Price: | US $ 30000-41000/Set |
---|---|
Min Order: | 1/Set |
Pay Type: | L/C,T/T,Western Union |
Purpose:It is widely used for quilting high-quality garments, quilt covers,hand bags,gloves,sleeping bags,pajamas,bed spreads,seat covers,plus material and household ornaments.
Note:When you order, please make sure the type of the bobbin, 10# or 7#.
Detail Information:
· Needle bar and press plate are connected by cam-free double-swinging device, which is with high precision and durable. This structure can avoid lubrication and dirty material effectively.
· High rigidity machine body and structure can make the machine running faster and more stable.
· Adopting the new structure of press plate's adjusting makes the machine much simple.
· Multi-span independent pattern (360°and 180° patterns are available)
· Advanced and practical up thread-break detection unit
· Computerized automatic needle-lifting speed adjustment
· New generation of CNC system, advanced machine structure, high precision quilting, dispense with too much parameter adjustment or pattern modification during quilting
· Easy preparation of CAD drawing extremely precise
· Different patterns in each line can be quilted on 3.2 m fabric and patterns can strongly combine
· Able to quilt simple embroidery patterns
· Fault detecting and indication enabling fast fault correction and return operation
Parameter(Unit mm):
Parameter(Unit mm) | 64-2A | 94-2A |
---|---|---|
Dimension(L×W×H): | 3350×1050×1750 | 4500×1050×1750 |
Quantity of needle bar: | 2 | 2 |
Quilting width: | 1600 | 2400 |
Space between needle rows: | 76.2 | 76.2 |
pace between needles: | 25.4 | 25.4 |
X-axis movement displacement: | 203.2 | 305 |
Thickness of quilting: | ≤25 | ≤25 |
Stitch length: | 2~5 | 2~5 |
Speed of production(m/h) | 20-100 | 20-100 |
Model of needle: | 16#,19# | 16#,19# |
Speed of main shaft(RPM): | 550~650 | 550~650 |
Total power required: | 4.5KW | 4.5KW |
Voltage: | 380V/50HZ , 220V/60HZ | 380V/50HZ , 220V/60HZ |
Gross weight: | 2500kg | 3500kg |
Prod Model: | 64-2A |
---|
