Product description reference:
| Model | Yarn Dia.(mm) | density (pcs/cm) | Air Permeability | Mesh Count |
| warp | weft | warp | weft |
| TYC70904 | 0.7 | 0.9 | 12.6 | 5.8 | 2820 | 32 |
| TYC70903 | 0.7 | 0.9 | 16 | 4 | 2350 | 41 |
| TYC50908 | 0.5 | 0.9 | 25 | 7 | 1635 | 64 |
| TYC50705 | 0.5 | 0.7 | 28 | 8 | 1200 | 69 |
| TYC35505 | 0.35 | 0.5 | 42 | 12 | 680 | 105 |
| TYC10525 | 0.9 | 1.05 | 12 | 4 | 3610 | 30 |
| TYC1008 | 0.8 | 0.9 | 5.9 | 1.6 | 3050 |
|
| TYC1009 | 0.9 | 1.2 | 5.1 | 1.4 | 3620 |
|
| TYC1010 | 1 | 1.2 | 4.7 | 1.3 | 4800 |
|
1. Advantages:
High quality
Excellent filtration function
Good stripping, high stability, not easy deformation
Smooth surface
Clogging protection and durable
2 .Application:
Sludge dehydration
Juice squeeze
Paper pulp
Mine tailings disposal
Belt filter cloth mainly matching with belt type filter press, vacuum rubber belt filter and hirizontal vacuum belt filter.
3 Why choose us?
Computerized weaving process
1 Annual maximal weaving capacity:from 250 000 up to 500 000 m.
2 Heavy looms from 4 up to 13 m wide.
Controlled thermostabilisation process
1 Capacity: width (10 m) - length (160 m)
2 Process whole trace ability
Neat fishing
1 Final cut accurately matching the width required.
2.Belts seams: clipper (hooks) - loop - weaved
3 Glued edges
4 Guiding profiles
Laboratory test
1 Air permeability measurement
2 Mechanical resistance measurement.
3 Electron microscope
