Price: | US $ 31-33/Roll |
---|---|
Min Order: | 30/Roll |
Pay Type: | L/C,T/T,D/P,Western Union,Paypal |
Featured product | Popular Size | |
Standard PVC Strip Curtain Cold Room PVC Strip Curtain Anti-Insect PVC Strip Curtain Anti-Static PVC Strip Curtain Anti-Ultraviolet PVC Strip Curtain Welding PVC Strip Curtain | 2mm*75mm*50M 2mm*100mm*50M 2mm*200mm*50M 2mm*300mm*50M 2mm*400mm*50M 3mm*200mm*50M 3mm*300mm*50M 3mm*400mm*50M 4mm*400mm*50M | |
PROPERTIES | Standard | Unit | Value |
Hardness Sh A | EN ISO 868 | Sh A | 80 |
Tearing resistance | DIN 53515 | N/mm | 50 |
Tensile strength at break | ASTM D 638 EN ISO 527 | N/mm² | 16 |
Elongation at break | % | 300 | |
Residual elong. (after break) | % | 62 | |
Thermal conductivity | ASTM C 177 | W/m.K | 0,16 |
Cold bend brittle temperature | ISO 8570 | °C | -25 |
Usage temp. range | EN 1876 | °C | -15/+50 |
Vicat softening temp. | EN ISO 306 | °C | 50 |
Specific heat capacity | ISO 11357 | kJ/kg.K | 1,6 |
Sound reduction | DIN 52210 | dB | >35 |
Reaction to fire | EN 1598 | EN1598 | |
Light transmittance | ASTM D 1003 | % | <13 |
UV/IR filter | EN 1598 | Filter | alta |
UV resistance | ISO4892 | - | alta |
Charge buildup | IEC 61087 | Sparks | Si |
Surface resistivity | IEC 60093 | .1012 Ω/ | 40 |
Water absorption | EN ISO 62 | % | -0,2 |
Density | ASTM D 792 | g/cm3 | 1,22 |
Prod Model: | welding PVC Curtain |
---|---|
Effection: | Welding |
Style: | Transparent or Not Transparent |
Size: | as Request |
Color: | Red/Green/Grey/Black |
Bubble: | No |
Stick: | No |
Pollution: | No |
Certificate: | Yes |
Export Market: | Global |
Open Styles: | Swing |
Material: | PVC |
