| Prod Model: |
JIT-1650S |
| Model Number: |
1650s |
| Frame Material: |
Hot Galvanized Steel Tube (75*50*2.0mm, 32*1.5mm) |
| Sail Material: |
PE or PVC |
| Fabric: |
300gpe, 450g PVC, 650gpvc, 750g PVC, 900g PVC |
| Feature: |
Waterproof/UV-Resistance/Fire-Retardant |
| Color: |
Green/White/Grey/Red/Blue or Customized |
| Date Of Delivery: |
in 15 Days |
| MOQ: |
1 Set |
| Certificates: |
ISO9001/SGS/Ce/TUV |
| Factory: |
The Biggest Tent/Shelter Manufacturer in North Chi |
Product Description
16' wide Customerized Heavy Duty Portable Prefab House / Fabric Building / Yacht Tent (JIT-1650S) | Model | JIT-1650S |
| Size (LxWxH) | 15.0 x 5.0 x 5.0m (50' x 16.4' x 16.4') |
| Shoulder height | - |
| Frame material | Hot-dip galvanized steel tube |
| Wall thickness of the tubes | 75x50x2mm, 32x1.5mm, 42x2.5mm |
| Fixing methord | Stake pegs / Stake pegs and earth auger / Expandable bolts |
| Cover material | PE or PVC |
| Fabric | 300gPE, 450g PVC, 650gPVC, 750g PVC, 900g PVC |
| Color | Green/White/Grey/red/blue or customized |
| Door type | 3-zippe Rolling up door | Sliding Door | Winch Door |
| Door size | W3.8xH3.0/4.5m | - | W3.8xH3.0mor customized |
| Package | 1 x Steel box, the archs was loaded in the container directly. |
| Packing box size | 294x73x60cm |
| Delivery time | in 15 days |
| Payment | T/T, L/C |
| Max. allowed wind speed | 70km/h |
| Max. snow load | 80kg/m2 |
| Warranty | Frame: 8-15 years against rust perforation
PE Cover: 1-3 years ( see conditions)
PVC Cover: 8-10 years (see condition) |
Special New Design shelter for very heavy snow and wind.Made of strong 75x50mm rectangle steel tube as frame, perfect roof shape for no snow accumulation.This is a very good choice if your areas have heavy snow and wind in winter, a real investment for your boat.There are different sizes for your choices....
>>JIT ST Series:| Series | Model | SIZE | Load Capability | Gross Weight(kg) |
| Width | Length | Ridge Height | Sets/20' | Sets/40' | 300g PE | 610g PVC |
| ST | JIT-1536S | 4.5 (14.8') | 11.0 (36') | 4.5 (14.8') | 24 | 32 | | 789 |
| ST | JIT-1639S | 5.0 (16.4') | 12.0 (39') | 5.0 (16.4') | 21 | 30 | 795 | 845 |
| ST | JIT-1650S | 5.0 (16.4') | 15.0 (49') | 5.0 (16.4') | 21 | 24 | 975 | 1047 |
| ST | JIT-2430S | 7.3 (24') | 9.15 (30') | 4.3 (14') | | 30 | 1190 | 873 |
| ST | JIT-3240S | 9.75 (32') | 12.2 (40') | 5.0 (16.4') | | 20 | 1190 | 1290 |
| ST | JIT-3250S | 9.75 (32') | 15.0 (49') | 5.0 (16.4') | | 18 | 1400 | 1560 |
| The length can be extended unlimited...Customized size is available. |
>> Specifications of Our Tents
- Frame struss:Strong hot-dip galvanized steel tube which can last more than 8 years.
- Fabric cover:High quality PVC-coated polyester textile, 100% waterproof, flame retardant, UV resistant, tear resistant, self-cleaning ability, etc.
- Connector:Strong hot-dip galvanized steel
- Allowed temperature condition:-30 degree Celsius~+70 degree Celsius
- Wind load:Max.100km/h (can be reinforced)
- Snow load:75kg/sqm (snow can't stay if use big degree roof pitch design)
- Easy to be assembled and dismantled, movable.
- No pole inside, 100% available interior space.
>> Fixing Methods of Our Tents
>> Accessories of Our Tents
- Covers:Colourful cover, transparent cover, inflatable cover
- Windows:Dome or square windows, mesh windows, clear PVC windows
- Flooring System:Customerized
- Doors:Double-wing glass door, single-wing glass door, rolling up door (automatic or manual)
- Wall:Soft PVC fabric wall
- Fixing Methods:Ground anchors, Stake pegs, expandable bolts
- Other Optional Items:Table, chair, lighting, AC, carpet, installation tools etc.
>>Out Customers>> Why is JITCOVER your best choice?1.Leading tent/shelter manufacturer in China, with LARGEST area of plants, most skilled workers and more than 100 tons of material stock.2.Upscale raw material, thick layer hot galvanized steel tubing and best quality PVC fabric with 10 years warranty.3.Professional engineer team with 20 years experience, fast response to customer request on new models in 24 hours.4.ISO 9001:2008 standard Quality Control System, from the raw material to the final packaging quality is strictly guaranteed.5.Directly Factory Wholesale Price to all customers, Maximum save your cost and be most competitive in your marke.For more information, please contact us now!!
We are the leading tent/shelter manufacturer in China, with LARGEST area of plants, most skilled workers and more than 100 tons of material stock. We've been offering high quality products to CoverAll, CoverTech, MdmShelters, ShelterStation, Kroftman, Dancover etc. For many years and built long term win-win relationship.
UPSCALE raw material, Thick layer hot galvanized steel tubing and best quality PVC fabric with 10 YEARS warranty. Professional engineer team with 20 years experience, fast response to customer request on new models in 24 hours. ISO 9001: 2008 standard Quality Control System, from the raw material to the final packaging quality is strictly guaranteed. Directly Factory Wholesale Price to all customers, Maximum save your cost and be most competitive in your market.
For more information, please contact us now! !
