Paper Making Felt, Paper Making Canvas, Paper Making Blanket
| Price: |
US $ 15-50/Roll |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Roll |
| Pay Type: |
L/C,T/T,D/P,Western Union,Money Gram |
| Prod Model: |
BOM |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Kind: |
Paper Making Press Felt |
Product Description
Using Method and Maintenance of Paper Making Felt
1. Compare specification, size and weight with required standard, if there is something wrong, please don't use it.
2. Find the facade with sign "The Side with Paper" before using, don't reverse it and operate it according to the arrow.
3. Wrap the top of oiled axle with plastic bag while fixing, don't be soiled with grease; if there is grease, please wash it with gas before operating.
4. The felt must be spread and sprinkled with water before pressing. When it is evenly wetted, strain it and slowly operate the machine.
5. Press the felt before adding paper. Meanwhile, soften the polyamide fiber of felt surface with soda water to improve its adaptability.
6. Adopt the way of double-sides sprinkling to wash felt. Adopt high pressure (5~20kgf/cm2)moving sprinkling pipe to wash the reverse side; and adopt frequent pressure(1~3 kgf/cm2)fan sprinkling to wash the obverse side.
7. In normal operation, the standard line is straight, if not, please correct to avoid affecting the quality. Correcting method: strain the front side of standard line according to the operating direction; soften the back of standard line. Adjust a little once until finding standard line is level and straight.
8. After used for a period, the felt should be washed regularly, and choose special detergent for different felt. Wash alkaline felt with acid detergent, acid one with alkaline detergent; neutral one with non-ion active detergent. To the special part, adopt the high-pressure water-gun to sprinkle.
Characteristics
1. Paper Making Felt of BOM High linear pressure comprehensive wire Bottom Web
Adopt single or more skein of high intensity industrial comprehensive wire as material, use special technology to weave single double or more layer basic cloth then deal with it by acupuncture and other special way.
This kind of felt has good permeability because of its special weaving way.
Comprehensive wire has characteristics of high intensity, non-distortion, easy to wash.
Comprehensive wire basic cloth has non-compression and good elasticity, resistance to high linear pressure, these are beneficial to improve the speed and increase the output.
BOM felt surface is smooth and thick, this is beneficial to improve the quality of paper.
High intensity, wear-resisting, and long service life of BOM felt are beneficial to reduce the cost of production.
2. Paper Making Felt without Felt Mark
Basic cloth is made from special material; the smooth surface is beneficial to reduce the difference of two sides.
Lint-free is beneficial to improve the quality of paper.
Good permeability, easy to wash, and long service life.
3. Paper Making Felt Dealt with Chemical
Some special properties have been added through dealing with special chemical characteristic.
Easy to wash, bad affinity between papermaking filler and fiber can prevent pollution. With strong wear-resisting and long service life, the chemical reaction makes the fiber integrate closely, forming wearing layer.
4. Polyester Shaping Web
Be made with special machine which has polyester wire of different diameter, including single and double layer. It features stable size, even space, smooth surface, wear-resisting and long lifetime.
Be used in shaping part of long-web machine and drying part of senior grade paper.
5. Polyester Special Dry Web
Be made with polyester wire of different diameter by winding ring, cutting, passing silk, shaping, trimming, and sealing side, etc.
Dry web features high temperature resistance, high intensity, wear-resisting, smooth surface and non-distortion, etc.
It is mainly used in drying part, shipping and filtering of other parts for making paper.
Our services
1. We will make the exact specifications as customer's requirements.
2. We have ten engineers waiting to help you solve the problems when using our mesh fabrics, belt
Images
| Name | No. | Structure | Weight/m | Characteristic | Scope of application |
| Top felt of BOM High Linear pressure bottom web | 1725 | Single layer, pure chemical fiber | 800-1000 | High intensity, low extension, high linear pressure, high speed, smooth surface, good permeability without felt mark | paper machine with round web, long web, more webs, more vats |
| 1625 | Single layer, high chemical fiber | 800-1000 |
| 1726 | Double-layer, pure chemical fiber | 1000-1200 |
| 1626 | Double-layer, high chemical fiber | 1000-1200 |
| 1724 | Three-layer, pure chemical fiber | 1200-1600 |
| 1624 | Three-layer, high chemical fiber | 1200-1600 |
| Wet felt of BOM High linear pressure bottom web | 2725 | Single layer bottom web (slender) | 700-900 | High warp tensile strength, high- linear pressure, good permeability, dewatering with high-speed, non-distortion, long service life | Paper machine with single web and vat, double webs and vats, more webs and vats, long webs, more vats |
| 3725 | Single layer bottom web (more slender) | 700-900 |
| 4725 | Single layer bottom web (common) | 700-900 |
| 2726 | Double-layer bottom web (slender) | 1000-1400 |
| 3726 | Double-layer bottom web (more slender) | 1000-1400 |
| 4726 | Double-layer bottom web (common) | 1000-1400 |
| 2724 | Three-layer bottom web (more slender) | 1300-1600 |
| 3724 | Three-layer bottom web (slender) | 1300-1600 |
| 4724 | Three-layer bottom web (common) | 1300-1600 |
Felt for Pulp Board of BOM High linear pressure
| 5725 | Single-layer bottom web | 700-900 | High warp tensile strength, good permeability, wear-resisting, stable property, long service life | Paper machine with more webs and more vats |
| 5726 | Double-layer bottom web | 1000-1400 |
| 5724 | Three-layer bottom web | 1300-1600 |
BOM Dry felt
| 6722
| Basic cloth with weft(pure chemical fiber)
Basic cloth with weft (high chemical fiber) | 1500-1800
| Stable size, smooth surface, good permeability, long service life | Drying part, all kinds of paper |
