P7.62 SMD 3 in 1 Video LED Display Curtain for Stage, Events, Shows (Novastar system)
| Price: |
US $ 300/Square Meter |
| Trade Terms: |
FOB,CIF,EXW |
| Min Order: |
1/Square Meter |
| Pay Type: |
T/T,Western Union |
P7.62 LED display curtain for stage
Product Description
P7.62 LED display curtain for stage is flexible LED display, super light, can be mounted on ceiling or install as a bankground of the stage to make an amazing stage. It shows some video as well as stage lighting.
Features:
1. Super light, abut 9KG/sqm.
2. Very flexible, can make many shapes for different stage requirement
3. Low power consumtion
4. Transparent
5. Easy to install and dismantle, save labor cost
6. Very safe
7. Cost effective for big screen
For more information, please send an inquiry. Thank you!
| Technical Prameters |
| PROJECT | P7.62 LED display curtain for stage |
| Pixel pitch | 55mm |
| Pixel density | 330 ls/sqm. |
| Pixel configuration | 1Red 1Green 1Blue |
| Drive mode | Static drive |
| LED lamp type | Epistar from Taiwan |
| Cabinet size(W*H*D) | 440 W(mm) | 5280 H(mm) |
| Cabinet resolution | 8 Pixels(W) | 96 Pixels(H) |
| Color scale | 65,536 degree |
| View angle(H/V) | 120/60 degree |
| Brightness (White balance) | ≥1000cd/sqm. |
| Power consumption(one cabinet) | Max:300W/sqm. Average:100W/sqm. |
| Operating Voltage | AC100V±10% or 220V ±10%; 50---60HZ |
| Net weight | 9Kg / square meter |
| Operating temperature | -20°C----+60°C (Customized power supply:-45°C---+60°C) |
| Operating humidity | 10%_95%RH |
| Life time | ≥100,000hours |
| MTBF | 5,000 hours |
| Whole Display Flatness | ≤0.5mm Juncture |
| Frame frequency | >60 Hz/s |
| Refresh rate | ≥800Hz /s |
| Control distance | 100m (without repeater), single mode fiber:20km, multi mode fiber: 500m |
| Power | 110V/220V±15% 50--60Hz |
| LED control system | Dbstar or Colorlight |
| Operating system | Windows 2000 / Windows Xp / Windows 7 |
| Protections for outdoor display | IP65 |
| Maintenance way | Rear Access |
| Accepting signal with video processor | PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI |
| Prod Model: |
P7.62 LED display curtain for stage |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Feature: |
So Lignt |
| Tube Chip Color: |
Full Color |
| Display Function: |
Video Display |
| Pixel Configuration: |
1R,1G,1B |
| Pixel Density: |
17,200 dots / m² |
| Scanning Mode: |
1/4 Scan |
| System Operating Platform: |
WIN XP |
| Display Type: |
LED Video Display |
| Application: |
Stage Performance |
| IP Rating: |
IP43 |
| Certification: |
UL |
| Pixel Pitch: |
55mm |
ENBON optoelectronics Limited is a High-tech enterprise specialized in R&D, manufacturing and sales of outdoor & indoor LED display. It was established in Jan 15, 2010 covering an area of 8, 000 square meters, with around 150 employees. By bringing in and gathering many experts from this industry, we can keep pace with the development of new technology and are able to provide creative products to meet different requests of our clients'. Right now, Enbon wins good reputation for its various ultra-thin and super-light rental outdoor and indoor LED screens, LED strip/mesh curtains, LED dance floor etc.
AlllouruproductsthavevpassedeCECEFCCCandnRoHSHcertificateses70%0ofoouruproductstarerforoexportrandngoodsdarerexportedetotovere808countriesesWeWareranaLEDEcompanynyouocanacountnonoforogoodoqualitytandncompetitivevpricingngBesidesesyouocanaalsosexpectcexcellentnprersalelesellingnandnafteresalelservicesehererewhichccontainsnprofessionalaconsultationonfreeetrainingngfreeedrawingsgsinstallationoandn2 yearsrwarrantytyWeWwilllinspectcouruproductstinstalledeinidomesticimarketeperiodicallyly.
EnbonoisiequipedewithtadvancedemachinesesuchcasaAutomatedePickc& PlacecmachineneHighgSpeedeSMTMTWavevPeakaSolderingnmachineneReflowoSolderingnMachineneHighg& lowoTemperaturerAgingnroomomVibrationotestererWaterproofotestererAntitstatici& dustsfreeeworkshopoetctcModernrautomaticiequipmentntogetherewithtouruinnovativevengineersrsdedicatedeworkersrandnexperiencedesaleseandnserviceseteamamwe'rerthehrighthsuppliereyouocanatrustsforogoodosolutionsnforoalllyouruLEDEdisplayaprojectsts.
Contactcusuforoanaofferetoday!yOuruteamawilllrespondnini1 workingndayayWeWlookoforwardrtotbebyourugoodopartnereandngrowotogether!r
