vibrating apron feeder
Apron feeder, a fixed feeder, is the accessory equipment for conveying machinery. This machine is used to convey materials to primary crusher continuously and evenly. It can also be used for short-distance conveying, especially for heavy, big and abrasive materials. Because of its working reliability in harsh conditions, such as in the open air, in damp environment, ect, apron feeder has been widely applied in the industries of metallurgy, mining, cement and building materials etc. This machine can be in horizontal or inclined installation, with max. inclination degree to be 25°. To avoid direct hit against feeder, storage bin is cannot be emptying. The series of feeder is usually used for uniform and continuous short-distance convey of large materials to various crushing equipment under the large-scale hopper. It is widely used in the fields of mine, smelting, building materials, highway, railway, water conservancy and chemical industry, etc.
vibrating apron feeder APPLICATION
The apron plate feeder is the one for the continuity of the bulk materials conveying equipment, which is widely
used in the industries of mining, cement, chemicals and metallurgy etc. This kind of feeder can deliver massive materials and realizes operation in severe working conditions such as the high temperature and humidity.
vibrating apron feeder FEATURES
1). Advancing technology;
2). Ability of working in severe environment ;
3). Large conveying quantity;
4). Long life and easy maintenance ;
vibrating apron feeder parameters:
BWZ Series Heavy Duty Apron Feeder
MODEL |
Width(mm) |
Wheel Base(mm) |
Max. Feed Size(mm) |
Capacity(t/h) |
Power(kW) |
BWZ1250×6 |
1250 |
6000 |
650 |
150 |
15 |
BWZ1400×8 |
1400 |
8000 |
750 |
250 |
18.5 |
BWZ1600×9 |
1600 |
9000 |
900 |
350 |
30 |
BWZ1800×9 |
1800 |
9000 |
1050 |
500 |
37 |
BWZ2000×10 |
2000 |
10000 |
1100 |
680 |
45 |
BWZ2200×10 |
2200 |
10000 |
1250 |
800 |
55 |
BWZ2400×12 |
2400 |
12000 |
1600 |
1000 |
2×55 |
BWH Series Medium Duty Apron Feeder
MODEL |
Width(mm) |
Wheel Base(mm) |
Max. Feed Size(mm) |
Capacity(t/h) |
Power(kW) |
BWH800×5 |
800 |
5000 |
400 |
100 |
7.5 |
BWH1000×6 |
1000 |
6000 |
450 |
130 |
7.5 |
BWH1200×6 |
1200 |
6000 |
500 |
180 |
15 |
BWH1400×8 |
1400 |
8000 |
550 |
280 |
22 |
BWH1600×8 |
1600 |
8000 |
600 |
400 |
30 |
BWH1800×8 |
1800 |
8000 |
700 |
600 |
37 |
