Fiberglass Insect Screen Mesh
Introduction
Fiberglass insect screen is made of glass fiber by the means of single filament plastic coating process, plain weaving and thermal finalizing. It is best to keep out a wide range of pests and insects. It is widely used for air exchange and insects proof in high grade office building. It is also used for field, garden, vegetable shed, etc.
Specification
Density | Yarn Diameter | Weight | Quality | Width | Length | Color |
Warp | Weft | (mm) | (g/m2) | (m) | (m) |
18 | 16 | 0.28+2 | 110-125 | Stiff/soft | 0.6-3.0 | 20-2000 | Grey, Black, Brown, Green, White, etc |
18 | 14 | 105-120 |
17 | 16 | 105-120 |
17 | 15 | 100-115 |
Fiberglass&Polyester Pleated mesh:
Fiberglass&Polyester Pleated mesh is made of fiberglass yarn& polyester yarn. The most advantage of this mesh is fire proof, which will be very safe for our house. It's also water proof, easy clean, anti-UV. Now it is very popular in Europe and middle-east market.
Specification:
PRODUCT | FOLD HEIGHT | COMPOSITION | COLOR | YARN DIAMETER | MESH DENSITY | AREA WEIGHT(G/M2) | BREAKING STRENGTH(N/25MM) | STANDARD WIDTH(M) | STANDARD LENGTH(M) |
Fiberglass&Polyester Pleated mesh | 15MM-20MM | Fiberglass Yarn and Polyester Yarn Mixed | Gray, Black, etc | 0.28MM± 0.02MM | 18*16/INCH | 110±5G/M2 | > 25 KGF | 1.0-3.0 | 12.5-30M PER PIECE |
Polyester pleated mesh:
Polyester pleated mesh is a kind of pleated mesh with economical and practical. Its price is more better than PP material. It is also water proof, anti-UV, easy clean. We have more than ten years for this kind of mesh, now we could provide square hole type and hexagonal hole type.
PP Pleated Mesh
Introduction of PP Pleated Mesh:
PP pleated mesh made by polypropylene yarn, it is a green material. The yarn DIA is about 0.18mm to do very well for sunshine and the air into room.
Specification
PRODUCT | FOLD HEIGHT | COMPOSITION | COLOR | YARN DIAMETER | MESH DENSITY | AREA WEIGHT(G/M2) | BREAKING STRENGTH(N/25MM) | STANDARD WIDTH(M) | STANDARD LENGTH(M) |
PP PLEATED MESH | 15MM-20MM | POLYPROPYLENE | GRAY,BLACK,BROWN,GRAY&BLACK | 0.18MM± 0.01MM | 20*20/INCH | 48±2G/M2 | > 25 KGF | 1.2-3.0 | 25-30M PER PIECE |
