Curtain Wall

Name: Curtain Wall
Brand: FullPackage
SKU: 820570045
Availability: InStock
Rating: 4.9 (111 reviews)

Price:	US $ 2700/Ton
Min Order:	10/Ton
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	CW011
HS Code:	761090000
Application:	Transportation Tools
Shape:	Flat
Grade:	6000 Series
Temper:	T3-T8
Window & Door Aluminium Profile:	60 Series
Alloy:	Alloy
Surface Finishing:	Powder Spraying
Alloying Ingredient:	6061
Certification:	ISO
Polished Aluminum Profile:	Chemical Polishing

Product Description

Aluminum PVDF Profile

(1). Suitable for aluminium curtain wall.

(2). 20 years warranty.

(3). High corrosion resistance.

(4). 5-10 years weather resistance.

(5). Good wear resistance & anti-scratch.

(6).Size customized.

More Information:

1.Material: Aluminium alloy 6063, 6061.
2.Temper: T5, T6.
3.Quality standard: DIN; AAMA; AS/NZS; CHINAGB.
4.Surface treatment: Mill finish, anodized, powder coated, wood grain, polished, brushed, electrophoresis, etc.
5.Color avalilable: Anyone is available based on your color samples.
6.Packing details: Shrinking film; Plastic & kraft paper; Wooden pallet
Carton packing; By customer's requirements.
7.Samples Time: Normally, 2-3 weeks.
8.Delivery: 25-30 days for mass production.
9.Production Capacity: 6000MT/Month
10.MOQ: It's based on the drawings. Basically, it's 2 tons.
11.Port: Fuzhou; Xiamen; Shanghai; Guangzhou; As per requested.

Aluminum/Aluminium Extrusion Profiles for Construction/Decoration/Industrial

What We Can Do

Alloy:	6063	6061	6060	6005	6082	6463	7075
Temper :	T5	T6	T4
Standard:	DIN	AAMA	AS	CHINAGB
Certification:	ISO9001: 2008.
Surface Finish:	Mill finish	Anodizing	Powder Coating	Wood Grain	Electrophoresis	Polished	Brushed
Color:	Anodizing:	Silver, bronze, champagne, titanium, nickel, golden yellow, etc.
		Anodizing thickness is up to 25um.
	Powder Coating:	White, black, bronze, grey, green, etc .
		Powder coating thickness is more than 60um.
	Wood Grain:	1. Italian MENPHIS transfer printing paper.
		2. AKZO NOBEL INTERPON D1010(10 years warranty): Australia ceder, Bush cherry, Chest nut, Jarrah I, Jarrah II, Western red ceder, etc.
		3. AKZO NOBEL INTERPON D34(5 years warranty): Bush wood, Western red, Jarrah, Snow gum, etc.
	Electrophoresis:	Silver, nickel, golden yellow, black, champagne, etc
	Polishing	Silver, nickel, golden yellow, black, etc
	Brushing:	Silver, nickel, golden yellow, black, bronze, etc
Machining:	Cutting, punching, drilling, bending, weld, mill, CNC, etc.
OEM customized aluminium profiles are available.

TABLE OF CHEMICAL COMPOSITION OF ALUMINUM ALLOY
Alloy	Si	Mg	Fe	Cu	Mn	Zn	Cr	Ti	Impurity		Al
Alloy	Si	Mg	Fe	Cu	Mn	Zn	Cr	Ti	Unit	Total	Al
6063	0.2-0.6	0.45-0.9	< 0.35	< 0.1	< 0.1	< 0.1	< 0.1	< 0.1	< 0.05	< 0.15	Surplus
6061	0.4-0.8	0.8-1.2	< 0.7	0.15-0.4	< 0.15	< 0.25	0.04-0.35	< 0.15	< 0.05	< 0.15	Surplus
6060	0.3-0.6	0.35-0.6	0.1-0.3	≤0.1	≤0.1	≤0.15	≤0.05	< 0.1	< 0.05	< 0.15	Surplus

ADODIZINMG QUALITY
Grade	corrosion resistance			abrasive resistance
	CASS test		alkaline dropping test	sandtrial Abrasion coefficient f,g/um
	hours	grade	alkaline dropping test	sandtrial Abrasion coefficient f,g/um
AA10	16	≥ 9	≥ 50	≥ 300
AA15	32	≥ 9	≥ 75	≥ 300
AA20	56	≥ 9	≥ 100	≥ 300
AA25	72	≥ 9	≥ 125	≥ 300

POWDER COATING QUALITY
Gloss values	Thickness(um)		color variation	indentation resistance	adhesion	impact resistance	cupping test
	Max Thickness	Min Thickness
60	≤ 120	≥ 40	Color should be consistent with the sample color	≥ 80	0	No cracking and shedding phenomenon after the front impact test,small fine lines around the concave is allowed	No cracking and shedding phenomenon after the cupping test ( 6mm indentation depth )

Our Advantages!

1. 22 years' experiences of manufacturing, 12 years' exporting experiences as ALIBABA GOLDEN SUPPLIER.
2. STRONG R&D: Help customers finalize the design, strong tool design ability,excellent pressing and surface treament technology.
3.Strict quality management: ISO Administration system.
4. 24 hours on-line communication.Professional, Patient, Flexible.
5. High capacity of manufaturing and wide range of products.
6. Be able to provide secondary fabricating.
7. Small order isaccepted.
8. Be able to provide one-stop supply solution.
9. Multiple payment methods: TT, LC. DP,OA.

FAQ to Save Your Precious Time!

Q1: What's the thickness for anodizing? Can you do 15um?
A: Our normal thickness is about 10 um. Yes, we can do 15um and above.

Q2: What color you can do for powder coating? The thickness for powder coat?
A: We can do any color for powder coat as long as you can provide the color sample. Our normally powder coating thickness is 60-80um.

Q3: What color you can do for wood grain?
A: Our most popular colors are Western Red Cedar, Australia Cedar, Jarrah I, Jarrah II, Chestnut, Bush Cherry, Bush Wood, Western Wood, Snow Gum, etc. If you need any other colors, we can do according to the color samples you provide.

Q4: How's the weather resistance for wood grain finish D1010?
A: (1). Powder: Akzo Noble Interpon D1010.
(2). Wood grain film: Italian Menphis.
(3). Standard complied: American AAMA Standard.2603
(4). UV test:1000 hours.
(5). Salt spraying test:1000 hours.
(6). Normal weather: 10 years color guarantee.

Q5: What's the payment terms?
A: Usually by T/T, 30% deposit and the balance paid before shipment.

Q6: What certification do you have? What's your standard?
A: We have ISO certification. Our standard is DIN, AAMA, AS/NZS, China GB.

Q7: What's the delivery time for samples and mass production?
A: (1). 2-3 weeks to open the new moulds and make free samples.
(2). 3-4 weeks after receipt of deposit and confirmation of the order.

Q8: What's the packing way?
A: Commonly we use plastic film and kraft paper, also we can make as per customers' requirements.

Zhaoqing Asia aluminum factory co. Ltd. Is one of the largest aluminum profile manufacturers in Asia. Since IT was founded in 1991, the company has been committed to high, refined, sharp aluminum extrusion profile design and manufacturing, through years of unremitting efforts and insisted that the aluminium products from a single building doors and Windows, curtain wall aluminum expanded to include all kinds of industrial profiles, aerospace, rail transportation, automobile manufacturing, electronic appliances, communication technology, IT and other areas, products all over the world.

With the continuous development of the company and grow, in 2007, the company by the foshan big drain the overall move to zhaoqing flourishing national high and new technology industrial development zone and the aluminum industrial city, and officially changed its name to zhaoqing Asia aluminum Co., Ltd., at the same time, in order to ensure product quality and production efficiency, the company spent heavily to update and increased more than from the mold to squeeze until the surface treatment of imported automation equipment, annual production capacity of up to 400000 metric tons, become the industry leader.

Over the years, the aluminum with a good leadership team, high-quality staff, modern management mode, excellent technology, scientific production process control and strict quality testing, already became the Chinese and foreign aluminum industry production capacity is strong, the product series is complete, quality management, first-class production base of aluminum, can in the shortest production cycle to provide clients with the most sophisticated aluminum products. Its stable product quality and comprehensive after-sales service, won the universal praise, stir and set up in dubai, sailing hotel, the building such as the bird's nest, water cube and the national grand theater of a large number of landmarks.

Outstanding product quality and excellent enterprise management also win various awards from local to national and international. In 2007, the company successfully passed the GJB9001B military system certification and became one of the first three companies to adopt this system in the aluminum profile industry. At the same time, the company's "south" brand trademark was awarded "China well-known trademark", "south" brand aluminum products has won "top ten brand of Chinese aluminum", "China aluminum top ten enterprises" and other honorary titles.

1991: Established in Nanhai, Guangdong

1992: Designated supplier of window, door and curtain Wall profiles for National Construction Department.

2001: Mergers and acquisitions of several factories makes it become one of the largest aluminum profiles manufacturers.

2003: Honored as ' Top 10 Aluminum profiles enterprise', first time shown on Forbes' list of top 200.

2004: Honored as ' China Famous Brand Products'.

2005: With annual output over 150, 000 tons making it the largest in China, top 5 in the world. Certified by car and military profiles authority.

2007: Industry city is established, annual output is over 200, 000 tons. Finished the Burj Khalifa Project( highest in the world).

2009: Successful strategic recombination, support of banks, Asiaalum enters its new century.

2011: Certified by DNV Classification Society, the largest anodizing line is set up.

2012: Certified by National Lab(CNAS).

2013: Honored as ' Most Powerful Window, Door, Curtain Wall Aluminum Profiles Enterprise in Chinese Construction Industry'.

2015: Joint venture with Guangtou Group, establish Guangyin Asiaalum.

2016: Top 10 famous construction profiles brand, national good faith demonstration enterprise.
