| Prod Model: |
HD |
| Max.Loading Capacity: |
1000L |
| Voltage: |
220V/380V/Customized |
| Material: |
SS304/SS316 |
| Speed: |
2800r/Min |
| Connection: |
Clamp,Thread,Welded,Flange |
| Motor: |
ABB/Siemens/Customized |
| Flow: |
0-130m3/H |
| Usage: |
Food,Cosmetic,Chemical,Pharmaceutical,Ects |
| Mixer Type: |
Homogenizer |
| Working: |
High Speed Mixer |
| Application: |
Liquid |
| Additional Capabilities: |
Granulating |
Product Description
Thank you for your browsing.Guangzhou Hundom machinery Equipment Co.,Ltd. Which is a professional manufacturer, specialized in all kind of household chemical machinery,food machinery.pharmaceutical machinery,packaging equipment manufactures with good quality and very competitive price in China.We have manufactured the jacketed kettle,colloid mill,stainless steel tank,pump,emulsifier mixer ect.Also we have our own professional designers and factory to meet any of your requirements.Should any of products be of interest to you,please contact us.
Facial Cream Vacuum Homogenizer Emulsifying pump with explosion-proof motor
Structure:
Emulsion pump is a high performance equipment used for continuous production circulated treatment of fine material.
In the small chamber there are 1-3 sets of paired and clutched stators and rotor.
Driven by motor, the rotor revolve quickly and produces a strong axial suction force which intakes the material to the chamber.
The machine disperses, shears and emulsifiers the material in shortest time, and the diameter range of the particles gets smaller so that fine and stable produced.
High shear dispersion emulsifying pump advantages:
1, Large processing capacity,suit industrialized on-line continuous production.
2, Particle size distribution range narrow,high evenness.
3, Saving energy consume,saving time,high efficiency.
4, Low noise,stable operation.
5, Dispel of batch production quality difference.
6, No deal angle,material 100 percent through disperse shear.
7, Having short distance,low head convey function.
8, Using simple,convenient repair.
9, Can realize automatic control.
Notes:
*Flow listed on the table refers to the datas measured when the medium is water, the exit pressure≤0.2Mpa of the model listed in the table.
*If have high temperature, high pressure, flammability, explosion and erosion, relevant parameters must be provided clearly for selecting customization precisely.
*For poor liquid medium, a pump which has a matching flow is suggested to feed at the inlet, input pressure≤0.2Mpa.
*If the data in the table is modified, no further notification will be given, and the right parameters as per the provided sample.
Main technical parameter:
| Model | Power(kw) | Speed(RPM) | Capacity (L/H) |
| HD1-60 | 1.5 | 2800 | 0-1.5 |
| HD1-100 | 2.2 | 2800 | 0-3 |
| HD1-130 | 4 | 2800 | 0-4 |
| HD1-140 | 5.5 | 2800 | 0-5 |
| HD1-165 | 7.5 | 2800 | 0-8 |
| HD1-180 | 11 | 2800 | 0-12 |
| HD1-185 | 15 | 2800 | 0-18 |
| HD1-200 | 22 | 2800 | 0-25 |
| HD1-210 | 30 | 2800 | 0-35 |
| HD1-230 | 45 | 2800 | 0-50 |
| HD1-245 | 55 | 2800 | 0-75 |
| HD1-260 | 75 | 2800 | 0-90 |
| HD1-275 | 90 | 2800 | 0-110 |
| HD1-280 | 132 | 2800 | 0-130 |
