JR306-SC-OW
The Vandal Resist Emergency Telephone is based on a stainless steel faceplate and provide a clear handsfree, loud-speaking operation for any public area. It is designed to meet the needs of clients who experience loss through vandalism.
Ideal for schools, streets, public square, court houses, rail platforms, car-parks, police stations, hospitals, outside buildings, gate entry, etc.
Industrial Flush Mounted Telephone is designed for voice communication in the hostile environment where reliability, efficiency and safety are of prime importance.
Electret noise reducing microphone for clear communication~
Service temperature range from -40° to +140°F ( -40° to +60°C )~
Waterproof connections & stainless steel fittings for longer life~
Compact durable enclosure with mounting plate for easy mounting~
Modular parts for easy service~
Hearing aid compatible~
Bell ringer~
Vandal Resistant enclosure for high visibility. Optional Grey enclosure~
Weather, dust & corrosion resistant~
Tone or pulse dialing for universal configuration~
Easily connected to any single line analog CO or PABX telephone line~
corrosion protected steel faceplate~
Front access plate for ease of hook-up
Key Features:
Suitable for indoor & outdoor application
Designed to flush mount or surface mount into flat surface
The phone has stainless steel faceplate, Material: Metal SS 304,
thickness 2 mm.
The telephone electronics is on the rear of the faceplate and is
covered with back box in CRCA for protection
The phone operates on standard analog phone line
It is Line powered i.e. power drawn from telephone line. It doesn't require battery or any external power source.handsfree operation
Built in Ringer, in front panel.
Sealed, push button for smoother and faster dialing of
numbers.
Metallic Push button in SS 304 material.
Dialing system: Tone dialing (DTMF)
Hook Switch: Non -movable, Magnetically operated hook switch
Handset with Noise canceling microphone for effective communication from noisy areas
Handset cord: Stainless Steel spiral cord
No mechanical or moving parts.
Visual LED indicator: High Intensity, flashing,Red color LED, during incoming call and High Intensity,continuous, Green color LED, during use mode
Compatible for interconnection with external ringer, flasher, hooter etc. through additional hardware
Compatibility: Fully compatible with all PBX's
Cabling: Single Pair Telephone Cable
| Operating: | -30°C to +65°C |
| Storing: | -40°C to +75°C |
| Ringing Tone | Shrill warble tone 80 dBA @ 1 metre typical |
| M.T.B.F. | Calculated to have an M.T.B.F. in excess of 50,000 hours using |
| Lightning / Transients | Protection to ITU-T k.21 enhanced levels |
FEATURES
Standard Analogue phone
Robust housing, constructed of stainless steel
Vandal resistant metal keypad with standard 12 keys
Hands free operation
Can be programmed remotely by tone phone
Non-volatile memory
On wall mounting, simple installation
Weather protection IP54-IP65
4 X Tamper proof screws for mounting
Fast-fit terminal connection
Telephone line powered
CE, FCC compliant
TECHNICAL SPECIFICATIONS
Lightning / Transients
Protection to ITU-T k.21 enhanced levels
PACKAGE
Unit size: 150*200*52(mm)
Packaging materials: pearl cotton, carton
Net weight: 1.5KG
