A membrane switch is an electrical switch for turning a circuit on and off. It differs from a mechanical switch. Membrane switch is very thin and soft. The touch surface material usually is PET or PC. The circuit can be PET, FPC or even PCB. Membrane switches are user-equipment interface utilities that allow for the communication of commands from users to electronic devices.


---PRODUCTION DESCRIPTION---

> Construction:

A membrane switch typically has 6 or more or less layers. The top layer of a membrane switch is the graphic overlay interface between the user and the machine. The other critical layer is a the circuit layer. It can also be PET, FPC or PCB. All the layers are normally assembled using pressure-sensitive adhesives. Contact between two traces can be made through a printed shorting pad or through a metal dome that stands on legs.

> Membrane Keypad Structure

1) 4 layers structure: Graphic overlay + Spacer + Circuit(can be PET circuit or FPC circuit) + Back Adhesive
2) 6 layers structure: Graphic overlay + Spacer: Dome Retainer + Spacer + Circuit(can be PET circuit or  FPC circuit) + Back Adhesive;
3) Other Structure
     3.1) Overlay + Rubber Adhesive + Rubber Keypad + Rubber Adhesive + Retainer + Spacer + Circuit + Back Adhesive;
     3.2) Overlay + Spacer + Retainer + PCB Circuit;
And also there are many other kinds of structures for the interface keypads structure. It based on customer's real needs and we can design the suitable and economical structure for our customer's final application.


> Main Technical Specifications:


Item	Description	Technical capabilities
1	Max. Size	1200mm x 1000mm
2	Overlay Material	PET: Autotype (Autotex F150, F200, F280, V150, V200, V280,                             Autoflex EBG130, EBG180, EBG250, EBA130, EBA180, EBA250)          Autotex : XEV150, XEF200;          Autostat CT3, CT4, CT5, CT7          DuPont etc. PC:  GE LEXAN--8010 8B35 8B35F HP92S HP40  FR700 FR60
3	Spacer	3M Adhesive, NITTO, TESA, SONY, SEKISUI, Domestic Adhesive
4	Back Adhesive	3M(Mainly), Others(Little)
5	Silver Paste	CHANGSUNG: CSP-3163, CSP-3352, CSP-5150; ACHESON: ED 725A(6S-61), ED 427SS, ED 479SS, ED 976SS HV; FUJIKURA and OTTI
6	Oil Ink	SEIKO, JUJO, DUBUIT, PROELL, NORCOTE UV
7	Carbon Paste	FUJIKURA, ACHESON ED 581SS, OTTI
8	6 Layers Metal dome Type Membrane Switch Structure	Overlay + Spacer + Dome Retainer + Spacer + Circuit Layer+ Back adhesive
9	4 Layers Polydome Type Membrane Switch Structure	Overlay + Spacer + Circuit + Back adhesive
10	Contact Resistance	0.5-10Ω
11	Insulation Resistance	≥10MΩ (100VDC)
12	Base Material Voltage Durable	≤ 2000V DC
13	Bounce Time	≤ 5ms
14	Working Current	≤ 100mA
15	Working Voltage	≤ 50VDC
16	Life	≥ 1,000,000 times
17	Key Travel	Flat type: 0.05mm-0.5mm, Tactile Type: 0.1-1.5mm
18	Working Temperature	-40ºC-+80ºC
19	Actuation Force	20-550g
20	Storage Condition	Temperature: -40ºC~+85ºC ,Humidity: ≤98% RH
21	PET Circuit Tail Flexible Feature	180°to any angle

Free from the erosion of harmful gas.
