Price: | US $ 10-50/Square Meter |
---|---|
Min Order: | 10/Square Meter |
Pay Type: | T/T |
Sun Hong Forming Fabric produced with imported Equipment 14m German Weaving machine. Wide weaving width makes
sure the rate of finished products yields . Austria Automatic seaming machine obtains Average splice point and strong
constructions and Norway 14.5m heatsetting machine.
Feature of Sun Hong Fabric | ||
*Superb dimensional stability. | ||
*Excellent anti-wear property. | ||
*Minimum drainage resistance. | ||
*Allows for smallest thread mark. | ||
*Great retention of fiber fines. | ||
*Much longer lifespan. |
Our fabrics are available in a variety of woven patterns, mesh count, thread diameter, surface topography and air
permeability upon your request. And the following is the most hot sale fabric supplied And the following is the
most hot sale fabric supplied by Sun Hong .
For more products information ,welcome to visit Sun Hong website www.sunhongfabric.com
Single Layer Forming Fabric
Models | Weaving series and types | Filament diameter mm | Density(root/cm) | tensile strength | Thickness mm | m³/m²h | Force elongtion (in 50N/cm Tension,Tensile rate not more than ) | |||
warp | weft | warp | weft | surface | joint | |||||
SH27254 | 4 heddle monolayer forming fabric | 0.2 | 0.25 | 30 | 22 | ≥600 | ≥400 | 0.49 | 8000 | 0.60% |
SH27274 | 0.2 | 0.27 | 30 | 21.5 | ≥600 | ≥400 | 0.51 | 7800 | 0.60% | |
SH31204 | 0.18 | 0.2 | 35 | 28 | ≥600 | ≥380 | 0.43 | 7500 | 0.68% | |
SH31204-1 | 0.18 | 0.2 | 35 | 30 | ≥600 | ≥380 | 0.43 | 7000 | 0.68% | |
SH30205 | 5 heddle monolayer forming fabric | 0.17 | 0.2 | 32 | 28.5 | ≥500 | ≥350 | 0.41 | 7100 | 0.60% |
SH31215 | 0.2 | 0.21 | 35 | 32 | ≥600 | ≥400 | 0.48 | 7000 | 0.60% | |
SH25358 | 8 heddle monolayer forming fabric | 0.22 | 0.35 | 28 | 19.5 | ≥700 | ≥500 | 0.85 | 9000 | 0.65% |
SH25388 | 0.22 | 0.38 | 29.5 | 19 | ≥700 | ≥500 | 0.87 | 8500 | 0.65% | |
SH27358 | 0.22 | 0.35 | 30 | 20 | ≥700 | ≥500 | 0.85 | 8500 | 0.65% | |
SH25458 | 0.22 | 0.45 | 29 | 15.2 | ≥700 | ≥500 | 0.87 | 7500 | 0.65% |
Double and A Half Layer Forming Fabric
Models | Warp Mesh | Weft Count | Warp Diameter | Weft Diameter | Air Permeability | FSI | DI | |
/m³/m²H | CFM | |||||||
SH2B6408 | 71.5-72.5 | 67.5-68.5 | 0.15 | 0.18 0.12/0.22 0.22 | 4350 | 275 | 155 | 25.7 |
71.5-72.5 | 65.5-66.5 | 0.15 | 0.18 0.12/0.22 0.22 | 4600 | 290 | 152 | 26.3 | |
71.5-72.5 | 56.5-57.5 | 0.15 | 0.18 0.12/0.22 0.22 | 5800 | 370 | 135 | 29 | |
71.5-72.5 | 47.5-48.5 | 0.15 | 0.18 0.12/0.22 0.22 | 7900 | 500 | 119 | 33 | |
SH2B5616 | 62.5-63.5 | 60.5-61.5 | 0.17 | 0.20 0.13/0.30 0.30 | 4500 | 285 | 139 | 23.9 |
62.5-63.5 | 59.56-60.5 | 0.17 | 0.20 0.13/0.30 0.30 | 3950 | 250 | 137 | 20.6 | |
62.5-63.5 | 53.5-54.5 | 0.17 | 0.20 0.13/0.30 0.30 | 5050 | 320 | 126 | 23.7 | |
62.5-63.5 | 47.5-48.5 | 0.17 | 0.20 0.13/0.30 0.30 | 6000 | 380 | 115 | 25.1 | |
SH2B4216 | 47.0-48.0 | 47.0-48.0 | 0.22 | 0.20 0.13/0.30 0.30 | 6000 | 380 | 107 | 25.1 |
47.0-48.0 | 40.0-41.0 | 0.22 | 0.25 0.17/0.40 0.40 | 7000 | 445 | 94 | 25.1 | |
SH2B3616 | 40.5-41.5 | 38.5-39.5 | 0.26 | 0.30 0.20/0.50 0.50 | 5500 | 350 | 89 | 18.8 |
40.5-41.5 | 36.5-37.5 | 0.26 | 0.30 0.20/0.50 0.50 | 6350 | 400 | 85 | 20.4 | |
40.5-41.5 | 34.5-35.5 | 0.26 | 0.30 0.20/0.50 0.50 | 7000 | 445 | 82 | 21.4 |
Triple(SSB) Layer Forming Fabric
Models | Warp Mesh | Weft Count | Warp Diameter | Weft Diameter | Air Permeability | FSI | DI | |
/m³/m²H | CFM | |||||||
SH3C6020 | 69.5-70.5 | 79.5-80.5 | 0.13/0.20 | 0.13 0.13/0.27 0.27 | 3950 | 250 | 195 | 25.4 |
SH3C5220 | 59.5-60.5 | 79.5-80.5 | 0.13/0.20 | 0.13 00.13/0.30 0.30 | 4500 | 285 | 186 | 29 |
59.5-60.5 | 67.5-68.5 | 0.13/0.20 | 0.13 0.13/0.30 0.30 | 6350 | 400 | 166 | 34.5 | |
59.5-60.5 | 61.5-62.5 | 0.13/0.20 | 0.15 0.15/0.35 0.35 | 6000 | 380 | 156 | 29.9 | |
SH3C5224 | 51.5-52.5 | 54.4-55.5 | 0.17/0.25 | 0.17 0.17/0.40 0.40 | 4500 | 285 | 137 | 19.9 |
51.5-52.5 | 48.5-49.5 | 0.17/0.25 | 0.17 0.17/0.40 0.40 | 6000 | 380 | 127 | 23.6 | |
SH3C4224 | 41.5-42.5 | 43.5-44.5 | 0.22/0.30 | 0.22 0.22/0.45 0.45 | 5500 | 350 | 110 | 19.6 |
41.5-42.5 | 39.5-40.5 | 0.22/0.30 | 0.22 0.22/0.45 0.45 | 7000 | 445 | 103 | 22.6 | |
SH3C4220 | 41.5-42.5 | 49.5-50.5 | 0.20/0.30 | 0.22 0.22/0.45 0.45 | 5500 | 350 | 119 | 22.2 |
41.5-42.5 | 45.5-46.5 | 0.20/0.28 | 0.22 0.22/0.50 0.50 | 6350 | 400 | 113 | 23.4 | |
41.5-42.5 | 39.5-40.5 | 0.20/0.28 | 0.22 0.22/0.50 0.50 | 8000 | 505 | 103 | 25.7 |
FAQ:
1.How to make an inquiry of Forming fabric ?
You need to provide the following information
If you have detailed requirement,we'll provide formal quotation list after your inquiry received immediately.
2.Could you provide free sample ?
Yes, we can provide free sample together with our catalogue for A Deepen understanding to Fabric . But the courier charge will on your side. We'll send back the courier charge from the order you placed.
Contact Us
Jenny
Cell:+86 15050826262
www.sunhongfabric.c
Prod Model: | SH-FF109 |
---|---|
Fabric Name: | Forming Fabrics |
Fabric Material: | Polyester |
Fabric Type: | Single, Double, 2.5, Triple Layer |
Fabric Usage: | Paper Making Industry |
Supply Type: | Make-to-Order |
Weaving Type: | 4 Shed, 5 Shed, 7 Shed, 8 Shed, 16 Shed |
Fabric Application: | Tissue, Packing, Cultural, Special Paper and etc. |
Fabric Feature: | Super Dimensional Stability, Longer Lifetime |
