| Price: | US $ 25-65/Piece |
|---|---|
| Min Order: | 10/Piece |
| Pay Type: | L/C,T/T,D/P,Western Union |
| Prod Model: | Light Curtain |
|---|---|
| Delivery Time: | 15 Working Days |
| Open: | Opening |
| Glass Curtain Wall Kind: | Full Glass Curtain Wall |
| Frame Curtain Wall Kind: | Mixed Frame |
| Number Of Layers: | Single |
| Type: | Light Curtain |
| Material: | Safety Machine |
| Supporting Construction: | Light Curtain |
| Shape: | Long |
| Usage: | Elevator Parts |
| Technical Features | ||||||||
| Number of infra Red Diodes | 17 Diode sets | 32 Diode sets | 17 Diode sets | 20 Diode sets | 32 Diode sets | 36 Diode sets | 40 Diode sets | 48 Diode sets |
| Response Time | 45ms relay output | 61ms relay output | 45ms relay output | 48ms relay output | 61ms relay output | 65ms relay output | 69ms relay output | 77ms relay output |
| 21ms transistor output | 37ms transistor output | 21ms transistor output | 24ms transistor output | 37ms transistor output | 41ms transistor output | 45ms transistor output | 53ms transistor output | |
| Scanning Beams | 94-33 Beams | 154-94 Beams | 94-33 Beams | 128-58 Beams | 154-94 Beams | 174-106 Beams | 194-118 Beams | 234-142 Beams |
| Infrared Diodes Range | 117.5mm | 58.8mm | 117.5mm | 84mm | 58.8mm | 47.5mm | 47.5mm | 40mm |
| Detecting Height | 20-1841mm | 20-1615mm | 20-1841mm | 20-1678mm | 20-1868mm | 20-1990mm | ||
| Redundancy (One transmitter shidlded after 120s detected absent) | ○ | ○ | ○ | |||||
| Tolerance | Up/down:±15mm/7° Back/forth:±3mm/5° | |||||||
| Detecting Range | 0-4m | |||||||
| Operating Temperature | -20ºC-+65ºC | |||||||
| Reliabitlity | ||||||||
| Light Immnity | 100000Lux. | Sunlignt proof | ||||||
| Protection Level | See product catalog | |||||||
| Vibration | Vibration 20 to 500Hz 4hrs per X-Y-Z axis,sinusoidal vibration 30Hz ms 30mins per X-Y-Z axis | |||||||
| Enbironment Test (hing & low temperature) | GB/T2423.1-GB/T2423.4 | |||||||
