Plastic Industrial High Speed Rolling Door Detail information:
1. Motor
ABB motor (SEW is optional). Work power source 220V/50Hz or 380V/50Hz. The power 0.55-1.5KW; F: IP55, 1500turns/minute. Operating temperature: -30-70 degree Celsius.
2. Control system
Schneider Inverter control system.
3. Steel construction system
Cover box: Galvanized steel, T=2.0 mm; Guide rail: Galvanized steel/Stainless steel /Aluminum alloy. Surface process: Electrostatic painting, various colors available.
4. Curtain:
Brand: SOIEN, imported from Europe. Material: PVC Plastic Fiber; Thickness: 1.0 mm/1.2mm/1.5mm/2.0mm; Color: Yellow/ Bluse/Orange/White/Red/Transparent
5. Safety performance
A Photo cells of both sides.
B Proximity sensor, at the bottom.
6. Operation method
Control buttons of both sides
7. Control mode(optional)
Both-side geomagnetic ring/ Both side radar/ Both-side remote control / Both-side pull cord switch / linkage interlock
8. Opening speed
Adjustable btween 1.0m/s and 2.5m/s
9. Emergency opening
Manual swing bar available in case of power failure
Remarks:
1. Established in 1997, we have gained much experience in door solutions for various industries.
2. Honors and Certifications:
A. The member of Standard Committee of China Automatic Door and Garage Door
B. The member of Committee of China Steel Structure
C. China AAA enterprise
D. ISO9001: 2000 Management certification.
E. CE Certification
Product name | High speed rolling door |
door material | French-made high -density industrial fabric |
Control system | Japanese Mitsubishi Inverter, PLC and other components. |
Dynamical systems | Motor: SEW from Germany / SNMA Power: 0.75kw~2.2kw |
Framework & rolling shaft | In 2mm thicknesses cold-roll steel sheets, or according to your order |
Cross bar | In aluminum lath |
Curtain | made in high-density polyester fabric (Thickness: 0.8mm or 1.5mm) |
Color | red, yellow, orange, blue, Grey etc. |
transparent window | transparent pvc film imported from Japan, thickness:1.5mm |
Command systems | magnetic, radar sensor, pulling rope, remote control, pushbottom |
Safe system | Photoelectric sensor, Safe edge bottom, Emergency stop protection |
Seal | seal brush are Installed inside the guides, good seal dustproof |
Cross bar | In aluminum lath |
Motor | SEW from Germany / SNMA |
Power | 0.75kw~2.2kw ( according to the size of the door) |
Photoelectric sensor | installed on the side tracks, with emergency stopping reaction when sensing obstacles |
Safe edge bottom | when the people or vehicle touch the bottom edge of falling door,it bound up automatically. |
Emergency stop protection | with emergency stop buttom on control panel |
Opening control method | Remote control, Wall switch, Radar, Geomagnetic and so on. |
F A Q1. What's the payment details?Deposit before production, and balance before shipment.2. What's the delivery time?For common order, about 7 days only.3. What about the warranty for the doors?We provide 12 months warranty for all doors and accessories.When the product quality appear.4. Do you provide OEM Service?Yes. OEM & ODM Service is ok for us.5. What's the MOQ?We accept 1 set as sample order.6. How about the package?Plywood case or Cardboard, suitable for sea freight or air freight, as your request.
