Heat Resistant Ptfe ( Teflon ) Sewing Thread
The Description of Heat Resistant Ptfe Sewing Thread
PTFE sewing thread is a high quality sewing thread for high temperature resistant filtration bag, The thread may be made into special reinforced type according to the requirement.
Sewing thread: 1400dtex(1200~1300den); Breaking strength>33N; Elongation: 5%, Con-tinuous length>3000M
Application: Sewing the body of filter bag for PTFE, Nomex, PPS, P84, Fluoro-US silk and Acrylicfiber.
Sewing the enhanted filter bag, or strengthening sewing the opening and the bottom of the bag.
100% PTFE Sewing Thread for Industrial Filter Bag Sewing Machine
The Description of PTFE Sewing Thread
Thanks to its excellent stability,non-aging,strength does not decay,it is a bag of "loyal partner" in the filter area. The PTFE sewing thread the first choose for its uniqe characteristics in the performance of heat resistance, abrasion resistance, acid resistance and also the working life. The PTFE sewing thread has a max heat resistance of 260 degree, which mean it can hold 10 minutes at 260 degree and other material can't. And the Ptfe sewing thread has a great strength, it won't change the shape and also its capacity when time goes. Compared to the Nomex, polyester, fiberglass sewing thread, it is more expensive, still we all like it.
With the characteristic of good chemic stability of PTFE, it is widely used in the fiber materials under high temperature, strong acids and strong base condition.
PTFE fiber can be classified into White Staple Fiber and Brown Staple Fiber. Brown fiber is produced from carried-added emulsion treated with pressure and extrusion, followed by removal of carriers under high sintering, there are still several residues of carbonized carriers adhered to the fiber surface, which makes the fiber brown in color.
PTFE Sewing Thread is made of PTFE Filament Fiber.
100% PTFE is mainly used to produce heat resistance PTFE filter bag.
Technical Information of Ptfe ( Teflon ) Sewing Thread
| Spec. | PTFE13 | PT29 | PT36 | PT48 | PT56 | PT59 |
| Density | 1250±90den | 1600±120den | 1900±150den | 2600±90den | 1250±90den | 1600±90den |
| Break Force | ≥33N | ≥45N | ≥50N | ≥60N | ≥43N | ≥55N |
| Eltension at break | 6% | 6% | 6% | 6% | 6% | 6% |
| Titre | 480t/M | 480t/M | 480t/M | 480t/M | 480t/M | 480t/M |
| Heat resistance | -190~+260ºC | -190~+260ºC | -190~+260ºC | -190~+260ºC | -190~+260ºC | -190~+260ºC |
| Shrinkage | <2% | <2% | <2% | <2% | <2% | <2% |
| Length per kg | 7200M | 5600M | 4800M | 3400M | 7200M | 5600M |
| Plied Yarn | 3 | 4 | 5 | 6 | 3 | 4 |
The Features of PTFE( Teflon ) Sewing Thread:
1. Anti UV and none-aging
2. Excellent chemical stability, no corrosion
3. High tensile strength
4. Very low shrinkage
5. Excellent abrasion resistance
6. Suitable for high temperature environments up to 260 degree centigrade
7, Excellent chemical stability, no corrosion.
8, High tensile strength.
9, Very low shrinkage.
10, Excellent abrasion resistance.
Application of Ptfe (Teflon) Sewing Thread
PTFE sewing thread for dust bag sewing thread sewing of high temperature resistant, can make Nomex, PPS, PTFE dust bags, It is characterized by high strength, high temperature resistance, corrosion
resistance, suitable for sewing bag automatic sewing production line, high production efficiency.
100% Ptfe( Teflon ) Sewing Thread Specification:
| No. | SFF10T1 | SFF12T1 | SFF15T3 |
| Material | 100%PTFE | 100%PTFE | 100%PTFE |
| Density | 1000D | 1200D | 1500D |
| Tensile | 3.8kg | 4.56kg | 5.7kg |
| Strength on Normal temperature | >4g/D | >4g/D | >4g/D |
| Strength on high temperature | >1.3g/D | >1.3g/D | >1.3g/D |
| Working temperature | -200-286 | -200-286 | -200-286 |
| Shrinkage | ≤3% | ≤3% | ≤3% |
| Color | white | white | white |
| Meter/Kg | ≈9100 | ≈7580 | ≈6050 |
Ptfe ( Teflon ) Sewing Thread Size and Delivery
| • Material | 100% PTFE Filament |
| • Production Process | Ring Yarn & TFO (Two For One) |
| • Quality | Extra Lubrication, Non-Knot & High-Resistance |
| • Color | raw white |
| • Size | 20/2, 20/3, 20/6, 30/2, 30/3, 40/2, 40/3, 50/2, 50/3, 60/2 & 60/3 |
| • Production capacity | 1000pc/day |
| • Packing | 12pcs/Inner Box, 20Box/Carton |
| • MOQ | 200pcs |
| • Payment Term | T/T, D/P, L/C At Sight, |
| • Price Term | FOB, CIF |
| • FOB port | Ningbo, Shanghai |
