Ucp218 Pillow Block Bearing

Name: Ucp218 Pillow Block Bearing
Brand: FullPackage
SKU: 775345625
Availability: InStock
Rating: 4.6 (117 reviews)

Price:	US $ 18.5/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	10/Set
Pay Type:	L/C,T/T,D/P

Contact Supplier

Showroom Product Company Profile

Prod Model:	UCP218
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Weight:	10.90kg
Unit Color:	Dark Green
Material:	Chrome Steel
Tolerance:	P0
Certification:	ISO9001
Clearance:	C0
ABS:	Without ABS
Type:	Pillow Block Bearing
Brand:	Fkd
Application:	Printing Machinery

Product Description

Product name: Pillow Blocks

Product item: UCP 200 X00 300

Product packing: Polybag + individual color box + carton + pallet

Product material: Chrome steel (GCR15) for bearings, cast iron (HT200) for housings

Pillow Block Bearings are composed of a single row deep groove ball bearings with seals at both sides and spherical outside surface, and a housing, suitable for simple support.

Pillow Blocks are for mechanical equipment, like agricaltural, metallurgical, textile and printing machinery.

Bearing No.	Dimensions mm inch											Bolt Size mm inch	Weight Kg


	d	h	a	e	b	S1	S2	g	w	b	n
UCP201	12	30.2	127	95	38	13	19	14	62	31	12.7	M10	0.69
UCP201-8	1/2	1-3/1/6	5	3-3/4	1-1/2	1/2	3/4	9/16	2-7/16	1.2205	0.500	3/8	0.69
UCP202	15	30.2	127	95	38	13	19	14	62	31	12.7	M10	0.69
UCP202-9	9/16	1-3/1/6	5	3-3/4	1-1/2	1/2	3/4	9/16	2-7/16	1.2205	0.500	3/8	0.69
UCP202-10	5/8												0.69
UCP203	17	30.2	127	95	38	13	19	14	62	31	12.7	M10	0.68
UCP203-11	11/16	1-3/16	5	3-3/4	1-1/2	1/2	3/4	9/16	2-7/16	1.2205	0.500	3/8	0.67
UCP204	20	33.3	127	95	38	13	19	14	65	31	12.7	M10	0.66
UCP204-12	3/4	1-5/16	5	3-3/4	1-1/2	1/2	3/4	9/16	2-9/16	1.2205	0.500	3/8	0.66
UCP205	25	36.5	140	105	38	13	19	15	71	34.1	14.3	M10	0.81
UCP205-13	13/16	1-7/16	5-1/2	4-1/8	1-1/2	1/2	3/4	19/32	2-25/32	1.3425	0.563	3/8	0.85
UCP205-14	7/8												0.83
UCP205-15	15/16												0.82
UCP205-16	1												0.81
UCP206	30	42.9	165	121	48	17	20	17	84	38.1	15.9	M14	1.24
UCP206-17	1-1/16	1-11/16	6-1/2	4-3/4	1-7/8	43/64	25/32	21/32	3-5/16	1.5	0.626	1/2	1.27
UCP206-18	1-1/8												1.26
UCP206-19	1-3/16												1.24
UCP206-20	1-1/4												1.23
UCP207	35	47.6	167	127	48	17	20	18	93	42.9	17.5	M14	1.58
UCP207-20	1-1/4	1-7/8	6-9/16	5	1-7/8	43/64	25/32	45/64	3-21/32	1.689	0.689	1/2	1.64
UCP207-21	1-5/16												1.61
UCP207-22	1-3/8												1.58
UCP207-23	1-7/16												1.55
UCP208	40	49.2	184	137	54	17	20	18	100	49.2	19	M14	1.89
UCP208-24	1-1/2	1-15/16	7-1/4	5-13/32	2-1/8	43/64	25/32	45/64	3-15/16	1.937	0.748	1/2	1.93
UCP208-25	1-9/16												1.9
UCP209	45	54.0	190	146	54	17	20	20	106	49.2	19	M14	2.14
UCP209-26	1-5/8	2-1/8	7-15/32	5-3/4	2-1/8	43/64	25/32	25/32	4-11/64	1.937	0.748	1/2	2.24
UCP209-27	1-11/16												2.2
UCP209-28	1-3/4												2.14
UCP210	50	57.2	206	159	60	20	23	21	113	51.6	19	M16	2.66
UCP210-29	1-13/16	2-1/4	8-1/8	6-1/4	2-3/8	25/32	29/32	53/64	4-29/64	2.0315	0.748	5/8	2.78
UCP210-30	1-7/8												2.73
UCP210-31	1-15/16												2.68
UCP210-32	2												2.64
UCP211	55	63.5	219	171	60	20	23	23	125	55.6	22.2	M16	3.31
UCP211-32	2	2-1/2	8-5/8	6-47/64	2-3/8	25/32	29/32	29/32	4-59/64	2.189	0.874	5/8	3.46
UCP211-33	2-1/16												3.4
UCP211-34	2-1/8												3.35
UCP211-35	2-3/16												3.29
UCP212	60	69.8	241	184	70	20	23	25	138	65.1	25.4	M16	4.9
UCP212-36	2-1/4	2-3/4	9-1/2	7-1/4	2-3/4	25/32	29/32	63/64	5-7/16	2.563	1.000	5/8	5.03
UCP212-37	2-5/16												4.95
UCP212-38	2-3/8												4.88
UCP212-39	2-7/16												1.81
UCP213	65	76.2	265	204	70	25	28	27	150	65.1	25.4	M20	5.15
UCP213-40	2-1/2	3	10-7/16	3	2-3/4	63/64	1-3/32	1-1/16	5-29/32	2.563	1.000	3/4	5.24
UCP213-41	2-9/16												5.15
UCP214	70	79.4	266	210	72	25	28	27	156	74.6	30.2	M20	6.2
UCP214-42	2-5/8	3-1/8	10-15/32	8-17/64	2-27/32	63/64	1-3/32	1-1/16	6-9/64	2.937	1.189	3/4	6.41
UCP214-43	2-11/16												6.31
UCP214-44	2-3/4												6.21
UCP215	75	82.6	275	217	74	25	28	28	162	77.8	33.3	M20	7.16
UCP215-45	2-13/16	3-1/4	10-53/64	8-35/64	2-29/32	63/64	1-3/32	1-3/32	6-3/8	3.063	1.311	3/4	7.41
UCP215-46	2-7/8												7.3
UCP215-47	2-15/16												7.19
UCP215-48	3												7.07
UCP216	80	88.9	292	232	78	25	28	30	174	82.6	65.1	M20	8.1
UCP216-49	3-1/16	3-1/2	11-1/2	9-1/8	3-1/16	63/64	1-3/32	1-3/16	6-27/32	3.252	2.563	3/4	8.28
UCP216-50	3-1/8												8.15
UCP216-51	3-3/16												8.02
UCP217	85	95.2	310	247	83	25	28	32	185	85.7	34.1	M20	9.81
UCP217-52	3-1/14	3-3/4	12-13/64	9-23/32	3-17/64	63/64	1-3/32	1-1/4	7-9/32	3.374	1.343	3/4	10.03
UCP217-53	3-5/16												9.89
UCP217-55	3-7/16												9.6
UCP218	90	101.6	327	262	88	27	30	33	198	96	39.7	M20	11.96
UCP218-56	3-1/2	4	12-7/8	10-5/16	3-15/32	1-1/16	1-3/16	1-19/64	7-51/64	3.7795	1.563	3/4	12.07
UCP305	25	45	175	132	45	17	20	15	85	38	15	M14	1.4
UCP305-13	13/16	1-46/64	6-7/8	5-3/16	1-25/32	43/64	25/32	19/32	3-11/32	1.4961	0.591	1/ 2
UCP305-14	7/8											/
UCP305-15	15/16											1/ 2
UCP305-16	1
UCP306	30	50	180	140	50	17	20	18	85	43	17	M14	1.8
UCP306-17	1-1/16	1-31/32	7-3/32	5-1/2	1-31/32	43/64	25/32	23/32	3-3/4	1.6929	0.669	1/ 2
UCP306-18	1-1/8
UCP306-19	1-3/16
UCP307	35	56	210	160	56	17	25	20	106	48	19	M14	2.8
UCP307-20	1-1/4	1-13/64	8-9/32	6-5/16	2-13/64	43/64	31/32	25/32	4-3/16	1.8898	1.748	1/ 2
UCP307-21	1-5/16
UCP307-22	1-3/8
UCP307-23	1-7/16
UCP308	40	60	220	170	60	17	27	22	116	52	19	M14	3
UCP308-24	1-1/2	2-23/64	8-21/32	6-11/16	2-3/8	43/64	1-11/16	7/8	4-9/16	2.0472	0.748	1/ 2
UCP308-25	1-9/16
UCP309	45	67	245	190	67	20	30	24	129	57	22	M16	4.1
UCP309-26	1-5/8	2-41/64	9-21/32	7-15/32	2-5/8	25/32	1-3/16	15/16	5-3/32	2.2441	0.866	5/8
UCP309-27	1-11/16
UCP309-28	1-3/4
UCP310	50	75	275	212	75	20	35	27	143	61	22	M16	5.8
UCP310-29	1-13/16	2-61/64	10-13/16	8-11/32	2-15/16	25/32	1-3/8	1-1/16	5-5/8	2.4016	0.866	5/8
UCP310-30	1-7/8
UCP310-31	1-15/16
UCP311	55	80	310	236	80	20	38	30	154	66	25	M16	7.4
UCP311-32	2	3-5/32	12-7/32	9-9/32	3-5/32	25/32	1-1/2	1-3/16	6-1/16	2.5984	0.948	5/8
UCP311-33	2-1/16
UCP311-34	2-1/8
UCP311-35	2-3/16
UCP312	60	85	330	250	85	25	38	32	165	71	26	M20	9.4
UCP312-36	2-1/4	3-11/32	13	9-17/32	3-11/32	31/32	1-1/2	1-1/4	6-1/2	2.7953	1.024	3/4
UCP312-37	2-5/16
UCP312-38	2-3/8
UCP312-39	2-7/16
UCP313	65	90	340	260	90	25	38	33	176	75	30	M20	10
UCP313-40	2-1/2	3-35/64	13-3/8	10-1/4	3-17/32	31/32	1-1/2	1-5/16	6-15/16	2.9528	1.818	3/ 4
UCP313-41	2-9/16
UCP314	70	95	360	280	90	27	40	35	187	78	33	M22	12
UCP314-42	2-5/8	3-47/64	14-3/16	11-1/32	3-17/32	1-1/16	1-9/16	1-3/8	7-3/8	3.0708	1.299	7/8
UCP314-43	2-11/16
UCP314-44	2-3/4
UCP315	75	100	380	290	100	27	40	35	198	82	32	M22	14
UCP315-45	2-13/16	3-15/16	14-31/32	11-13/32	3-15/16	1-1/16	1-9/16	1-3/8	7-25/32	3.2283	1.26	7/8
UCP315-46	2-7/8
UCP315-47	2-15/16
UCP315-48	3
UCP316	80	106	400	300	110	27	40	40	210	86	34	M22	18
UCP316-49	3-1/16	4-11/64	15-3/4	11-13/16	4-11/32	1-1/16	37150	1-9/16	8-9/32	3.3858	1.339	7/8
UCP316-50	3-1/8
UCP316-51	3-3/16
UCP317	85	112	420	320	110	33	45	40	220	96	40	M27	20
UCP317-52	3-1/4	4-13/32	16-17/32	12-19/32	4-11/32	1-5/16	1-25/32	1-9/16	8-21/32	3.7795	1.575	1
UCP317-53	3-5/16
UCP317-55	3-7/16
UCP318	90	118	430	330	110	33	45	45	235	96	40	M27	24
UCP318-55	3-7/16	4-41/64	16-15/16	13	4-11/32	1-5/16	1-25/32	1-25/32	9-1/4

HEBEI HAILAN BEARING MANUFACTURE Co., Ltd

Brief introduction of company

Hebei Hailan Bearing Manufacture Co., Ltd, is the professional manufacturer and exporter of Pillow blocks, Taper roller bearing(both in metric size and inch size), Deep groove ball bearing, Spherical roller bearing, Self-aligning ball bearing, Thrust ball bearings etc.

We have more than 20 years' experience of producing and exporting all kinds of bearings. With the advanced technique and equipments, we can provide high-level products under standard process and devices.

Hebei Hailan Bearing Manufacture Co., Ltd is located in the Hometown of Bearing in the North China, Linxi, Hebei Province, where is the boundary of Hebei Province, Shandong Province and Henan Province, and she enjoys superior location and convenient transportation.

We have passed the ISO9001: 2000 International Quality Management System and got the Certificate of Import&Export from our government. The annual output is more than 10 million sets. We have registered the trademark of " FKD, FE, HHB" , they are well known in the oversea market. Our market have extended to North America, South America, Eastern Europe, Southeast, Asia, Africa, Middle East, Eastern Asia, Western Europe etc.
