| Price: | US $ 186.1-204.5/Piece |
|---|---|
| Min Order: | 1/Piece |
| Pay Type: | Western Union,Paypal,Money Gram |
| Prod Model: | 12V50AH |
|---|---|
| Color: | White |
| Housing Material: | ABS |
| Connection Mode: | Series and Parallel |
| Type: | Li-Fe |
| Usage: | 12V Electronic Equipment |
| Electrolyte: | No |
| Cell | model | 2714895 | |
| Capacity(0.5C) | 13ah | ||
| rated voltage(V) | 3.7V | ||
| Typical Impedance (mΩ) | ≤2mΩ | ||
| Battery material | Ternary | ||
| PACK | Combination method | 4p3s | |
| Minimal capacity(0.5C) | ≥50Ah | ||
| Nominal voltage | 11.1V | ||
| Max. charge voltage | 12.6V | ||
| Discharge cut-off voltage | ≤8.5V | ||
| Charge current | 6A | ||
| Discharge Current | 80A | ||
| Pack Impedance standard | ≤20mΩ | ||
| Weight (Approx.) | 6.1KG | ||
| Max. dimension(L×W×H)(mm) | 290*210*98mm | ||
| Operating temperature | Charge temperature | 0ºC~45ºC | |
| Discharge temperature | -10ºC~55ºC | ||
| Protection board | Single cell over-charge cut-off voltage | 4.25V | |
| over-charge release voltage | 4.1V | ||
| Single cell under-discharge cut-off voltage | 2.5V | ||
| Discharge release voltage | 2.9V | ||
| Over-discharge cut-off current | 150A | ||
| Over-discharge cut-off current delay | 1S | ||
| Short-circuit protection | yes | ||
| Short-circuit protection delay | 500uS | ||
| Condition for the recovery of over-current and Short-circuit | Self | ||
| Balance current | 45mA | ||
Function Button Speciality : 1 positive pole ,1 negative pole ; LCD of capacity ,1 push switch for LCD ,1 charger hole ;
Note:We offer the full capacity battery pack , we are the 10 years experiences manufacturer . These buyers who buy this battery, must agree that you are familiar with the safe use of lithium battery Knowledge.
Safety Reminder: DIY assembled when good protective measures, Wear protective goggles, insulated gloves.
Large electric vehicle: electric golf carts, buses, electric cars, sightseeing cars and hybrid vehicles DIY
Light electric vehicle: electric bicycle, small flat electric car, forklift, cleaning vehicles, electric wheelchair
Power tools: electric drill, electric saw, lawn mower
Remote control cars, boats, aircraft and other toys
Solar and wind power energy storage equipment
