Price: | US $ 28-30/Roll |
---|---|
Min Order: | 30/Roll |
Pay Type: | L/C,T/T,D/P,Western Union,Paypal |
Featured product | Popular Size | |
Standard PVC Strip Curtain Cold Room PVC Strip Curtain Anti-Insect PVC Strip Curtain Anti-Static PVC Strip Curtain Anti-Ultraviolet PVC Strip Curtain Welding PVC Strip Curtain | 2mm*75mm*50M 2mm*100mm*50M 2mm*200mm*50M 2mm*300mm*50M 2mm*400mm*50M 3mm*200mm*50M 3mm*300mm*50M 3mm*400mm*50M 4mm*400mm*50M | |
Physical Properties | |||
Property | ASTM | Unit | Result |
Light transmittance | ASTM D1003 | % | 85 |
Shore A hardness | EN ISO868 | Sh A | 80 |
Tearing resistance | DIN 53515 | N/mm | 50 |
Tensile stength at break | ASTM D 638 EN ISO 527 | N/mm² | 16 |
Elongation at break | % | 340 | |
Residual elong(after break) | % | 68 | |
Thermal conductivity | ASTM C177 | W/m.k | 0.16 |
Cold bend brittle temp | ISO 8570 | ºC | -35 |
Min. usage temp | EN 1876 | ºC | -15 |
Max. usage temp | EN ISO 306 | ºC | 50 |
Vicat softening temp | ºC | 50 | |
Specific heat capacity | ISO 11357 | kj/kg.k | 1.6 |
Sound reduction | DIN52210 | Db | >35 |
Fire retardance | NF P 92-507 AS/NZS3837 DIN 4102 | classe | Grp4 B2 |
UV/IRfilter | AWS | Filter | |
UV resistance | ISO 4892 | yes | |
Charface buildup | IEC 61087 | Sparks | yes |
Surface resistivity | IEC60093 | 1012 Ω | 40 |
Water absorption | EN ISO 62 | % | .0.2 |
Anti-insect | yes | ||
Density | ASTM D 792 | g/m3 | 1.25 |
Prod Model: | Plain PVC Strip Curtain for factory |
---|---|
Thickness: | 1mm-7mm |
Length: | 50m |
Width: | 200mm-400mm |
Color: | as Require |
Usage Time: | More Than 2 Years |
Location: | Door and Anywhere |
Transmissivity: | 87% |
Tensile Strength: | 19.4MPa/18.7MPa |
Elongation At Brreak: | 617% / 727% |
Foldability At -50c In 1 Hour: | No Flaw |
Material: | PVC |
