| Prod Model: |
SS-600/800 |
| Punch: |
Customized |
| Handle: |
Customized |
| Material: |
PP PE Pet |
| Usage: |
Garment Bag,Packing Bag |
| Computerized: |
Computerized |
| Type: |
Plastic Bag Making Machine |
| Product Line: |
Bag Making Machine |
| Machine Type: |
Sealing and Cutting Machine |
Product Description
Feature 1.This machine uses fully automatic servo motor with computer digital function to control length, it is easy for operation.The produced one is very tight and fast at the seals,it apparently shows a good quality.2.Flow process of production is from rolled material through automatic edge alignment,edge trimming,strip piercing,laminating,ultrasonic compressive embossing,photo cell sensing,hole punching,thermo cuttingoff and ends with automatic counting,all of the operations are fully automatic.3.This machine equips automatic stop equipment,it will work to stop the machine when it is running out of material supply or when photo cell is out of order or when temperature is losing down and below the minimum required.Technical parameter:Machine model | Model type | SS-600 | SS-800 |
| Materlal | LDPE-PP-PPE | LDPE-PP-PPE |
| Sealing and cutting Width | 100~500mm | 120~600mm |
| Sealing and cutting Length | 120~600mm | 150~800mm |
| Sealing and cutting Thickness | 0.04~0.15mm | 0.04~0.15mm |
| Bag-Making Speed | 50~150(pcs/min) | 50~150(pcs/min) |
| Film annulus diamete | Φ500×1200mm | Φ500×1600mm |
| Step motor | 1KW | 1KW |
| Transducer mo | tor1.5KW | 2.2KW |
| Heater | 3KW | 3.5KW |
| Food-out motor | 0.25kw | 0.37kw |
| Ultrasonic | 1set | 1set |
| Conveying electrica | 0.55kw | 0.75kw |
| Fold film motor | 0.55kw | 0.75kw |
| Sealing capacity | 10~30m/min | 10~30m/min |
| Cooling | 0.37kw | 0.37kw |
| Machine Power | 15KW | 17KW |
| power supply | 50Hz 220v | 50Hz 220v |
| Overall Dimensions (L×W×H) | 2000×1900×1700 | 2100×2000×1700 |
| 1800×1700×1900 | 1900×1800×1900 |
| 1600×800×1000 | 1600×800×1000 |
| 4200×1400×1800 | 4300×1600×1800 |
After services:
1. How long will your engineer reach our factory?
Within one week after machine arrival your factory.
2. How many days will you finish installing?
We will finish installation and training within 15days.
3. What should we charge for your engineer?
You should charge for the cost of our engineer's visa, air tickets, hotel, food, and also their salary 50USD one day per person.
4. How long is your machine's warranty period?
All our machine have one year guarantee, starting from finished installation.
5. How could we do after one year warranty period?
We also can do service for you, but you need pay salary for my technician 80USD/day.
6. How could we do if the parts broken within warranty?
We would express the free replacement parts during the warranty date.
7. Does your engineer understand English?
Our engineers understand a little English. All of our engineer have more than five years machine installation experience. In addition, they can use body language to communicate with customer.
8. Can you help us find any engineer in our location?
Of course, we will check and inform you as soon as possible.
