craft, packing, advertising signs,etc.
Technical index:
Model | GY-1610s | |||||
Laser Power | 80,100,120,150w, | |||||
Gas of Laser | Co2 | |||||
Working Area | 1600*1000mm | |||||
Positioning Accuracy | 0.01mm | |||||
Cutting Accuracy | 0.03mm | |||||
Transmitting system | 3 axis Ball screw rail PANASONIC servo | |||||
Cutting Thickness | 3MM 6MM | |||||
Support Software | AUTOCAD, CORELDRAW | |||||
Support Format | PLT, DXF, DSF, AI | |||||
Machine Voltage | 220V±10% 50HZ, Gross Power: 10KW | |||||
Working Temperature | 0ºC-45ºC (No Condensation) | |||||
Working Humidity | 5-95% | |||||
Cooling way of Laser | Water Cooling | |||||
Machine Weight 215Kg | 320Kg | |||||
Demension | Machine: 2160*1450*1080mm | |||||
water chiller: 70*55*90cm |
Prod Model: | GY-1610S |
---|---|
Model: | Gy-1610s |
Working Area: | 1600mm*1000mm |
Positioning Accuracy: | 0.01mm |
Cutting Accuracy: | 0.03mm |
Cutting Thickness: | 6mm 8mm |
Machine Voltage: | 220V,50Hz |
Machine Dimension: | 2160mm*1450mm*1080mm |
Machine Weight: | 400kg |
Cooling Type: | Water Cooling |
