| Price: | US $ 0.8/Piece |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 1000/Piece |
| Pay Type: | L/C,T/T,D/P,Paypal,Money Gram |
| Prod Model: | Magforever |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Composition: | NdFeB Magnet |
| Certification: | RoHS |
| Sample: | Free |
| Delivery: | 25-40days |
| OEM: | Yes |
| Size: | OEM |
| Environment: | ISO9001: 2000; SGS |
| Application: | Speaker Magnet, Solenoid, Motor Magnet, Industrial Magnet |
| Coating: | Zinc |
| Grade: | N35 |
| Type: | Permanent |
| Shape: | Coil |
| Technical Specifications of Sintered Neodymium Magnet | |||||
| Grade | Remanence Br mT (KG) | Coercive Force Hcb KA/m (KOe) | Intrinsic Coercive Force Hcj KA/m (KOe) | Maximum Energy Product BHmax KJ/m3 (MGOe) | Maximum Operating Temperature Tw ºC |
| N35 | 1170-1220(11.7-12.2) | ≥868(≥10.9) | ≥955(≥12) | 263-287(33-36) | 80ºC |
| N38 | 1220-1250(12.2-12.5) | ≥899(≥11.3) | ≥955(≥12) | 287-310(36-39) | 80ºC |
| N40 | 1250-1280(12.5-12.8) | ≥907(≥11.4) | ≥955(≥12) | 302-326(38-41) | 80ºC |
| N42 | 1280-1320(12.8-13.2) | ≥915(≥11.5) | ≥955(≥12) | 318-342(40-43) | 80ºC |
| N45 | 1320-1380(13.2-13.8) | ≥923(≥11.6) | ≥955(≥12) | 342-366(43-46) | 80ºC |
| N48 | 1380-1420(13.8-14.2) | ≥923(≥11.6) | ≥876(≥12) | 366-390(46-49) | 80ºC |
| N50 | 1400-1450(14.0-14.5) | ≥796(≥10.0) | ≥876(≥11) | 382-406(48-51) | 60ºC |
| N52 | 1430-1480(14.3-14.8) | ≥796(≥10.0) | ≥876(≥11) | 398-422(50-53) | 60ºC |
| 35M | 1170-1220(11.7-12.2) | ≥868(≥10.9) | ≥1114(≥14) | 263-287(33-36) | 100ºC |
| 38M | 1220-1250(12.2-12.5) | ≥899(≥11.3) | ≥1114(≥14) | 287-310(36-39) | 100ºC |
| 40M | 1250-1280(12.5-12.8) | ≥923(≥11.6) | ≥1114(≥14) | 302-326(38-40) | 100ºC |
| 42M | 1280-1320(12.8-13.2) | ≥955(≥12.0) | ≥1114(≥14) | 318-342(40-43) | 100ºC |
| 45M | 1320-1380(13.2-13.8) | ≥955(≥12.5) | ≥1114(≥14) | 342-366(43-46) | 100ºC |
| 48M | 1360-1430(13.6-14.3) | ≥1027(≥12.9) | ≥1114(≥14) | 366-390(46-49) | 100ºC |
| 50M | 1400-1450(14.0-14.5) | ≥10339(≥13.0) | ≥1114(≥14) | 382-406(48-51) | 100ºC |
| 35H | 1170-1220(11.7-12.2) | ≥868(≥10.9) | ≥1353(≥17) | 263-287(33-36) | 120ºC |
| 38H | 1220-1250(12.2912.5) | ≥899(≥11.3) | ≥1353(≥17) | 287-310(36-39) | 120ºC |
| 40H | 1250-1280(12.8-12.8) | ≥923(≥11.6) | ≥1353(≥17) | 302-326(38-41) | 120ºC |
| 42H | 1280-1320(12.8-13.2) | ≥955(≥12.0) | ≥1353(≥17) | 318-342(40-43) | 120ºC |
| 45H | 1300-1360(13.0-13.6) | ≥963(≥12.1) | ≥1353(≥17) | 326-358(43-460 | 120ºC |
| 48H | 1370-1430(13.7-14.3) | ≥955(≥12.5) | ≥1353(≥17) | 366-390(46-49) | 120ºC |
| 35SH | 1170-1220(11.7-12.2) | ≥876(≥11.0) | ≥1592(≥20) | 263-287(33-36) | 150ºC |
| 38SH | 1220-1250(12.2-12.5) | ≥907(≥11.4) | ≥1592(≥20) | 287-310(36-39) | 150ºC |
| 40SH | 1240-1280(12.5-12.8) | ≥939(≥11.8) | ≥1592(≥20) | 302-326(38-41) | 150ºC |
| 42SH | 1280-1320(12.8-13.2) | ≥987(≥12.4) | ≥1592(≥20) | 318-342(40-43) | 150ºC |
| 45SH | 1320-1380(13.2-13.8) | ≥1003(≥12.6) | ≥1592(≥20) | 342-366(43-46) | 150ºC |
| 30UH | 1080-1130(10.8-11.3) | ≥812(≥10.2) | ≥1990(≥25) | 223-247(28-31) | 180ºC |
| 33UH | 1130-1170(11.3-11.7) | ≥852(≥10.7) | ≥1990(≥25) | 247-271(31-34) | 180ºC |
| 35UH | 1180-1220(11.8-12.2) | ≥860(≥10.8) | ≥1990(≥25) | 263-287(33-36) | 180ºC |
| 38UH | 1220-1250(12.2-12.5) | ≥876(≥11.0) | ≥1990(≥25) | 287-310(36-39) | 180ºC |
| 40UH | 1240-1280(12.5-12.8) | ≥899(≥11.3) | ≥1990(≥25) | 302-326(38-41) | 180ºC |
| 28EH | 1040-1090(10.4-10.9) | ≥780(≥9.8) | ≥2388(≥30) | 207-231(26-29) | 200ºC |
| 30EH | 1080-1130(10.8-11.3) | ≥812(≥10.2) | ≥2388(≥30) | 223-247(28-31) | 200ºC |
| 33EH | 1130-1170(11.3-11.7) | ≥836(≥10.5) | ≥2388(≥30) | 247-271(31-34) | 200ºC |
| 35EH | 1170-1220(11.7-12.2) | ≥876(≥11.0) | ≥2388(≥30) | 263-287(33-36) | 200ºC |
| 38EH | 1220-1250(12.2-12.5) | ≥899(≥11.3) | ≥2388(≥30) | 287-310(36-39) | 200ºC |
| 28AH | 1020-1080(10.2-10.8) | ≥780(≥9.8) | ≥2704(≥34) | 199-231(25-29) | 240ºC |
| 30AH | 1020-1080(10.2-10.8) | ≥811(≥10.2) | ≥2704(≥34) | 223-247(28-29) | 240ºC |
| N35T | 1170-1210(11.7-12.1) | ≥868(≥10.9) | ≥955(≥12) | 263-287(33-36) | 80ºC |
| N45T | 1320-1380(13.2-13.8) | ≥876(≥11.0) | ≥955(≥12) | 342-366(43-46) | 80ºC |
| N48T | 1380-1420(13.8-14.2) | ≥836(≥10.5) | ≥876(≥11) | 366-390(46-49) | 80ºC |
| 35MT | 1170-1210(11.7-12.1) | ≥868(≥10.9) | ≥1114(≥14) | 263-287(33-36) | 100ºC |
| 45MT | 1320-1380(13.2-13.8) | ≥995(≥12.5) | ≥1114(≥14) | 342-366(43-46) | 100ºC |
| 38HT | 1210-1250(12.1-12.5) | ≥899(≥11.3) | ≥1353(≥17) | 287-310(36-39) | 120ºC |
| 40HT | 1240-1280(12.4-12.8) | ≥923(≥11.6) | ≥1353(≥17) | 302-326(38-41) | 120ºC |
| 45HT | 1320-1380(13.2-13.8) | ≥995(≥12.5) | ≥1353(≥16) | 342-366(43-46) | 120ºC |
| 35SHT | 1170-1210(11.7-12.1) | ≥876(≥11.0) | ≥1592(≥20) | 263-287(33-36) | 150ºC |
| 38SHT | 1210-1250(12.1-12.5) | ≥907(≥11.4) | ≥192(≥20) | 287-310(36-39) | 150ºC |
| 42SHT | 1280-1320(12.8-13.2) | ≥995(≥12.5) | ≥1592(≥20) | 318-342(40-43) | 150ºC |
| L-30SHT | 1080-1130(10.8-11.3) | ≥804(≥10.1) | ≥1592(≥20) | 223-247(28-31) | 150ºC |
| L-33SHT | 1130-1170(11.3-11.7) | ≥844(≥10.6) | ≥1592(≥20) | 247-271(31-34) | 150ºC |
| L-35SHT | 1170-1210(11.7-12.1) | ≥876(≥111.0) | ≥1592(≥20) | 263-287(33-36) | 150ºC |
| L-38SHT | 1210-1250(12.1-12.5) | ≥907(≥11.4) | ≥1592(≥20) | 287-310(36-39) | 150ºC |
| L-30UHT | 1080-1130(10.8-11.3) | ≥812(≥10.2) | ≥1990(≥25) | 223-247(28-31) | 180ºC |
| L-33UHT | 1130-1170(11.3-11.7) | ≥852(≥10.7) | ≥1990(≥25) | 247-271(31-34) | 180ºC |
| L-38UHT | 1210-1250(12.1-12.5) | ≥907(≥11.4) | ≥1990(≥25) | 287-310(36-39) | 180ºC |
| L-30EHT | 1080-1130(10.8-11.3) | ≥812(≥10.2) | ≥2388(≥30) | 223-247(28-31) | 180ºC |
