| Price: | Negotiable/Piece |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 100/Piece |
| Pay Type: | L/C,T/T |
Application
The SCM2-60B series are with two impellers back to back. because of two impeller to gain energy, it is an obvious choice that there is need for high head values but if hard to reach with single impeller centrifugal pumps. suitable for civil and industrial uses to pump clean water and chemically non-aggressive liquid. Particularly be used for increasing the supply pressure, feeding boilers and loading extremely.
Operating conditions
Liquid temperature up to 60
Ambient temper up to 40
Total suction lift to 9m
Continuous duty
Construct
Pump
Pump body: Cast Iron
Impeller: Brass/Cast/Aluminum
Insulation class: B and F
Motor
Motor: Closed, externally ventilated
Protection class: IP44 or IP54
Mechanical seal: Stainless steel/Carbon-ceramic
Shaft:45# steel / Stainless steel
Thermal protector(if required)
Our Enterprise Spirit
The Market is the Core and The Quality is the Life.
We welcome worldwide merchants to join us for common development !
FAQ
Q: What is your MOQ of this item?
A: Our MOQ is a full 20ft container, but for the first time cooperation, we accept samples order to check quality.
Q: Is it all right to make customers'own brand name?
A: Sure, we can be your OEM manufacturer with your authorization of brand.
Q: What are your payment terms?
A: 30% T/T deposit, 70% balance before shipment or L/C at sight.
Q: How long is your warranty?
A: One year after receive B/L.
Q: What is the delivery time?
A: 25-30 days after receiving your L/C or T/T deposit.
| Model | POWER KW/HP | MAX.HAED M | MAX.FLOW L/MIN | SUCT.MAX M | DNA:INCH | DNM:INCH |
| SCM2-45 | 0.75/1 | 35 | 90 | 9 | 1.25" | 1" |
| SCM2-52 | 1.1/1.5 | 45 | 105 | 9 | 1.25" | 1" |
| SCM2-60A | 1.5/2 | 55 | 105 | 9 | 1.25" | 1" |
| SCM2-60B | 1.5/2 | 55 | 130 | 9 | 1.5" | 1.5" |
| SCM2-68 | 2.2/3 | 66 | 150 | 9 | 1.5" | 1.25" |
A: 25-30 days after receiving your L/C or T/T deposit.
| Prod Model: | SCM2-60B |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Place Of Origin: | Zhejiang, China (Mainland) |
| Model Number: | Scm2-60b Series |
| Impeller: | Brass |
| Wire: | Copper |
| Shaft: | 45#Steel/Stainless Steel |
| Voltage: | 220V/110V |
| Brand: | Wedo Brand |
| Standard Or Nonstandard: | Standard |
| Mechanical: | Carbon/Ceramic/Stainless Steel |
| Material: | Cast Iron |
| Structure: | Single-stage Pump |
| Power: | Electric |
| Application: | Clarified Water Pump |
| Theory: | Centrifugal Pump |
| Assembly: | Electric Water Pump |
| Type: | Scm2-60b Centrifugal Water Pump |
| Media: | Clean Water |
