Canvas Tarpaulin Flatbed CO2 Laser Cutting Machine 2.1mx3.0m

Name: Canvas Tarpaulin Flatbed CO2 Laser Cutting Machine 2.1mx3.0m
Brand: FullPackage
SKU: 788309905
Availability: InStock
Rating: 4.7 (116 reviews)

Price:	US $ 10000-30000/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	TSHY210300
Laser Type:	CO2
Application Area:	Car Accessories, Plush Toys, Home Textiles
Application Material:	Fabric, Textile, Non-Woven, Leather
Power Supply:	AC220V+-5%50Hz
Graphic Format Supported:	Ai, Plt, Dxf, BMP, Dst, Dwg, Dxp
Cutting Area:	2100mmx3000mm
Output Power:	80W
Cutting Speed:	Adjustable
Working Table:	Conveyor Working Table
Guarantee:	One Year Free Maintenance

Product Description

Feature:
1, It's customized for various types fabric materials'cutting for embroidery,sportswear,printing insoles,shoes,etc
2, It's good to cut any shapes without fringe and sewing automatically.
3,Converyor working table with negative pressure adsorption function can cut long size fabric continuously and to impress you, thus the fabrics still kept flatly and smoothly.
3,The following-up fume extractor system is going with laser head to save power consumption and good fume chasing effect.
4, DSP control system support online and offline data transferring.
5, Built up a data base in computer to save space room for the cutting workshop
6, Optional auto feeding system is available to choose and no need
7, Optional CCD camera is available to copy or identify various printed materials

Notice: Our current platform working size:
1600x3000mm
2100x3000mm
3200x6000mm
Other sizes can be customized

Parameter:

Model	TSHY210300	Option
Working Area	2100mmx3000mm	According to Demands
Laser Power	40w/50w/60w/80w/100w/130w/150w
Laser Type	CO2 Sealed Laser Tube , 10.6μm
Cooling Type	Water Cooling
Engraving Speed	0-60000mm/min
Cutting Speed	0-36000mm/min
Laser Output Control	0-100% Set by Software
Min. Engraving Size	Chinese: 2.0mm2.0mm, English Letter:1.0mm1.0mm
Locating Accuracy	≤±0.01mm
Controlling Software	DSP Control System
Graphic Format Supported	DST PLT BMP DXF DWG AI LAS,etc
Compatible Software	CORELDRAW,PHOTOSHOP, AUTOCAD,TAJIMA,etc.
Color Separation	Yes
Drive System	High-precision 3-phase Stepper Motor
Auxiliary Equipments	Exhaust Fan and Air Exhaust Pipe
Power Supply	AC110V/220V+10%,50HZ/60HZ
Working Environment	Temperature:0-45C,Humidity 5-95%(No Condensate Water)
Option	Water chiller,CCD or Red Dot Position System

Sample show:

Close-up

Application:

1. Industrial textile: filter cloth, bolting cloth, filter fabric, nonwoven, glass fiber, felt, synthetic fibre, fabric ducting, polypropylene (PP), polyethylene (PE), polyester (PES), polyamide (PA), cement packing, geotextile, coated fabric, sponge, insulating material and other industrial flexible materials.
2. Non-woven fabrics for health & medical: insulating material, glass fibre, polyester fibre, Microfiber, Cleanroom Wiper, Glasses cloth, Micro-fiber Wiper, non-dust cloth, clean wiper, paper diaper, etc.
3. Home furnishing fabrics: upholster, carpet, mat, floor rug, mattress, curtain, doormat, valance, wall paper, tablecloth, bed sheet, bedspread, counterpane, dust cover, sofa fabric, etc.
4. Garment fabrics: sportswear, swimwear, diving suit, exposure suit, liner, lining, adhesive interlining, wadding piece, case-hardened cotton, synthetic leather, genuine leather, etc.
5. Automotive interiors: car seat cover, car cushion, car mat, car carpet, car rug, pillowcase, air bag, auto dustproof cover, seat belt (safety belt), etc.
6. Outdoor products: polyester, nylon, PE/PVC/TPU/EVA/Oxford fabric, Oxford polyester cloth, PVC coated fabric, Tarpaulin, canvas, PVC tarpaulin, PE tarpaulins, Sail cloth, Inflatable products, tents, Inflatable toys, Inflatable castle, Inflatable boats, surf kites, fire balloon, parachute, paraglider, parasail, rubber dinghy, canopy, awning, etc.

Our machine series:
CO2 Laser Engraving and Cutting Machine for most of the non-metal materials.
Laser Marking Machine fiber laser marker for meta tag,hardware,circuit board,machinery,plastic marking of barcode,symbol,texts,;CO2 laser marker for nonmetal (fabric,leather,textile,PU,paper,cardboard,PVC,etc) of barcode,images,floral,flying dynamic marking effects.
Metal laser Cutting Machine:YAG metal laser cutting machine(can 7-8mm Mild Steel and 5-6mm Mild Steel ), Fiber metal laser cutting machine( can cut 8-12 mm Carbon Steel )

Order Notice:
Please let us know following informations:
1.What materials you want to cut ?
2.What is the mostly used thickness and what is the maximum thickness?
3. What is the MAX dimension of your materials ?
4. After cutting, what will be the metal used for? (application)
5. Are you an end user or reseller?
According to your above information,we'll recommend the most suitable machine to you.

Demo video
https://www.youtube.com/watch?v=xs_Im20mv6g   carpet cutting
https://www.youtube.com/watch?v=GbkX77rZW_Q   labels engraving
https://www.youtube.com/watch?v=DOUXxajO3_w   insole engraving
https://www.youtube.com/watch?v=hPIgjdvG_GY      fiber laser cutting metal
https://www.youtube.com/watch?v=KJ4UGkaCjkk    fiber laser cutting machine
https://youtu.be/5PgXtVNajn4      large format fabric cutting
https://youtu.be/L6Rz6L3UaXY       embroidery applique cutting
https://youtu.be/uy6NRT4HsrU    MDF laser cutting

Taishun laser equipment Co., Ltd has been in the field of laser technology development and production for more than 20 years since the company was established, and always stand in the fore front product research and development.

Taishun company has strong Technical force and established set of perfect quality Management system, passed ISO9001: 2008 Quality Management System Certification, BV authentication, SGS and National Mandatory Product "3C" certification, which has reliable quality.

We developed 6 series of more than 10 types laser products which adopt international advanced technology. Such as, fiber laser metal cutting machine, YAG laser metal cutting machine, CO2 laser cutting and engraving machine, Fabric Flatbed laser cutting machine, Conveyor working table machine, laser marking machine and so on.

Taishun laser are good at produced medium and small laser power laser cutting machine, specially to supply one whole sets of laser processing solution scheme and related facilities for customers in plush toys, leather cutting, plush fabrics, automobile, textile, textile clothing, advertising handicrafts, electronics, medical equipment and etc. These laser equipment were widely applied in electronic circuit, auto spare parts, hardware tool, medical instrument, digital products, apparatus and instrument, optic communication component, packing and printing etc. To create a new Second-Generation small power laser cutting machine with more rapid and refinement manufacturing.
