| Price: | US $ 200-3800/Piece |
|---|---|
| Min Order: | 1/Piece |
| Pay Type: | T/T,Western Union,Money Gram |
| Prod Model: | HO1501 |
|---|---|
| Name 1: | Speed Single Head Computerized Embroidery Machine |
| Name 2: | Multi-Function Cap T-Shirt Flat Embroidery Machine |
| Embroidery Function: | 3D Cap T-Shirt Flat Bag Towel Uniform Embroidery |
| Rotary Hook: | Japanese Koban Rotary Hook |
| Operation: | Computerized Operation |
| Control System: | Dahao Control System |
| Main Motor: | Servo Motor |
| Language: | 12 Languages |
| Power Support: | 110V/60Hz or 220V/50Hz |
| Trimming System: | Automatic Trimming System |
*Suitable for caps/flat /3D/towel/leather/ logo/ finished garment like T-shirt, uniform embroidery, multi function
*Easy handling, easy installing, easy maintenance;
*Take less room, easy to move (equipped universal wheel);
*Equipped with Dahao color display showing real time stitching;
*Pre-sew design trace capable;
*Automatic trimmer, automatic color change;
*Automatic thread break detection (both bobbin and upper threads)
*High speed of up to 1200 spm*cap embroidery frame rotation range of up to 270 degrees;
*Have a certain scale production capacity;
| Model | HO1501C | Name | Speed Single Head Computerized Embroidery Machine |
| Head | Single Head | Color | 15 Colors |
| Computer | Dahao syetem full color touch screen computer | Function | Cap,T-shirt, Finished garments, etc |
Embroider area | 510*360 mm | Max. Speed | 1200 spm |
Cap frame | 270 degree wide | Power supply | 110V/60Hz or 220V/50Hz |
Momery Size | 20,000,000 stitches | Language | 12 Languages |
| Auto color change | YES | Thread breaking detection | YES |
| USB input port | YES | Auto thread trimmer | YES |
| Emergency stop | YES | Built-in bobbin winder | YES |
| Computerized | YES | Pre-sew design trace capable | YES |
For more machine video details,
Please freely contact me on 008618820987339
****************************************************************************************************
High Speed Single Head Computerized Embroidery Machine for Multi Embroidery Functions Cap T-shirt Flat Embroidery
Main Features for the embroidery machine
1.Single head 15 needles embroidery machine with 510*360 mm
2.Automatic thread trimmer
3.Maximum speed 1200 SPM
4.270° Wide cap frame unit
5.8" newest touch screen display showing real time stitching
6.USB input port
7.Automatic color change
8.Thread break detection
9.Pre-sew design trace capable
10.Memory size 20, 000, 000 stitches
11.Emergency stop
12.Electricity:110V/60Hz or 220V/50Hz available
14.Low power consumption 100W to 150W
15.Built-in bobbin winder
Newest 8" Dahao Computerized Control System
A.8" touch screen showing real time stitching
B.Manual, Semi-auto, Auto Color Change
C.Function keys including Menu, Speed up and slow
D.Multi languages available like English, French, Spanish etc.
E.Frame-moving keys, Manual Trimming
F .DOT ket to return to 100 degree
G.Start, Stop, and emergency Stop
H.Embroidery Status (Page Up/Page Down), USB Input,
I.Parameter Settings, Clear, ESC, Enter, etc
Hoops for the embroidery machine
A.2 X Shirt Front Round Hoop 9 cm (3.5")
B.2 X Shirt Front Round Hoop 23 cm (9")
C.2 X Shirt Front Round Hoop 12 cm (4.7")
D.2 X Jacket Back Square Hoop 30 X 30 cm (12" X 12")
E.1 X Round Hoop 510*360 mm
Cap device for the embroidery machine
1 cap driver, 1 cap hoop station, 2 Cap hoops
Option embroidery device:
*Shoes device *Cordinf device *Sequin device
Other accessaries for the embroidery machine
Table stander with wheels, Extended Table Top, Operation Manual, Tool Kit,8GB USB driver,Bobbin Winder
High Speed Single Head Computerized Embroidery Machine for Multi Embroidery Functions Cap T-shirt Flat Embroidery
High Speed Single Head Computerized Embroidery Machine for Multi Embroidery Functions Cap T-shirt Flat Embroidery
Packing for the embroidery machine : Standard Wooden Cas
.
1 We provide one year warranty for all our machines,during this period ,if there was any problem about the machine ,we will send the spare parts to you for free and guide u how to solve the problme .If necessary, we will send our engineew to your side for help
2 Our delivery time is within 20 days after we receive the deposit ,if you have more than 2 sets machines or any order which is in hurry ,pls feel free to contact me ,then we can prepare for you ASAP.
3. Our Technicist will trainning you after you recived the machine,and we have service department 24 hours for solving your problem in any time. Customer's satifaction is our ultimate goal.We gained the good reputation from all clients.
.
Our advantage
1.Considerate pre-sale service ,patient answer ,offer details of machine and shipping information .
2.High quality ,import parts from janpan
3.Quickly ship,when machine is in stock ,delivery 20 days .
4.Comfortable price ,sincere partner .
5.More than 12 months warranty, flexile after-sale service .
High Speed Single Head Computerized Embroidery Machine for Multi Embroidery Functions Cap T-shirt Flat Embroidery
Further details picture video online checking
please freely contact us : 0086 188 2098 7339
