Rich 30 Mesh High Quality Stainless Steel Wiremesh/ Cloth/ Netting

Name: Rich 30 Mesh High Quality Stainless Steel Wiremesh/ Cloth/ Netting
Brand: FullPackage
SKU: 799168655
Availability: InStock
Rating: 4.6 (20 reviews)

Price:	US $ 5/Square Meter
Min Order:	10/Square Meter
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	30 mesh high quality stainless steel wiremesh/ clo
Material:	SUS304
Hole Shape:	Square
Application:	Cages
Type:	Stainless Steel Plain Wire Mesh
Material Type:	Stainless Steel Wire
Weave Technique:	Twill Weave
Wire Mesh Width:	1.5m
Technique:	Woven
Nickels:	4%
Certification:	SGS

Product Description

Stainless steel wire mesh

Product Description

Material: common material: SUS 201 302 304 316 316L 310S

Meantime please add my info as bellow for convenient talk !

Olga

skpe:balice52

whats'app:86-15175871625

http://www.yc-wiremesh.com.

waiting for your prompt reply .

special material:410 430 904L etc

Wire diameter: 0.0.025mm-1.80mm

Mesh counts: plain weave 2-635 mesh, dutch weave 12*64-500*3200 mesh

Micron size: 20-500 micron

Weave style: plai/ twill/ dutch

Technique: woven

Feature: acid-resisting,alcali-resisting,wear and corrosion resistance

Application: Used imn mine, oil, chemical industry, pharmaceutical industry and machine-making etc.

Size

Mesh	Wire Diameter	Mesh	Wire Diameter	Mesh	Wire Diameter
3	1.0mm	24	0.19mm-0.5mm	90	0.1mm-0.12mm
4	0.7mm-1.5mm	26	0.19mm-0.4mm	100	0.07mm-0.14mm
5	0.6mm-1.2mm	28	0.19mm-0.35mm	110	0.08mm-0.09mm
6	0.5mm-1.0mm	30	0.15mm-0.4mm	120	0.07mm-0.1mm
7	0.5mm-0.8mm	32	0.17mm-0.3mm	140	0.06mm-0.07mm
8	0.4mm-1.0mm	34	0.23mm	150	0.06mm-0.07mm
10	0.3mm-1.0mm	35	0.25mm-0.3mm	160	0.06mm
12	0.3mm-0.8mm	36	0.15mm-0.28mm	180	0.05mm
14	0.27mm-0.7mm	40	0.12mm-0.27mm	200	0.05mm-0.06mm
16	0.25mm-0.7mm	50	0.13mm-0.25mm	300	0.03mm-0.04mm
18	0.20mm-0.55mm	60	0.1mm-0.19mm	400	0.023mm-0.03mm
20	0.19mm-0.55mm	70	0.1mm-0.15mm	500	0.025mm
22	0.21mm-0.5mm	80	0.08mm-0.17mm	635	0.018mm

Our Services

OEM	Yes
Special Sizes or Shape	Yes
Customized packing	Yes
Sample	Can be offered or Made
Delivery time	Usually within 7-15 working days
Payment terms	T/T, Western Union, PayPal., Escrow, L/C
Optional Way of Transportation	Sea Transportation, Air Transportation International Express: DHL,TNT,DEDEX,UPS,EMS

Detailed Images

Material

Material:S.S 304, 304L, 316, 316L

Graph 1: Stainless Steel Woven Wire Mesh (Twill Weave)

Mesh	Wire Diameter	Absolute filtration value(μm)	Named filtration value(μm)
20x250	.0098x.0079	110-120	98-105
30x360	.0098x.0060	90-100	80-84
40x560	.0070x.0040	70-75	47-52
120x400	.0040x.0025	50-55	37-43
120x160	.0040x.0025	40-45	28-32
80x700	.0040x.0030	35-40	24-26
200x600	.0024x.0018	28-32	19-21
165x800	.0028x.0020	24-26	14-16
165x1400	.0028x.0016	16-18	9-11
200x1400	.0028x.0016	12-14	5-6
250x1400	.0022x.0016	11-12	3-4
325x2300	.0015x.0010	8-9	2-3

Graph 2: Stainless Steel Woven Wire Mesh (Plain Weave

Mesh	Wire Diameter	Absolute filtration value(μm)	Named filtration value(μm)
8X85	.014X.0126	318 - 340	250 - 255
12X64	.024X.0165	270 - 285	200 - 205
14X88	.020X.013	225 - 245	150 - 155
20X150	.0098X.007	155 - 165	100 - 105
24X100	.015X.010	115 - 125	80 - 85
30X150	.009X.007	95 - 100	65 - 70
40X200	.007X.0055	65-70	55 - 60
50X250	.0055X.0045	55 - 60	40 - 45
80X400	.0049X.0028	43 - 48	35 - 40

Material: SS 201,202,304,304L, 316,316L, 321, 430,ect
Usage:Filters ,chemical industry, mine industry, paper-making,etc
MOQ: 10 rolls
Woven style: plain,twill,dutch
Mesh :1-100mesh
Diameter: 0.02-5.0mm
Packaging Details: inner kraft, outside plastic cloth, put into wooden pallet or case
Delivery Detail: 10-15 days after received your deposit.
Have exported: USA, EU , Japan and Africa, etc
We have free sample,if you want to know the quality,just tell us.
>>>CONTACT US

Specifications

Type	Mesh/Inch	Wire diameter	Absolute Filtration Finess µm	Nominal Filtration Finess µm
Plain Dutch Weave Wire Mesh	885-80400	0.014''0.0126''- 0.0049''0.0028''	318-340 to 43-48	250-255 to 35-40
Twill Duntch Weave Wire Mesh	20250 - 3251400	0.0098''0.0079'' - 0.0015''0.0010''	110-120 to 8-9	98-105 to 2-3
