Ep100 Ep150 Ep200 Fabric for Tire Sheets and Conveyor Belts
Price: |
Negotiable/Ton |
Min Order: |
10/Ton |
Pay Type: |
L/C,T/T |
EP FabricThe EP Fabric is woven by HMLS polyester yarns in warp and Nylon6.6 yarns in weft. It is suitable for transportation of middle and long distance; heavy load under a high speed. EP fabric is mainly used for conveyor belt ,and it's characteristic as below: 1.High tensile strength 2.Pretty shock resistance3.Low elongation4.Good adhesion5.Low unit weight 6. Good heat resistant7.It can be adjusted by customers' requirementNo. | spec item | unit | EP-80 | EP-100 | EP-125 | EP-150 | EP-200 | EP-250 | EP-300 | EP-350 | EP-400 |
warp | weft | warp | weft | warp | weft | warp | weft | warp | weft | warp | weft | warp | weft | warp | weft | warp | weft |
1 | Frame | dtex | 1100X1 | 930X1 | 1100X1 | 930X1 | 1670X1 | 1400X1 | 1100X2 | 1870X1 | 1100X2 | 1400X2 | 1100X4 | 1870X2 | 1100 X4 | 1870 X2 | 1870 X3 | 1870 X2 | 1870X4 | 1870X2 |
2 | Density | end/10cm | 155 ±2 | 76 ±2 | 194 ±2 | 86 ±2 | 170 ±2 | 72 ±2 | 166 ±2 | 56 ±2 | 186 ±2 | 44 ±2 | 120 ±2 | 38 ±2 | 146 ±2 | 38 ±2 | 150 ±2 | 38 ±2 | 125 ±2 | 38 ±2 |
3 | Average breaking strength≥ | N/mm | 100 | 50 | 137 | 55 | 165 | 70 | 206 | 75 | 246 | 85 | 330 | 105 | 350 | 105 | 400 | 105 | 465 | 105 |
Breaking strength(min)≥ | 95 | 45 | 118 | 50 | 145 | 60 | 176 | 68 | 220 | 75 | 290 | 95 | 320 | 95 | 370 | 95 | 425 | 95 |
4 | Elongation at 10% load≤ | % | 1.5 | | 15 | | 1.5 | | 1.5 | | 1.5 | | 1.5 | | 1.5 | | 1.5 | | 1.5 | |
5 | Elongation at break | % | ≥14 | | ≥14 | ≤45 | ≥14 | ≤45 | ≥14 | ≤45 | | ≤45 | ≥15 | ≤45 | ≥15 | ≤45 | ≥15 | ≤45 | ≥15 | ≤45 |
6 | Drying shrinkage%≤(150ºC*30min) | % | 5.0 | 0.5 | 5.0 | 0.5 | 5.0 | 0.5 | 5.0 | 0.5 | 5.0 | 0.5 | 5.0 | 0.5 | 5.0 | 0.5 | 5.0 | 0.5 | 6.0 | 0.5 |
7 | Uneven drying shrinkage≤ | % | 10 | 10 | 10 | 10 | 10 | 10 | 10 | 10 | 10 |
8 | Adhesion strength≥ | N/mm | 7.8 | 7.8 | 7.8 | 7.8 | 7.8 | 7.8 | 7.8 | 7.8 | 7.8 |
9 | Weight (grams per m2) | g/m2 | 300±10 | 340±15 | 425±20 | 530±20 | 615±20 | 780±30 | 860±30 | 1000±35 | 1040±40 |
10 | Thickness | mm | 0.55±0.05 | 0.55±0.05 | 0.60±0.05 | 0.70±0.05 | 0.80±0.05 | 1.07±0.10 | 1.20±0.10 | 1.26±0.10 | 1.40±0.10 |
11 | Width | mm | 800~1400 | 800~1500 | 800~1500 | 800~1550 | 800~1600 | 800~1600 | 800~1600 | 800~1600 | 800~1600 |
12 | Length | m/roll | 800±10 | 800±10 | 800±10 | 800±10 | 800±10 | 800±10 | 800±10 | 800±10 | 800±10 |
Why choose us? 1.A professional international sales team, which is specialized in the framework materials for 16 years.2.Well and high-quality control3. Strong production capacity and testing capabilities4.Various designs are available5.Prompt delivery6.FREE SAMPLE can be offered7.The products are sold to all larger tyre manufacturer in China and export to many counties and regions in Europe,South America, Africa ,Middle east, South and east Asia and so on,and enjoy a good reputation. What 's the capacity?The Group has production capacity of Canvas Fabric 30,000 tons/year, Steel Cord 100,000 tons/year, Bead Wire 60,000 tons/yearTyre Cord Fabrics 40,000 Tons / year, Tyre Liner Fabric 5 million meters/year ,Film 20,000/year. Shipping Details:1.International standard export packing in packages or according to t o
customer's requirement.2.Loading port: Qingdao ,Shanghaior according to customer's requirement3. Delivery Time: 2 -5 days for samples 15-20 days for 1-4 20fcl containers 20-30 days for 3-6 20fcl containers 4.Payment Terms: Payment: 30% deposit, 70% by T/T against B/L copy or by L/C.
Prod Model: |
EP80-EP600 |
Certificate: |
ISO9001 |
Feature: |
Flame Retardant |
Size: |
Ep80-Ep600,Nn80-600,Ee80-600 |
Reply: |
Within 24 Hours |
Pattern: |
Plain |
Material: |
Polyester in Warp and Nylon in Weft |
Applications: |
Transmission Belt, Conveyor Belt |
Type: |
Canvas Fabric |
Style: |
Dipped |
Width: |
Make- to-Order |
Gram Weight: |
300-1040G/M2 |
Qingdao Entron International Trade Co., Ltd, belonging to the subsidiary of HL Group Ltd, is the manufacturer and exporter of work glove, filter cloth, tyre cord fabric, bead wire, steel cord and conveyor belt.
The company has been professionals in the products for 16 years, and they are approved and exported to more than 10 industrial nations such as Germany, Turkey, Poland, Portugal, Czech Republic, Russia, South Africa, Pakistan, India, Indonesia and others. During many years of market activity,
The goods are delivered to our customers according to their requirements and in appointed time. Quality and satisfied customers have always been most important for the company.
Why choose us?
1. A professional international sales team, which is specialized in the products for 16 years.
2. Well and high-quality control
3. Strong production capacity and testing capabilities
4. Various designs are available
5. Prompt delivery
6. FREE SAMPLE can be offered
7. The products are sold to all larger tyre manufacturer in China and export to many counties and regions in Europe, South America, Africa, Middle East, South and east Asia and so on, and enjoy a good reputation.
What 's the capacity?
The Group has production capacity of Canvas Fabric 30, 000 tons/year, Steel Cord 100, 000 tons/year, Bead Wire 60, 000 tons/year, Tyre Cord Fabrics 40, 000 Tons / year, Filter cloth 3, 500, 000 square metters/year, Tyre Liner Fabric 5 million meters/year, Film 20, 000/year. Work Glove 4, 000, 000 dozens / year
Shipping Details:
1. International standard export packing in packages or according to to customer's requirement.
Loading port: Qingdao, Shanghaior according to customer's requirement
Delivery Time:
2 -5 days for samples
15-20 days for 1-4 20FCL containers
20-30 days for 3-6 20FCL containers
Payment Terms:
Payment: 30% deposit, 70% by T/T against B/L copy or by L/C.
