Price: | US $ 160/Square Meter |
---|---|
Min Order: | 1000/Square Meter |
Pay Type: | L/C,T/T,D/P,Western Union,Paypal |
Prod Model: | JB-SM01 |
---|---|
Shape: | Flat |
Appearance: | Flat Tempered |
Standard: | GB 1216-85 |
Steel Degree: | Tempered Glass |
Thickness Of Flat Tempered Glass: | 5MM |
Thickness Of Curve Tempered Glass: | 5MM |
Fragment State: | I |
Technics: | Physically Tempered |
Flatness: | High Class |
Usage: | Military |
switchable smart glass film introduction:
Smart glass, also named as Privacy Glass or Switchable Transparent Glass ( STG ),
is an intelligent high function glass, which has a special characteristic of changing between clear and opaque by voltage control.
With such a function, Smart glass meets people's double requirements of light transmission and protecting privacy
switchable smart glass film Function
Privacy protection. As most important function, smart glass can be changed from
transparent to opaque via easy model ON & OFF.
Perfect function of safety. As smart glass is a special kind of laminated glass, it has
all the good function of the laminated glass, mainly the security.
Blocks more than 99% UV rays ,avoiding fading in the room.
Sound proof. With excellent damping action, the smart glass is easy to block the
noise.
Projection. Smart glass is a good projection screen. When it is under suit light,
the perfect projection appears.
Optical Properties | Parallel Light Transmission | ON | >81% |
OFF | <10% | ||
Visible Light Transmission | ON | >80% | |
OFF | < 5% | ||
Visual Angle | ON | 150 degree | |
UV Blocking | ON/OFF | >97% | |
Electrical Properties | Operating Voltage | ON | 48 volts A.C. |
Frequency | ON | 50~60HZ | |
Current | ON | 2 mA/sqm | |
Power Consumption | ON | 8 W/sqm | |
Switching Time | ON==>OFF | Tr.2ms | |
OFF==>ON | Td.10ms | ||
Specification | Thickness | 0.4mm | |
Max Size | 1524mm x 3048mm | ||
Color | milky white and brown | ||
Other index | Working Temperature | -30~80 °C | |
Life time | > 50000 hr |
