1.Features of HongFa Doors Include:
· Certified wind resistant
Resists wind loads up to 110 MPH
· Operates in high winds
Driven by innovative push-pull drive technology
· Rugged and high-performing
Fast open/close speed is built for industrial use
· Seals out bad weather
Full perimeter seal around the door
· Keeps people and equipment safe
Flexible curtain without rigid elements prevents injuries and damages
· Reduces production down-time
Self-reinserting door curtain maintains itself
2.Technical Data
Curtain Color | Blue, Orange,Yellow, Red, Grey, White,Green. |
| Viewing Window | Full transparent 1.5mm PVC window. |
| Power supply | AC 220V - 240V,Single- 3 Phrase, 50HZ |
| Temperature | -37 to 65 Celsius degree |
| Normal Working | -35 to 65 Celsius degree |
| Standard Motor Position | Left or Right |
| Installation Base | Concrete,Panel, Brick,Steel Structure. |
| Installation Space | ≥600mm above the door
≥600mm for motor side
≥200mm for non-motor side
≥800mm in front of the door |
| Using Area | For Production Line |
| Curtain Thickness | 0.8/1.2/1.5mm |
| Opening Frequency | 1000-1500times/Day |
| Operating Frequency | Opening :1.5m/s
Closing:1.2m/s |
3.Material Selection
1)Frame: 2MM thicknesses cold-roll Stainless steel or aluminium alloy
2)Guide track: Heavy-duty galvanized steel.
3)Direct-Drive Motor:
Standard:China Holip
Option: Japan Mitsubishi
4)Control system
Standard:China Sej / Snma
Option:German Sew
5)Command System: Radar Sensor, Magnetic Loop , Remote Control, Push button
6)Curtain: French High Density Industrial Fabric
7)Seal: Seal brush are Installed inside the guides, and the special bottom design
8)Safety Devices: Photocell Sensor(Korea Autonics) emergency stopping reaction when sensing obstacles.
9)Transparent window: 1.2MM thickness transparent PVC window, size and location is Customized
10)Limiting Switch: Mechanical limiting switch, easily and exactly.
11)Emergency STOP : With emergency stop button on control panel, can stop easily by Hand once disconnect or accident
12)Reinforce Girder: The Aluminium alloy Reinforce Girder to increase wind resistant effect.
4. Application Place
· Air Shower
· Garages
· Interior & Exterior Door Openings
· Food Processing Facilities
· Process Areas
· Waste Areas
· Plant Overhead Doors
5.Our Service
1) OEM service for you and your clients .
2) Arrange the shipment for you to everywhere .
3) CE / ISO-9001 / SGS Certification
4) Installation video or instruction for you.
5) Available suggestion about the correct doors.
6) Professional service supporting with different language , email or phone calling .
7) Operating guidance and instruction after installation .
8) Professional / Tirelessly after-sales service .
9) 12 Months warranty for all doors and accessories.
6.F A Q :
1)What's the payment details?
Deposit before production , and balance before shipment .
2)What's the delivery time?
For common order, about 7 days only .
3)What about the warranty for the doors ?
We provide 12 months warranty for all doors and accessories.
4)Do you provide OEM Service?
Yes.OEM & ODM Service is ok for us .
5)What's the MOQ?
We accept 1 set as sample order .
6)How about the package?
Plywood case or Cardboard , suitable for sea freight or air freight , as your request
