Prod Model: |
LDSQ100-A |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Machine Type: |
Industrial Washer |
Fuel: |
Steam Heating |
Clean Type: |
Immersion / Soak |
Cleaning Process: |
Solvent Cleaning |
Certification: |
ISO |
Product Description
LDSQ100-A transport type carpet cleans machine
LDSQ100-A Transport Type Carpet Washing Machine have washing, dewatering and drying function. It is the multi-unit connection machine, and the carpet enter inside the machine continuously, after washing, extracting and drying processing, then the clean carpet come out of the machine by rolls. It was researched and designed according to the requirement of railway and airline use. It has filled the new machine of domestic gas. And it has held the authentication and expansion by the province class section and railway department. This machine has the most advanced PLC with man-machine interface touch screen, also together with sewing connecting technology by machine.
This machine has many virtues: Reasonable structure, easy operation, safety, good washing effect, high working efficiency and saving energy. It has solved much difficulty, such as previous long-term great strength labor by hand, and hard to clean up.
It is the best washing machine for carpet used in the gangway of railway, airline and hotel and so on.
Overall Size | 12.6m*3.5m*3.7m |
Total Power | 17.09 KW |
Max. pressure of steam drum | 0.6 Mpa |
Dia of steam drum | φ900mm |
Max. atmospheric pressure of roll | 0.4 Mpa |
Brush linear speed | 34-204m/min (usually: 100-200m/min) |
Speed of rotation by brush roll | 60-360 r/min |
Speed of rotation by roller | 0.8-2.6 r/min |
Carpet running speed | 0.6-1.8 m/min |
Width of Carpet | <1m |
Thickness of carpet | 5-10mm |
Highest temperature of drying drum | 158 degree |
Total weight | 12T |
Water consumption | 2.5T/h |
Electronic Consumption | 17.9kw/h |
Steam Consumption | 250-300kg/h |
Soap powder consumption | 1.5g/meter |
Taizhou Tongjiang Washing Machinery Factory is specializing in producing textile washing machines with various specifications available.
Our main products include industrial washing machine, extracting machine, fully-automatic washer and extractor, drying machine, ironing machine, carpet washing machine and laundry equipment, etc. These products are new in type and low in power consumption. They are widely used in various trades, such as textile, printing, dyeing, silk, garments and chemical industries, hotels, restaurants, hospitals and laundry houses.
Recently, our factory successfully developed a chlorine washing machine and a foam washing machine which filled up domestic blank. They can replace the ones we had always imported from the USA.
Our products have a ready market not only in China but also in Southeast Asia. We ensure superb quality and reasonable price. We take full responsibility of repair, replacement or refund if serious quality problems happen. All our products enjoy life-long service and all the spare parts for them are available.
You are welcome to visit our factory and order our products.
