Gloss: |
High/Low/Matt |
Curing: |
180-200 Degree/6-15minutes |
Usage: |
Powder Coating |
Appearance: |
Powder |
Method: |
Spray |
Level: |
Finish Coat |
Certification: |
ISO9001 |
Substrate: |
Aluminum |
Formation Mechanism: |
Conversion Type |
Color: |
Ral & Pantong Color |
Components: |
Epoxy Polyester |
Main Raw Material: |
Epoxy Polyester |
Expiration Date: |
10 Month |
Packing: |
Plastic Bags Plus Cardboard Boxes |
Product Description
----------------------------------------------------------------------------------------------------------------------
Dear Sir/madam,
Glad to know you have a large demand of powder coating!
As being the LONG-STANDING SUPPLIER of Hitachi Metals ( Chengdu), we produce
high-quality powder coating since 2008, with competitive price.
a) ROHS2.0/SGS/9001/9000/MSDS.
b) Powder coating made with DSM resins, Pigment, higher resin content ( >62% ) .
c) More than special 26 new product annually, as well as 10,00 available effect.
d) Antibacterial, Skin effect, Transparent, Luminous, Ultra thin coating.
Contact Alina to get E-catalog and FOC samples!
Thank you :D
----------------------------------------------------------------------------------------------------------------------
1 Description:
Metallic gold epoxy polyester hybrid powder coating
Product Details | | |
Type | Epoxy Powder Coating; Polyester Powder Coating; Epoxy-Polyester Powder Coating | |
Color | RAL and PANTONE or customized | |
Surface Finish | RAL | |
Gloss level | High Gloss | |
Particle Size | Average 32-42μm | |
Specific Gravity | 1.2-1.7g per cubic meter | |
Coverage | 8-10 square meters per Kg at 30-90 μm film thickness | |
film thickness | Not less than 100μm | |
Application Recommendation | | |
Application Voltage | 60-90 KV | |
Gun to Component Distance | 15-30CM | |
Curing Temperature | 180-200ºC,10 min-15 min | |
Powder coated Film Mechanical Properties | | |
Adhesion | Cross-cut(2mm),no loss of adhesion | |
Impact Resistance | Direct impact 50kg/cm | |
Pencil Hardness | 1H-2H | |
Cupping Test | 6mm Mandrel | |
Bending Test | 5mm | |
Powder Coated Film Chemical Resistance | | | |
Salt Spray Test | 5% NaCl Solution for 500 hours - No change | | |
Acid Resistance | 5% HCL for 48 hours dip test - No change | | |
Alkali Resistance | 5% NaOH for 48 hours dip test - No change | | |
Storage Stability | |
Store in ventilated, dry, clean room, temperature < 25ºC | |
Relative humidity 50-65% | |
Away from direct sunlight, fire, heat | |
For best performance, use within 6 months | |
-------------------------------------------------------------------------------------------------------------------------------
2 Testing items
Testing items | Standards | Methods | Test index |
Iimpact strength | ISO 6272 | GB1732-1993 | 40cm |
Bending resistance | ISO 1519 | GB/T6742-1986 | 3mm |
Adhesion | ISO 2409 | GB/T9286-1998 | Grade 0 |
Cupping test | ISO 1520 | GB/T9753-1988 | 5mm |
Pencil hardness | ASTM D3363 | GB/T6739-1996 | H-2H |
Salt spray test | ISO 7253 | GB/T1771-1991 | More than500 hours |
H&humidity test | ISO 6270 | GB/T17740-1979 | More than1000 hours |
Weatherability | ASTM G151 | GB/T1865-1997 | 240(QUV B313) |
------------------------------------------------------------------------------------------------------------------------
3 Packing
Basic package | 2Plastic bags+Strong kraft carton |
Custom package(if customer equired) | Plastic bags+Stong kraft carton3 pallet |
Carton Size | 40cm27cm45cm 0.0375CBM NW 20KG GW 21KG |
Pallent package size | 213 120 120 cm |
-------------------------------------------------------------------------------------------------------------------------
4 Delivery
Delivery | |
BY courier | Like DHL,UPS ect,it is door to door,usually 5-8days |
BY air | Usually 3-4 daysto arrive |
BY sea | Usually 15-20 days to arrive |
------------------------------------------------------------------------------------------------------------------------
5.Why choose our products?
1). We have our own factory. The good quality and the competitive is the advantage of our company.
2). The material we choose is always good and products always come out with high quality.
3). A trial order or sample orders are welcomed.
4). Our products are exported to Europe, America, Southeast Asia, and other countries and regions in the world.
5). We will do our best to service you all the time if you have the further question.
----------------------------------------------------------------------------------------------
6 contact:
Alina Ren :D
---------------------------------------------------------------------------------------------
HSINDA
Colouring the future!
---------------------------------------------------------------------------------------------
Chengdu Eastern Union High-Tech New Materials Co., Ltd. An associated factory, with more than 20% of managements & technical experts abroad and superior European chemical technology, our factory quickly grow up to be the Europe's reliable powder coating supplier. Reaching annual output more than 3000 tons/year, which can make sure customers' request could be reached always.
We are ISO Certificate factory especially for produce powder coating with ISO TUV SGS certifacated.
Partner of Wal-mart, IKEA, HITACHI, Wecome Group, Changhong, BASF, Clariant, CYTEC, BAYER, Sinopec, etc.
1. Our main production series:
Epoxy powder coating, polyester powder coating, epoxy polyester powder coating etc.
2. Popular texture series:
Smooth(high gloss, semi-gloss, matt ), Sandy, Wrinkle, Hammer, Metallic, wooden effect. etc.
3. Color series: RAL & Pantone, customised also acceptable.
With our concept of "Quality first, Credit first, Service first", as well as our reasonable price, we got good reputation from our clients. Our principle is "Work with the truth, Go with the time", and our target is to satisfy our clients with superior products & services.
