FDA Approval Micron Nylon/ Polyester Filter Mesh Fabric
| Price: |
US $ 1/Roll |
| Min Order: |
5/Roll |
| Pay Type: |
L/C,T/T,Western Union,Paypal |
| Prod Model: |
MS MESH |
| Mesh Count: |
25-420 Mesh Per Inch(10t-165t) |
| Color: |
White/Yellow/Black |
| Width: |
0.6m-3.68m |
| Roll Length: |
30m/50m/200m/1000m Per Roll |
| Raw Material: |
China, Japan, Swizerland Yarn |
| Application: |
Screen Printing, Filter, Bag Making |
| Guarantee: |
Replacement & Return Avaliabe |
| Order Repeat: |
98% Repeat Orders |
| Stock: |
5000m2 Normal Specification in Stock |
| Delivery Time: |
1-2 Days for Inventory |
| Material: |
100% Polyester |
| Weave Type: |
Plain |
| Printing: |
Polyester Screen Printing |
| Elasticity: |
High |
Product Description
The production according to ISO9001 quality management system. Mesh produced are from 25 mesh per inch to 480 mesh per inch (10T-165 T in cm) with the maximum width of 368cm. Our annual capacity is more than 5 million square meters. Goods exports to NORTH AMERICA, SOUTH AMERICA, EUROPE, ASIA, MIDDLE EAST and AFRICA.Main specification as follow:
The mesh size: From 25 mesh-420 mesh/inch, 10T-165T
Width range from: 0.6m-3.68m
Sample usual delivery time: Within 3-5 days
Color: White, yellow and black
Characters: Low Elongation, high tension strength
[ Company Information ]
Hebei Maishi Wire Mesh Group is one of the top manufacturers and exporters of screen printing mesh.Our company was connected with production of metal wire mesh since 1986 and monofilament polyester screen printing mesh(bolting cloth) and nylon printing meh since 1995, in China.The machinery(from Switzerland Sulzer Looms P7100 & P7150) and apparatus used in production process fully based on the high computer technology.
- dedicated and experienced weavers.
- consistent quality products.
- on-time delivery.
- we have 15 R&D technical staffs, with more than 10 years experience.
- 90% repeat customers.
- reasonable claim refund system.
[ Quality Control ]
High quality is guaranteed by the usage of high tensile, low elongation, direct spinning monofilament 100% polyester yarns (not split yarns which are weak), strict quality control in each production process and final inspection by our Quality Control System. At Final Inspection, every meter of fabric is inspected for any kind of fault according to our Quality Control System. Only tested, approved, without-fault, A-Grade fabric is sold to our customers.
[ Product Features ]
· Low Elongation
· Excellent Tear Resistance
· Very good Dimensional Stability
· Faster tensioning without damage to the threads
· Higher tension threshold and breaking point
· Improved registration due to stable tension
· No unwanted chemicals, no any chemicals treatment in the production process
· The mesh with great precision exact and regular square holes| TYPE | MESH
COUNT | APERTURE | THREAD
DIAMETER | OPENING | THICKNESS | INK THROUGH VOLUME
THE ORETICALLY | TENSILE
STRENGTH |
| | Mesh/inch | Micron | Micron | % | Micron | Cm3/m2 | N/cm |
| 6-400 | 15 | 1300 | 400 | 65 | 780-810 | 560 | 110 |
| 8-300 | 20 | 970 | 300 | 58 | 550-580 | 406 | 100 |
| 10-250 | 25 | 700 | 250 | 49 | 508-518 | 355 | 85 |
| 12-140 | 30 | 700 | 140 | 69 | 250-260 | 380 | 50 |
| 12-250 | 30 | 610 | 250 | 53 | 495-505 | 305 | 90 |
| 15-250 | 38 | 467 | 250 | 49 | 489-501 | 213 | 83 |
| 18-150 | 45 | 410 | 150 | 53 | 255-275 | 138 | 60 |
| 21-80 | 55 | 378 | 80 | 68 | 125-140 | 125 | 36 |
| 21-150 | 55 | 330 | 150 | 46 | 250-260 | 123 | 55 |
| 24-100 | 60 | 316 | 100 | 57 | 188-195 | 109 | 49 |
| 24-120 | 60 | 303 | 120 | 51 | 230-240 | 104 | 51 |
| 32-80 | 80 | 237 | 80 | 55 | 120-130 | 110 | 40 |
| 30-120 | 75 | 213 | 120 | 41 | 205-210 | 102 | 52 |
| 32-100 | 80 | 212 | 100 | 46 | 160-170 | 69 | 48.5 |
| 36-80 | 90 | 202 | 80 | 51 | 145-150 | 70 | 45 |
| 36-90 | 90 | 185 | 90 | 45 | 155-165 | 65 | 49 |
| 36-100 | 90 | 182 | 100 | 41 | 175-185 | 60 | 51 |
| 39-55 | 100 | 195 | 55 | 56 | 76-83 | 55 | 24 |
| 39-80 | 100 | 176 | 80 | 48 | 125-135 | 73 | 31 |
| 43-80 | 110 | 147 | 80 | 40.8 | 118-125 | 53 | 31 |
| 47-55 | 120 | 152 | 55 | 51 | 88-96 | 47.6 | 29 |
| 48-70 | 120 | 135 | 70 | 41 | 108-120 | 45.5 | 30 |
| 53-48 | 135 | 139 | 48 | 55 | 85-90 | 48 | 26 |
| 53-55 | 135 | 128 | 55 | 47 | 88-96 | 44.5 | 29 |
| 54-64 | 137 | 115 | 64 | 38.5 | 85-95 | 38.9 | 30 |
| 54-70 | 137 | 108 | 70 | 34 | 108-120 | 40 | 31 |
| 58-55 | 145 | 118 | 55 | 38 | 89-94 | 39.5 | 30 |
| 59-55 | 150 | 114 | 55 | 45 | 85-90 | 38 | 30 |
| 61-48 | 155 | 115 | 48 | 49 | 76-83 | 41 | 30 |
| 62-64 | 155 | 105 | 64 | 42 | 115-125 | 33 | 31 |
| 64-45 | 160 | 105 | 48 | 43 | 73-82 | 36.5 | 28 |
| 64-55 | 160 | 98 | 55 | 38 | 95-99 | 36.1 | 30 |
| 64-64 | 160 | 88 | 64 | 30 | 100-110 | 30.7 | 31 |
| 68-55 | 175 | 85 | 55 | 34 | 85-95 | 29.2 | 30 |
| 68-64 | 175 | 78 | 64 | 29 | 108-110 | 32.0 | 32 |
| 72-48 | 180 | 90 | 48 | 36 | 68-75 | 33.1 | 28 |
| 72-55 | 180 | 86 | 55 | 37 | 95-105 | 32.2 | 33 |
| 77-48 | 195 | 81 | 48 | 34 | 80-85 | 29.0 | 28 |
| 77-55 | 195 | 75 | 55 | 28 | 86-92 | 26.6 | 29 |
| 80-48 | 200 | 72 | 48 | 33 | 75-84 | 28.7 | 27 |
| 90-48 | 230 | 56 | 48 | 25 | 70-80 | 23.5 | 25 |
| 100-40 | 250 | 58 | 40 | 37 | 66-73 | 21.3 | 28.5 |
| 110-40 | 280 | 52 | 40 | 33 | 68-75 | 20.5 | 29.6 |
| 120-31 | 305 | 49 | 31 | 36 | 60-64 | 19.5 | 29 |
| 120-34 | 305 | 45 | 34 | 30.5 | 60-70 | 18.4 | 30.5 |
| 120-40 | 305 | 37 | 40 | 21 | 65-67 | 13.5 | 32 |
| 130-34 | 330 | 42 | 34 | 30 | 50-55 | 16.5 | 31 |
| 140-34 | 355 | 31 | 34 | 19.5 | 52-58 | 14.4 | 31 |
| 150-31 | 380 | 36 | 31 | 29 | 47-50 | 13.1 | 30.5 |
| 150-34 | 380 | 30 | 34 | 20.5 | 48-53 | 14.9 | 30.5 |
| 165-31 | 420 | 31 | 31 | 22.5 | 42-48 | 12.5 | 28.9 |
[ Packing &Shipping ]
We have two kind of packing type:
1.Screen printing mesh in rolls
- pack the mesh with paper tube and plastic bag, then in carton.
Suitable for large quantites and ocean shipping.2.Screen printing mesh with fold
- fold the mesh into plastic bag, then in carton.
Suitable for small quantites have no requirement on the crease.
[ FAQ ]Q:Can you print our required marks on the mesh?
A:Yes, HEBEI MAISHI can print marks according to your request.
We'll print the specification on the mesh edge if you have no special requirement.
Q:Can we get samples before buying?
A:Yes, we're pleased to offer you samples for your testing freely 2m each sizes.Maishi trust our quality can be satisfied.
Q:I am a small wholesaler, do you accept small order?
A:Small order is no problem, we'd like to grow up with you together.
Q:How can you guarantee for quality and delivery time?
A:For delivery time, we usually have stocks from 500m-10000m for common size.So, we can ship the goods in time to our customers.
We can guarantee our customers if the mesh has problems, they can return back to us;We'll ship replacement mesh free cost with next orders.
[ Contact Us ]Name : Ms. Cyan (export department)Tel direct : 0086-311-89909774
Mobile: 0086-13931165973
Welcome to send inquiry.
MAISHI Manufacture Group is an ISO: 9001: 2008 Certified and manufacture of stainless steel wire mesh, screen printing mesh, filter cloth and alloy wire mesh in China.
MAISHI was established in 1986, as one of the top manufactures of wire mesh, we aspires for complete customer satisfaction to provide high-class quality mesh products at competitive prices with an on-schedule delivery.
MAISHI exported to more than 85 countries(including Europe, the USA, Australia, the Middle East, Southeast Asia, Africa and South America etc. ) All machinery and apparatus used in production are fully based on high computer technology. MAISHI firm is accepted as the only company capable of having TSE(Chinese Standard Institution) and ISO9001: 2008 certificates.
MAISHI consists of a cohesive group of skilled and competent workers. The transparent and professional management system and well delegated power structure enables swift decision making in all department.
We firmly believe that the satisfactions of valued customers is the focal point of all business in MAISHI GROUP.
