| Price: | US $ 48-50/Roll |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 1/Roll |
| Pay Type: | L/C,T/T,D/P |
| Prod Model: | 1mm - 7mm |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Thickness: | 1mm - 7mm |
| Length: | 50m |
| Color: | as Request |
| Character: | Super Smooth |
| Position: | Door |
| Stick: | No |
| Bubble: | No |
| Open Styles: | Swing |
| Certificate: | Yes |
| Application: | Door,Cafe,Warehouse |
| Usage: | Hospital |
| Material: | PVC |
| Location: | Door |
| Pattern: | Plain |
| Style: | Plain Dyed |
| Type: | Vertical Blind |
| Composition: | Curtain Hook |
| Certification: | SGS |
| Width: | 100mm - 500mm |
Performance Test | Method: B S 2782 | PVC strip curtain Standard Clear Formula P.35 Value | PVC strip curtain Super Cold Formula P.45 Value | Unit |
Relative Density | DIN 53 479 | ~1.22 | ~1.19 | g/cm3 |
Softness A Hardness | DIN 53 505 | 77 | 63 | - |
Brittle Point | DIN 53 372 | Approx -35 | Approx -45 | Degrees C |
Falling Ball Test | Internal Test | "-35 No Break | "-45 No Break | Degrees C |
Flexibility | DIN 51 949 | "-35 No Break | "-45 No Break | Degrees C |
Water Absorption | DIN 53 472 | 17 | 21 | Mg |
Tensile Strength | DIN 53 455 | 17 | 13 | Mpa |
Tensile Stress | DIN 53 455 | 300 | 420 | % |
Rupture Resistance | DIN 53 515 | >5 | >2 | N/mm |
Reaction to Fire | DIN 53 382 | Self-extinguishing | Self-extinguishing | 0 |
Flammability | Based US MV SS 302 | Inflammable | Inflammable | 0 |
Airborne Insulation | DIN 52 210 | ~30 dB | 0 | 0 |
Light Transmission | - | >80 | >80 | % |
