Yantai Youcheng Printing Facilities Co., Ltd. >> Korean 14 Color Screen Printing Oval Press

Korean 14 Color Screen Printing Oval Press

Korean 14 Color Screen Printing Oval Press
Price: US $ 70000/Piece
Min Order: 1/Piece
Pay Type: L/C,T/T,D/P,Western Union,Paypal
Prod Model: YC-OPK1448
Printing Head: 14 Color
Printing Size: 500X700mm
Platen Size: 600X800mm
Platen Quantity: 48 PCS
Platen Material: Aluminum
Dryer Power: 380V9kw
Drying Size: 500X700mm
Dryer Quantity: 14 Sets
Humidifier: 1
Power: 380V70kw
Type: Automatic Screen Printing Machine
Style: Screen-process Printing Press
Structure: Platen Press
Color & Page: 14 Color 48 Station
Application: Fabric Printing
Print Interface: Oval Screen Printer
System Supported: Youcheng OS

Product Description

Youcheng 14 Color 48 Station Automatic Oval Silk Screen Printer












Product Description



Application

It's suitable for printing t shirt ,garment and apparel tag, baby clothes, kid garment, underwear, swim cap,sock,gloves,napkin,pants, hoody, non-woven fabric, textile, umbrella, acrylic, leather etc



Main Feature

1.PLC controlled,user friendly interface,clear function display and easy operation

2.Flat screen printing with infrared drying system.Suitable for different types of ink (water based, pigment, plastisol based, sillicone , pvc, hot-set etc )and all size( big size such  as bed sheet and curtain) small area screen frame printing such as T-shirt collar and tags

3.Our rotaty t shirt screen printing machine is made in China, introduced by Korean technology, printing precision error is no more than 0.01mm, high printing precision with good quality .

4.Angle and height of squeegee and flood blade can be adjusted to insure consistent printing pressure according to your ink types.

5.Station/ Pallet/Table is driven by servo motor to insure stable and smooth running.

6.Fully automatic printing, only needs 2-3 persons to operate, saving labor cost .

7.It can rotate reversally and corotation rotate , which meet your different requirements; while our third generation printer can pnly rotate in one direction .

8. The guide rail improved much , we accept the imported rail from Taiwan , now it's rhombic shape instead of round rail, rhombic rail can fix the printing head firmly ,printing head won't shake , which decrease the printing error , also faster the capacity of printing .

9. Printing precision , the printing head is still , only the screen frame move up and down, so the printing precision is better than before , error is no more than 0.01mm.



Parameters

Printing head14 color
Printing size500x700mm
Platen size600x800mm
Platen quantity48 pcs
Platen materialAluminum
Dryer power380v9kw
Drying size500x700mm
Dryer quantity14 sets
Linear bearingTaiWan TBI
Printing motor200w JSCC
PLCTaiWan TaiDa
Touch screenTaiWan WeiLun 10 inch
Servo motorShenZhen ONK4.5kw
Air cylinderIndependent research and development
Positioning cylinderTianGong

Humidifier1 set
Power380v70kw
Weight5000kg



Our Advantage :

when the oval printing machine start work, the printing head is still,only the plated rotaty,so the speed is fast, also the high precision and the error is no more than 0.01mm

The important is that the space between the panels is big enough for the person could enter into the space between the panels to put the textiles, so more suitable for large size textile printing. And the panel size could could reach into 80cm*120cm\

The new developed oval screen printing machine could be foreard and inversion

The chain has elastic funtion and using life is 5 years.

The touch screen could be rotary.





Printed Samples







Our Services:



Pre-sale service:

- We provide presales service in various forms, for example, making investment budget, manufacturing, planning so that customers can make a reasonable plan with less cost.

- Investment budgeting: We provide services of product profit analysis,recommendation of machine and auxilian and relevant budgeting, human resources allocation and budgeting.

- Plant Planning: We provide the mounting dimension of the equipment base, design of equipment layout,workshop ventilation, water transmission etc.

- Offer information of peripherals

In-sale service:

1. Detailed design of lay-out that is the position of the procession

2. Technological information of provided products

3. Schedule about design, manufacturing and installation

4. Working & producing progression

5. Training course for the technician so that the installation is safe and standard

After-sale service:

- For customers buying our products, we provide them free training so that they can use and maintain the machine independently.

- We will answer customer's question on technology in time. If needed, we will offer on-site guidance and assist

- We can provide free technical guidance if customers need new equipment, add or rebuild equipment.

- We will prioritize the product upgrade of former customers.



Our Company Competitive Advantage :

1: with 15 years specializing manufacturing screen printing machine

2: we are a China-Korea jointed venture , our printing machines are made in China-Korea, core technology is introduced frm Korea, printing precision is very high , error is no more than 0.01mm .

3: Compared with MR and MHM great brand , our printer price is more reasonable and we always update our machines with our R&D department to meet the lastest requirements for our customer.

4: We have the biggest share in Asia market , especially in Viet Nam , Indonesia , Cambodia, India , Indonesia etc

5: All our printers have CE Certificate , exported to many Europe and Asia countries such as Netherlands, Poland, Russia, Japan, Korea, Viet Nam ,Cambodia , Indonesia, India, Turkey , Pakistan etc



    YANTAI YOUCHENG PRINTIING FACILITIES CO.,LTD   was founded in 2002 as the international manufacturer of screenprinting machine,dryer,stretching machine etc.Our machine are made in China, while high-technology is introduced from South Korea. Advanced PLC control system , providing powerful and convenient automatic operationg procesures , precise servo motor , accurate positioning device , frequency converter ensure whole printer rotating smoothly , positioning accurately and printing preciselyYoucheng are always being popular among the customers  for its superiaor quality and full after-sale service.Youcheng continue to improve our standard of customers and technology. Welcome to contact us for further information.



    1).Quality warranty: one years after sale.After that we still have responsibility to repaire the machine,but it need pay for.
    3).We will match include quick-wear part for you,such as parts of cylinder,power swith ect.

Youcheng Screen Printing Facility Co., Ltd. (Yantai ), have been in manufacturing the textile and garment printer field for 15 years, main products are screen printing machine, clothes dryer, heat press machine, exposure machine and mesh stretching machine.

All our machine are made in China-Korea, printing precision is very high, no more than 0.01mm with the technology from Korea, and main parts imported from Korea, Japan and Taiwan. With CE Certificate, our screen printers apply to print all kinds of T shirt, cloth sheets, non-woven fabric, baby diaper, umbrella, foam board, leather, PU, acrylic, socks, gloves, bag, flag and so on.

Our products are warmly welcome home and abroad, exported to Netherlands, Poland, Russia, Japan, Korea, India, Indonesia, Thailand, Vietnam, Cambodia, Uzbekistan, Belgium, Italy, Turkey, South Africa, UAE and so on.

Our Company Competitive Advantage:

1: With 15 years specializing manufacturing screen printing machine

2: We are a China-Korea jointed venture, our printing machines are made in China-Korea, core technology is introduced frm Korea, printing precision is very high, error is no more than 0.01mm.

3: Compared with MR and MHM great brand, our printer price is more reasonable and we always update our machines with our R&D department to meet the latest requirements for our customer.

4: We have the biggest share in Asia market, especially in Viet Nam, Indonesia, Cambodia, India, Indonesia etc

5: All our printers have CE Certificate, exported to many Europe and Asia countries such as Netherlands, Poland, Russia, Japan, Korea, Viet Nam, Cambodia, Indonesia, India, Turkey, Pakistan etc
