Price: | US $ 6-6.8/Piece |
---|---|
Min Order: | 5/Piece |
Pay Type: | T/T |
Sheet Thickness: | 0.5,0.5,0.6,0.8ect |
---|---|
Distance Short(mm) Swd: | 2.5,10,10,10ect |
Distance Long(mm) Lwd: | 4.5,25,25,25ect |
Strip(mm): | 0.5,0.5,1.0,1.0ect |
Roll Width(mm): | 0.5,0.6,0.6,0.6ect |
Roll Length(mm): | 1.0,2.0,2.0,2.0ect |
Weight(Kg/M2): | 1.80,0.73,1.00,1.25ect |
Application: | Sieving Diversified Pellet |
Hole Shape: | Diamond |
Usage: | Civil Building |
Weave Characteristic: | Stamping |
Stamping Expanded Metal Mesh Category: | Expanded Metal Mesh |
Hot-galvanize Technique: | Wire Annealing |
Specifications: | Mesh |
Weight: | Middle-weight |
Material: | Low Carbon Steel Plate, Aluminum Plate, Copper |
Surface Treatment: | Galvanized, PVC Coated |
Galvanized Surface Treatment: | Cold Galvanized and Hot-Dipped Galvanized |
Expanded Metal Mesh | ||||||
Sheet | distance | distance | strip(mm) | Roll Width | Roll Length | Weight |
Thickness | short(mm) SWD | long(mm)LWD | mm | mm | kg/m2 | |
0.5 | 2.5 | 4.5 | 0.5 | 0.5 | 1 | 1.8 |
0.5 | 10 | 25 | 0.5 | 0.6 | 2 | 0.73 |
0.6 | 10 | 25 | 1 | 0.6 | 2 | 1 |
0.8 | 10 | 25 | 1 | 0.6 | 2 | 1.25 |
1 | 10 | 25 | 1.1 | 0.6 | 2 | 1.77 |
1 | 15 | 40 | 1.5 | 2 | 4 | 1.85 |
1.2 | 10 | 25 | 1.1 | 2 | 4 | 2.21 |
1.2 | 15 | 40 | 1.5 | 2 | 4 | 2.3 |
1.5 | 15 | 40 | 1.5 | 1.8 | 4 | 2.77 |
1.5 | 23 | 60 | 2.6 | 2 | 3.6 | 2.77 |
2 | 18 | 50 | 2.1 | 2 | 4 | 3.69 |
2 | 22 | 60 | 2.6 | 2 | 4 | 3.69 |
3 | 40 | 80 | 3.8 | 2 | 4 | 5 |
4 | 50 | 100 | 4 | 2 | 2 | 11.15 |
4.5 | 50 | 100 | 5 | 2 | 2.7 | 11.15 |
5 | 50 | 100 | 5 | 1.4 | 2.6 | 12.39 |
6 | 50 | 100 | 6 | 2 | 2.5 | 17.35 |
8 | 50 | 100 | 8 | 2 | 2.1 | 28.26 |
Package:
>Transparent bag inside,woven bag outside per roll.
> Transparent bag insider, paper carton outside per roll.
>Special requires package and brand label will be accepted.
Usage:
Mainly used for civil construction, protect and fence for machines, handicraft article manufacturing. Wire mesh fence for highway, stadium fence or sport field fence, green area fence application. Heavy expanded metal can be used for foot tanker, heavy machinery and boilers, oil mines, locomotives, ships, and other working platforms, escalators, walkways. It can also be used for construction, roads, bridges, steel bars used.
