| Price: | US $ 1.8-2/Piece |
|---|---|
| Trade Terms: | FOB,DDP,FCA |
| Min Order: | 1/Piece |
| Pay Type: | T/T,Western Union,Paypal,Money Gram |
Cable Color: Aqua
Fiber counts: 2 Fiber (Duplex)
Fiber type: OM3 (50/125)
Connector type: LC-LC
Connector counts: 4 connectors
Application
¨ Telecommunication
¨ CATV, FTTH, LAN
¨ Fiber oiptic sensors
¨ Optical transmission system
¨ Test equipment
Features
¨ Screw-thread coupling mechanism
¨ Ceramic ferrules connectors
¨ Low insertion loss, high return loss
¨ Excellent mechanical endurance
¨ High credibility and stability
¨ Good in repeatability and exchangeability
¨ 100% Insertion, Return Loss, End Face and Interference inspection
Technical Data
Parameter | Unit | FC, SC, LC | ST, MU | MTRJ, MPO | E2000 | ||||||||
SM | MM | SM | MM | SM | MM | SM | |||||||
PC | UPC | APC | PC | PC | UPC | PC | PC | UPC | PC | PC | APC | ||
Insertion Loss | dB | ≤0.3 | ≤0.2 | ≤0.3 | ≤0.2 | ≤0.3 | ≤0.2 | ≤0.2 | ≤0.3 | ≤0.2 | ≤0.2 | ≤0.3 | ≤0.3 |
Return Loss | dB | ≥45 | ≥50 | ≥60 | ≥30 | ≥45 | ≥50 | ≥30 | ≥45 | ≥50 | ≥35 | ≥55 | ≥75 |
Repeatability | dB | ≤0.1 | |||||||||||
Durability | dB | ≤0.2dB typical change, 1000 matings | |||||||||||
Operating temperature | ºC | -20 ~ +75 | |||||||||||
Storage temperature | ºC | -40 ~ +85 | |||||||||||
Ordering Information
Connector | Fiber Core | Cable Diameter | Fiber Type | Polishing | Cable Jacket | Cable Color | Fiber Length |
LC SC FC ST D4 MU DIN SMA MPO MTRJ E2000
| Simplex Duplex | 0.9mm 2.0mm 3.0mm | SM:9/125um MM:50/125um MM:62.5/125um OM3 | PC UPC APC | PVC LSZH | Yellow Orange Aqua others | 1M 2M 3M
10M 20M 30M
|
| Prod Model: | LC OM3 DX |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Color: | Aqua |
| Fiber Core: | Om3 |
| Core: | Duplex |
| Polishing: | Upc |
| Wiring Devices: | ODF |
| Certification: | RoHS |
| Condition: | New |
| Type: | Fiber Patch Cord |
