PVC Coated Gabion Box / Galvanized Gabion Mattress
| Price: |
US $ 1.42-1.61/Square Meter |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
10/Square Meter |
| Pay Type: |
L/C,T/T,Western Union,Paypal,Money Gram |
| Prod Model: |
CT-1(Gabion) |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Mesh Hole: |
70*90mm 80*100mm 100*120mm |
| Selvedge: |
2.5mm-4.5mm |
| Color Options: |
Green Black Grey or Customize |
| Life: |
70-80years |
| Advantage: |
Cheap Price, Fast Delivery |
| Products Name: |
PVC Gabion Box |
| Export Markets: |
Global |
| Service: |
Best Service |
| Sample: |
Free |
| Material: |
PVC Coated Steel Wire |
| Application: |
Plants Protection Net |
| Hole Shape: |
Hexagonal |
| Surface Treatment: |
PVC Coated |
Product Description
Gabion wall, gabion box, gabion basket, gabion stone, stone cage for retaining wall, gabion mattress
Custom products& standard
PVC coated with UV stabilizer
Provide any size
Available in 5 finishes: Galvanized steel and PVC coated, High zinc-aluminium alloy
Gabions are divided into cells with diaphragms(usually spaced at 1 meter or 3' intervals), whose function is to reinforce the structure. The mesh(except for diaphragms )is reinforced on all edges with wires of a larger diameter to strengthen the gabions and facilitate the assembly and installation.
Applications:
1. Controlling and leading the river and flood.
2. Flood discharge and lead flow.
3. Rock fall defending.
4. Preventing the water and soil lost.
5. Protecting the bridge.
6. Reinforce fabric.
7. Seashore recovery project.
8. Seaport project.
Advantages:
1. Economic. Just put the stone into the gabion and seal.
2. Easily construct, no special technology needed.
3. Strong capacity of withstand nature destroy, rust-resistance and atrocious weather resistance.
4. Affording Large scale distortion, but never be defeated.
5. The slit between the mesh and stone is good for the growth, which can be the part of the environment around.
6. Excellent Penetrability, which can prevent from the whist by liquid.
7. Saving the transport costs. Which can fold while loading and transport, then assemble| Galfan Gabions Mesh Standard |
| Opening (mm) | Wire Diameter(Metal Wire) (mm) | Wire Diameter / Inner/Outside(mm) | Strands |
| 60X80 | 2.0-2.8 | 2.0/3.0-2.5/3.5 | 3 |
| 80X100 | 2.0-3.2 | 2.0/3.0-2.8/3.8 | 3 |
| 80X120 | 2.0-3.2 | 2.0/3.0-2.8/3.8 | 3 |
| 100X120 | 2.0-3.4 | 2.0/3.0-2.8/3.8 | 3 |
| 100X150 | 2.0-3.4 | 2.0/3.0-2.8/3.8 | 3 |
| 120X150 | 2.0-4.0 | 2.0/3.0-3.0/4.0 | 3 |
Hebei Changte Wire Mesh Manufacturing Co., Ltd is located in Anping, the famous Wire Mesh Land of China. Established in 2000, today Changte has developed to be a major company who equipped with more than 200 sets wire mesh production machines, and engaged in various of wire mesh products'sale and production.
Our factory has advanced equipments, skilled workers, complete quality management system, strong R&D capability. With choice materials, we are mainly manufacture Crimped wire mesh, Woven wire mesh, Filter screen mesh, Self cleaning screen mesh, Square wire mesh, Gabion wire mesh, Wire mesh fence, Razor barbed wire etc.
As our company is growing day by day, the list of clients is also increasing and today; We have marked a niche in not only domestic but also in international market. With our internationally certified products, we have revolutionized the global market place.
Our clients are spread across the corners of world, recommending our products for their durability, designing accuracy, dimensional tolerance and adaptability to work under adverse conditions.
For export, utmost attention is paid towards packaging of the products in order to protect them from damage, scratches and dents during the transit.
Today, we are exporting our products to some of the major international markets that are as follows:
UAE
Bahrain
Kuwait
USA
Australia
New Zealand
Jordan
Dubai
South
Zambia
Ivory Coast
Japan
Russia
South Africa
Germany
We adopt to the win-win cooperation model and Set up customer-oriented concept.
If there is anything we can do for you, please send your inquiry. We will try our best to help you. Welcome to visit our factory.
