| Prod Model: |
FSF-160W |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Power: |
160W |
| Cell: |
Mono |
| Type: |
Foldable |
| Weight: |
10kg |
| Efficiency: |
15.6% |
| Brand: |
Flagsun |
| Package: |
2PCS/Carton |
| Application: |
Commercial |
| Specification: |
Normal |
Product Description
Flagsun folding module kits are designed to provide portable 12 volt power wherever you need it.PoPwer available from 20W to 240W
Features:
· Padded, moulded carry bag
· Heavy duty carry handle, hinges and clasps Stainless steel telescopic&adjustable legs
· Weatherproof solar charge controller with LED indicator
· 5m cable with heavy duty Anderson connectors between module-regulator & regulator-battery clamps
· All cabled up ready to use
· 2 year warranty
These kits are the ideal solution for 4WD, camping, caravaning, boating and recreational activities wherever power is required for lights, small TV, camping fridge, pump or other small appliances.
| Type | Folding solar panel 120W/160W/180W |
| Rating Voltage | 12V |
| Max.Input Power | 120W | 160W | 180W |
| Current | Discharge | 10A |
| Charge | 10A |
| Charge | Equalized/Floating Charge | 14.4V/13.8V +/-1% |
| Resume | 13.3V/13.5V +/-1% |
| Temperature Compensation | -18mV/ |
| Start voltage |
| 12.3V +/-1% |
| Over discharge | Shut off | 11.1V +/-1% |
| Resume | 13.2V +/-1% |
| Over Voltage | Shut off | 16.5V +/-1% |
| Resume | 15V +/-1% |
| No-load current | <5mA | <10mA |
| Display | Digital display tube |
| Voltage of light open | <2V +/-1% |
| Voltage of light shut | >7V +/-1% |
| Max.open-circuit voltage | 25V |
| voltage drop | input<0.4v |
| Output <0.2v |
| Working temperature | -25 °C ~55 °C IP65 |
| Height | <5500m(more than 2000m need reduce the power use |
| Size & Weight | 120mm*80mm*25mm 0.13kg |
Suitable for
?Caravan/Motorhome
?Camping
?Farm Charger
?12V fridges
?Lights
?TV's & DVD's
?Inverters to run 240v appliances
?Set up anywhere
?Easy to use
?Ready to go.
Kit Inclusions
?1xFolading solar panel-(Pre wired and ready to go)
?12/24V DC Regulator & Solar Charger
?5m cable with Aligator clips.(anderson plug to battery clamps avaolable for purchase separately) also included is a carry bag.
?Operation manual .
