Features & Applications
Use as tarpaulin, truck cover, awning, tent, inflatable products
Could offer any customer made width from 1.50m to 3.2m
1.50 3.2
Could offer any customer made color
DERFLEX Coated Tarpaulin SpecificationsMaterial: 100% Polyester yarn with PVC CoatingWeight: 300gsm ~ 1500gsm Width: 1200 ~ 51000 mmLength: 10~100mThickness: 0.45mm~1.5mmSize: As per request| Inspection item(Unit) | Normal Value and Allowance | Experimental value | Reference standard |
| Mass per unit(g/m²) | ≥400 | 443 | GB/T4669-2008 |
| Hydrostatic pressing(kPa) | ≥50 | ≥50 | FZ/T01004-2008 |
| Resistance to blocking | Tolerance to mild adhesion | Non-adhesion | FZ/T01063-2008 |
| Resistance to temp.(-25°C×3min) | Non-delamination, non-break | non-break | FZ/T01007-2008 |
Breaking strength
(N/5×20cm) | Longitude | ≥1000 | 1980 | GB/T3923.1-1997 |
| Latitude | ≥1000 | 1480 |
Tear strength
(N) | Longitude | ≥40 | 163 | GB/T3917.3-1997 |
| Latitude | ≥35 | 77 |
| Flame resistance | longitude | Longitude | ≤15 | 0.2 | GB/T5455-1997 |
| Latitude | 0.2 |
| Afterglow time(S) | Longitude | ≤15 | 0.0 |
| Latitude | 0.0 |
| Damaged length(mm) | Longitude | ≤150 | 102 | |
| Latitude | 118 |
| Meltdown cast | Non-tolerance to burn of absorbent cotton or flame resistance | Not give rise to burn of absorbent cotton or smoldering | |
*Above test report is DERFLEX DG1122 based on 650gsm PVC coated Tarps.DERFLEX Tarpaulin Features:1. Laminated technology & Hot-melt Coating & Knife coating technology2. Outstanding tearing strength for welding3. Flame retardant character (optional),B1 ;M1, 4. Temperature resistance: -20--705. Cold Crack Resistance, Anti-Mildew, Anti-Static treatment, Waterproof6. Anti ultraviolet treatment(UV).(optional)7. Acrylic treatment (optional). Application:1. Rain and sunshine shelter, playground,2. Army tent, carriage tent and house building3. Amusement device4. Construction structure5. Truck cover, Top roof and side curtain6. Our door event tent(blockout)Color Available (DERFLEX tarpaulin):We can make any color according to RAL, Pantone, or Sample.
Since Shanghai Der new material co. Ltd was established, it has been engaging on manufacturing, developing as well as selling the materials for digital advertising. It is the professional supplier in advertising field. Our headquarters is located in Shanghai. Our Main Products are PVC Flex ( Frontlit, backlit and blockout flex), Mesh, Adhesive Vinyl (One Way Vision(Perforated Vinyl) and Self-adhesive Vinyl), Textile, Cotton Canvas, PVC Coated Tarpaulin, PVC Foam Board, Photopaper, inkjet coated paper and PP Film series etc. The strict and perfect quality control system ensures high quality of DER products and also achieves the favorite of global customers.
As an experienced manufacture in signage field, Der is equipped with professional R & D center, complete quality control system and senior sales & service personnel. Besides expectation of big quantity export, we pay much more attention to the quality control, esp. ., good quality (smooth, glossy, flat surface, good ink absorblity, good tensile and tear strength, great flexibility ). At the same time, we always develop new products to meet the demands of the world market. The strict and perfect quality control system ensures high quality of DER's products and also achieve the favorite of global customers.
