Prod Model: |
SH85106 |
Name: |
Forming Fabrics |
Supply Type: |
Make-to-Order |
Wire Diameter Warp(mm): |
0.20 |
Wire Diameter Weft(mm): |
0.25 |
Density (Root/Cm) Warp: |
29 |
Density (Root/Cm) Weft: |
22 |
Tensile Strength :Surface: |
>=600 |
Thickness: |
0.41-0.87mm |
Permeability: |
7500+-500 |
Hole Shape: |
Square |
Application: |
Dustproof |
Type: |
Primary Filter |
Style: |
Filter |
Material: |
Polyester |
Product Description
Product description: Paper making polyester forming fabrics can be divided into 4-shed, 5-shed, 8-shed, 16-shed, 24-shed according to the weaving type. Single layer, double layer, two-and a half layer fabric and triple-layer fabric are the three common Items.
4-shed and 5-shed series single layer polyester forming fabrics are the two widely used polyester forming fabric in paper making, mainly used for producing cultural paper (single glue, double glue and color glue), printing paper, glazed paper, packing paper, common newsprint. Suitable for common fourdrinier paper machine.
8-shed single layer polyester forming fabric is suitable for kraft paper, cardboard , corrugated paper making. Also could be used for producing common printing paper. Suitable for common fourdrinier paper machine.
8-shed double layer fabric is suitable for producing quality printing paper. For example ,dictionary paper, offset printing paper, newsprint and wrap paper. It can be used for tissue paper making and the surface pulp, lining pulp, core pulp and bottom pulp of the board paper etc. Suitable for medium and high speed paper making machine.
16-shed double and a half layer polyester forming fabric is suitable for producing quality printing paper, such as offset printing paper, copper plate paper, newsprint and cigarette paper series (wrap paper and filter tips paper), Also is could be used for producing toilet paper, tissue paper and surface pulp, lining pulp, core pulp and bottom pulp of the board paper etc. Suitable for medium and high speed paper making machine.
Multi-shed three-layer fabric is suitable for producing quality printing paper, tissue paper and cigarette paper etc. Suitable for high speed paper making machine.SUN HONG Technician Department concentrates on providing the best design. Cost effective polyester forming fabric helps to get the best ending paper properties. The below data sheet comes from SUN HONG .
Let us know before you use it.We are willing to share the information with peers.
weaving Series / Types | Model NO. | warp | weft | surface strength(N/cm) | Air Permeability (m³/m²h) |
4-shed single layer fabric | SH85254 | 0.20 | 0.25 | ≥ 600 | 7500±500 |
SH85274 | 0.20 | 0.27 | ≥ 600 | 7600±500 |
SH85204 | 0.20 | 0.22 | ≥ 600 | 6500±500 |
5-shed single fabric | SH85255 | 0.20 | 0.25 | ≥ 600 | 7600±500 |
SH85285 | 0.22 | 0.28 | ≥ 500 | 7800±500 |
SH85205 | 0.20 | 0.21 | ≥ 600 | 6700±500 |
8-shed single layer fabric | SH8508 | 0.22 | 0.40 | ≥700 | 8500±500 |
SH87358 | 0.22 | 0.35 | ≥700 | 8500±500 |
8-shed double layer fabric | SH856188 | 0.17 | 0.19/0.22 | ≥850 | 6800±500 |
SH60188 | 0.18 | 0.18/0.20 | ≥900 | 5700±500 |
SH862188 | 0.15 | 0.16/0.17 | ≥900 | 8500±500 |
16-shed 2.5 layer fabric | SH85016 | 0.28 | 0.20,0.27/0.50,0.50 | ≥1200 | 8500±500 |
SH854516 | 0.25 | 0.20,0.25/0.45,0.45 | ≥1250 | 8000±500 |
SH852516 | 0.18 | 0.13,0.18/0.25,0.25 | ≥1500 | 6500±500 |
SH853516 | 0.20 | 0.13,0.25/0.35,0.35 | ≥1500 | 7000±500 |
SH872516 | 0.18 | 0.13,0.20/0.25,0.25 | ≥1500 | 6200±500 |
SH873516 | 0.20 | 0.13,0.25/0.35,0.35 | ≥1500 | 6300±500 |
20-shed triple layer fabric | SH853520 | 0.15,0.20 | 0.15,0.15/0.35,0.35 | ≥1600 | 500±500 |
24-shed triple layer fabric | SH854024 | 0.20,0.20 | 0.20,0.17/0.40,0.40 | ≥1600 | 6500±500 |
Packing and delivery1. Bubble Film and waste thick fabric wrapping while protecting inside fabric.
2. Wrapped special fabric package outside. (Air shipping )
3. Composite wooden box(seashipping )Our service1. Samples: free samples with detail specification for you to choose.
2. We will make the exact specifications as customer's requirements
3. Felt and fabric design solution will be provided within 24 hours By Technician Department.
4. There is a Strict quality control process during each production step. Ensuring the quality.
5. Regular customers visiting May and June each year. WHY CHOOSE US?1. High Quality-QUALITY raw Material,Advanced Facilities,Fine Procedures.
