| Prod Model: |
GG-SG |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Use: |
Dose Fill |
| Capacity: |
100ml, 200ml, 500ml, 1000ml |
| Nozzel Size: |
2mm,4mm.6mm,8mm,12mm |
| Type: |
Volumetric Filling Machine |
| Automatic Grade: |
Semi-Automatic |
| Material Type: |
Paste |
| Filling Valve Head: |
Single-Head |
| Feed Cylinder Structure: |
Single-Room Feeding |
| Dosing Device: |
Capacity Cup |
| Filling Principle: |
Pressure |
| Packaging Container Lifting Structure: |
Pneumatic Lifting |
| Structure: |
Linear |
| Packaging Type: |
Bottle |
| Packaging Material: |
Stainless Steel |
Product Description
Semi-automatic double heads Filling Machine
We can produce 100ml, 200ml, 500ml, 1000ml etc. Capacity filling machine, and also can according to the customer requirements to produce.
Application
The equipment uses special rotating valve to control material-feeding and measurement, especially suits for the filling of high-viscosity material (egcrude oil, asphalt, paint, emulsion etc. )
Suitable for filling various kinds of highly viscous fluid in the industries of pharmaceutics, daily chemicals, foodstuffs, cosmetics, pesticide and special trades. With no need for power supply, the machine is safe and with the personalized design, can meet the modern enterprises requirements.
This machine is the semi-automatic double piston liquid filling machine, working under the state without electricity, it is safer to operate.
This machine reasonable in design, smart in model, easy to operate, the pneumatic part adopts the pneumatic components of Taiwans AirTac, SHAKO.
The part contacting materials is made of 304/316L stainless steel.
With adjustment handle of filling volume, the filling speed can be adjusted at will, with high filling accuracy.
Filling head adopts anti-leakage, anti-pull and with diving filling device.
According to customer requirements, such as brand, stainless steel materials, cylinder seal materials etc.
Wenzhou wanyuan food machinery factory- - Filling machine
Semi-automatic double heads Filling Machine
The below is filling machin specifications:
| Model | GG-DG (One Head) | GG-SG (Double Heads) |
| Power | 200/110V 50/60HZ | 220/110V 50/60HZ |
| Air pressure | 0.4-0.6mpa | 0.4-0.6mpa |
| Filling speed | 5-30bottles/min | 20-50bottles/min |
| Filling accuracy | +/-0.1% | +/-0.5% |
Filling volumes
range | 5-100ml 10-280ml 20-500ml 100-1000ml 500-2800ml 1000-5000ml | 10-280ml 20-500ml 100-1000ml 500-2800ml 1000-5000ml
|
| Overall dimensions | 1200*300*800mm | 1200*450*800mm |
| weight | 40KG | 60KG |
Our factory specializes in producing and selling processing equipment for dairy products, beverage, brewage, meat and poultry. Our main products include automatic double-tank sterilizing boilers, electric heating sterilizing boilers, emulsifying tanks, sugar dissolving tanks, cooling and heating cylinders, concentrating boilers, seed tanks, jacketed boilers, and direct cooling tanks.
Other food equipment can also be designed and manufactured according to customer requirements. The latest digital technology has been utilized for direct conversational programming and key parts have been carried out in mechanical machining, such as drilling, cutting, milling and grinding to ensure the ultimate precision. We have powerful technical force to independently and successfully design and manufacture products, completely realizing the simple and programmable operations of consistent products. We have some experienced experts and they can provide whole services for you from initial preparation, detailed construction and after-sales technique to spare part support.
At the same time, we combine our many years' experience to meet customer requirements and solve the difficulties of equipment technology. All our stainless steel equipment have reached sanitary equipment standard, which guarantees users with completely sanitary status through our abundant strength and a good reputation. We offer customers safe and reliable products and favorable prices.
