| Prod Model: |
FS-X8 |
| Cylinder Diameter: |
13" 14" 15" 16" 17" |
| Weight: |
700kg |
| Type: |
Circular |
| Knitting Product Type: |
Underwear |
| Knitting Style: |
Warp |
| Knitting Method: |
Single |
| Computerized: |
Computerized |
| Certification: |
ISO9001: 2000 |
| Condition: |
New |
| Needle Style: |
Jacquard |
Product Description
Product Type: FS-X8(8FEED) FS-X12(12FEED)
FS-X8 Seamless underwear machine,Each is equipped with 16pcs Needle selector ; FS-X12 seamless underwear machines , each with 24pcs Needle selector ; can use natural fibers, synthetic fibers, rayon, nude spandex ,covered yarn etc,,,raw materials production single face garment, The main production of underwear , outerwear , sportswear, medical uses , such as clothing , if necessary, can also produce terry products.
FS-X8 FS-X12 series of seamless underwear machine designed from the beginning to fully study the various advantages and disadvantages of imported equipment , the integration of the characteristics of imported machinery , fully consider the needs of the market as well as on-site sampling conditions , improved conditions and optimized design features to improve product applicability , reliability and usability within .
Caliber ,machine number, parameter
Syringe Caliber
Needles
parameter | 12" | 13" | 14" | 15" | 16" | 17" | |
| 28 | 1056 | 1152 | 1248 | 1344 | 1440 | 1536 | |
| 26 | 960 | 1056 | 1152 | 1248 | 1344 | 1440 | |
Function parameters
| machine number | FS-X8 | FS-X12 |
| Syringe Caliber | 12" 13" 14" 15" 16" 17" |
| feed | 8feed | 12feed |
| speed | 80rpm |
| needle pitch | 12-32G |
| Needle selector | Each feed 2pcs,16pcs | 24pcs |
| yarn feeder | Each feed 9pcs yarn feeder, Can any jacquard , can complete single multicolor knit |
| Yarn Clamps | 4,8feed double yarn clamps, other single yarn clamps |
| The nose lifting | Pneumatic and jog lift |
| Fabric density | Stepper motor control can be realized 3D knit |
| Traction system | Using ventilation system conducted stretch |
| Yarn break induction | Using infrared sensor alarm |
| Yarn racks | Floor racks and top racks two parts |
| Lubricating | Automatic timing , quantitative refueling |
| Power outages technology | Support for power protection, maintaining the status quo shutdown , power continued weaving, lower defect rate |
| Tying technology | Using Huff knitting needles can choose single or multiple double- lined elastic waist edge organization |
| Terry | According to the customer's needs to increase terry function configuration ( optional ) |
Zhuji hanjing Trade Co., Ltd was incorporated in 2014 in Zhuji, Zhejiang, is approved by the State Administration for Industry and export-oriented enterprises.
Hanjing trade Co., Ltd., owns several knitting machinery factory, the factory main production socks knitting machinery, stocking knitting machine, seamless underwear knitting machine and machine computer control system, Needle selection device etc...At the same time, we mainly provide export agent and consulting services.
At present, our customers are all over the world. The Americas region includes Argentina, Brazil, Ecuador, and Mexico. Asia has Vietnam, India, Russia, Kazakhstan and so on. Europe Middle East, Egypt, Syria, Lebanon, Turkey and so on.
