Automatical Silkscreen Octopus Printers
| Price: |
US $ 25000/Set |
| Min Order: |
1/Set |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: |
SuperImage SPG/SPE/SPA/SPJ |
| Print Type: |
Octopus Silkscreen Printing |
| Print Head: |
Silkscreen Printing Machine |
| Max. Print Size: |
50*70cm |
| Inks Type: |
Silkscreen Inks, Plastisol Inks, Silkscreen Paste |
| Print Colors: |
Max.14 Colors for Option |
| Type: |
Automatic Screen Printing Machine |
| Structure: |
Rotary Printing Press |
| Color & Page: |
Multi-Colour Printing Press |
| Print Interface: |
USB2.0 |
| System Supported: |
Windowsxp64 |
| Style: |
Silkscreen Printing |
Product Description
SuperImage Automatical Silkscreen Octpus
SuperImage Automatical Silkscreen Printing Machine for Textile/Fabric
SuperImage Automatical Silkscreen printing press
Top Quality & Stability & Excellent Warranty
Also called: Automatic silkscreen octpus
Automatic silkscreen printing machine
Automatic silkscreen printing press
Automatic silkscreen printer
This machine is a multi-purpose rotary screen printing machine, computerized central control system human-machine interface, touch screen, all input operating instructions function to text display. Adopting imported servo motor drive of the machine, the stability is strong, adapt to a variety of printing requirements, and ensure the accuracy of printing in 0.05mm, various body parts of the machine are subject to stringent quality control in the production process, less maintenance, strive for zero failures, easy maintenance, providing customers with the highest quality, most affordable, most practical, most trusted, most satisfying printing machinery and equipment.
Scope of application:SPG series automatic printing machine can print all textile products, such as t-shirts, pajamas, fabrics, cloth, non-woven bag, umbrella, water mark, also suitable for printed boards, paperboard, Fiberboard, glass, PVC, ceramic, marble and other materials.
Main Features:1. adopting new synchronous servo system, transmission speed and better stability.
2. the table automatically rotate each station positioning accuracy (± 0.05mm).
3. blade for each colour print head uses the frequency conversion velocity modulation, micro-gas lift.
4. printing ink scraper knife pressure, angle, speed and scrape ink count can be set or adjusted.
5. easy to maintain, easy to operate.
Basic Data and Specification:
| Item | Data |
| Product Name: | Automatic silkscreen octpus
Automatic silkscreen printing machine
Automatic silkscreen printing press
Automatic silkscreen printer |
| Suitable Materials: | All types of Textile, Fabric,including cloth, non-woven bag, umbrella, water mark, also suitable for printed boards, paperboard, Fiberboard, glass, PVC, ceramic, marble and other materials. etc. |
| Max. Printing Size: | 50*70cm |
| Print Colors: | 1,2,3,4,6,8,10,12,14,etc for option |
| Max. Printing thickness of textile/fabric/materials | 10mm |
| Suitable Objects: | Clothes,garments,bags, hats, luggage,shoes,etc |
| Printing Surface: | Plain Surface |
| Operation Methods: | Full Automatic |
| Suitable Inks: | Water Silkscreen inks
Rubber paste silkscreen ink
Plastisol silkscreen inks |
| Matching Ovens Quantity: | One piece for each color
Movable ovens |
| Printing Speed: | 700pieces/hour |
Other Working Specification:| Item | Data |
| Workstation quantity: | 8pieces, octopus |
| Working Air driver pressure: | 1.0Mpa |
| Main silkscreen press power: | 2.0KW |
| The max. power of ovens: | 13.5KW |
| Installation Size: | Φ3400×1600mm |
| Machine weight: | 800KG(N.W), and 1000KG(G.W) |
Quality Warranty:
SuperImage affords full quality warranty for our automatic silkscreen octopus products.
For any inferior quality products or loss caused by inferior products quality, SuperImage will be responsible for products-changing, returning and replacements delivery, as well as related compensation.
Super image technologies Co., Limited is a leading supplier of digital print and solvent inkjet systems. Mainly superimage is involved in specializing in developing, studying, manufacturing and exporting true solvent ink, eco/mild/low solvent ink, water dye ink, water pigment ink, sublimation ink, textile inks, textile pigment inks, textile sublimation inks, reactive inks, direct-to-fabric print ink, UV curable ink, LED UV inks, ink cassettes, ink cartridges, refillable cartridges/bulk ink system, chips solution, spare parts, and inkjet media for all types of large format printers, and packages materials, alike PE protection films, stretch films, shrinkle films, wrap films, BOPP films, OPP bilms, for all types of package, electronic, automobile, appliance manufacturing fields.
Superimage tech. Has many years' Experience in larger format printing field, and package films fields. At present, our solvent ink/eco/mild solvent pigment/water dye ink/water pigment ink/sublimation ink/textile inks/UV curable ink/cartridges products/bulk ink system/spare parts, and PE fimls, protection films, and stretch films, shrinkle films, sell well in many countries and districts, such as, west Europe, north America, south America, east Europe, Far East districts, and southeast Asia.
Superimage tech. Has high-level technical staff, first-class manufacturing equipment and efficient quality-control systems. Leading technical know-how and excellent quality are its advantages and objectives. All the products have been tested for a long time before their introduction to the market.
At present, superimage' S businesses cover manufacturing, distributing, and service in the industry of advertisements, commercial graphics, photos, signs, display, package lines and so on. The objective of superimage is "to be the best one in this field".
