Sc-Sc Optic Patch Cord

Basic Info:

• Model NO.: SC
• Type: single-mode Fiber
• Material Shape: Round Wire
• Allowed Tensile Strength: 100N<1000N
• Certification: ISO9001, SGS
• main Material: PVC;
• Connector Housing Color: Blue, Beige, Aqua, Black, Green, Red, Yellow,
• Clips: with Clips, Without Clips
• Cable Jacket Color: Blue, Beige, Aqua, Black, Green, Yellow,Customized
• Trademark: OEM
• Specification: SGS
• HS Code: 85447000

• Application: Communication, FTTX
• Connection Structure: SC-SC
• Allowed Lateral Pressure: 100(N/100mm)<1000(N/100mm)
• Core: single Core
• Cable Diameter Szie: 0.9mm,1.6mm,1.8mm,2.0mm,2.4mm,2.8mm,3.0mm
• Connector Boot Color: Blue, Beige, Aqua, Black, Green, Red,White,
• Length: 0.5m, 1m,2m or Customized
• Connector Type: Simplex, Duplex
• Transport Package: Carton, Plastic Bag or Custom Packaging
• Origin: hangzhou/shanghai or ningbo

Features:
1.Low insertion loss
2.Mechanicl properties meet standards ISO9001 and SGS
4.The patch cable can be customized according to customers specific requirements
5.Strict quality testing:IL and RL 100% test.


Applications:
1.Wiring of local area network between different enterprise buildings
2.Connection of optical links in optical active devices
3.Wiring in communication base station and distrinbtion case
4.Production and testing of optical devices
5.Optical fiber communication system,CATV and telecommunication network
6.LANs and WANs
7.FTTx

SPECIFICATIONS:

ITEM	Parameter
	Single-mode	Multi-mode
Test wavelength	1310nm, 1550nm	850nm, 1300nm
Insertion Loss	typical≤0.20dB,Max≤0.30dB	typical≤0.15dB,Max≤0.25dB
Return Loss	UPC≥50.0dB,APC≥60.0dB	≥35.0dB
Repeatability	≤0.10dB
Interchangeability	≤0.20dB
Durability	≤0.20dB typical change,1000 mating
Tensile Strength	≥120N(without 0.9mm patch-cord) or customized
Operating Temperature	-20ºC to +70ºC
Storage Temperature	-40ºC to +85ºC
